WAP-3701

Industrial Wireless Access Points, Clients, and Bridges NI WAP-3701, NI WAP-3711 Industrial Features • • • • IEEE 802.11g/b compliance 0 to 60 °C operating temperature Redundant dual 24 VDC power inputs A single device supports a wireless access point, client, and bridge • DIN-rail or panel mounting support • Metal enclosure, IP30 rated • Class I, Division 2 hazardous locations • IEEE 802.1X/RADIUS • Wi-Fi Protected Access (WPA) Software and Remote Configuration • Web-based management included • Simple Network Management Protocol (SNMP) and Universal Plug and Play (UPnP) support • Configuration backup and reset Wireless Security Features • 64- and 128-bit wired equivalent privacy (WEP) • Enabling/disabling service set identifier (SSID) broadcasts • MAC-address-based access control Overview National Instruments WAP-37x1 wireless access points (WAPs) add wireless connectivity to all Ethernet-based programmable automation controllers (PACs) such as NI CompactRIO and Compact FieldPoint. You can convert your PACs to wireless systems to reduce wiring costs or access remote locations and use the NI LabVIEW graphical development environment with both of these WAPs. An NI WAP-37x1 connects wireless devices to a wired network – it has an IP address so other wireless clients can access the device. A WAP-37x1 can also serve as a Dynamic Host Configuration Protocol (DHCP) server and configure other WAP-37x1 devices as wireless clients. A single WAP-37x1 typically can support up to 30 client devices, with the range depending on the wireless antennae selection. A WAP-37x1 also serves as a wireless bridge and allows two devices to talk to each other. The NI WAP-3701 supports the IEEE 802.11 North American 2.4 GHz band with channels from 1 to 11, and the NI WAP-3711 supports 2.4 GHz international frequency bands with channels 1 to 13. 45.80 mm (1.81 in.) 62.91 mm (2.48 in.) NATIONAL INSTRUMENTS PWR1 PWR2 WLAN LAN MAIN 44.00 mm (1.73 in.) 135.00 mm (5.31 in.) DIN-Rail Kit LAN 30.29 mm (1.19 in.) 105.00 mm (4.13 in.) Side View 52.98 mm (2.09 in.) 45.80 mm (1.80 in.) Front View Rear View 18.20 mm (0.72 in.) Panel Mounting Kit NI WAP-37x1 Mechanical Dimensions Industrial Features NI WAPs offer a dual redundant power supply with a 12 to 45 VDC input range. They are rated for 0 to 60 °C operating temperature and feature an IP30-rated metal enclosure for deployment in harsh environments. A DIN-rail and panel mounting bracket is included with each WAP-37x1. Ordering Information NI WAP-3701 ........................................................................780036-01 NI WAP-3711 ........................................................................780037-01 Accessory NI PS-5 Power Supply ..........................................................778805-90 BUY NOW! For complete product specifications, pricing, and accessory information, call 800 813 3693 (U.S.) or go to ni.com/comm. Industrial Wireless Access Points, Clients, and Bridges Specifications >> For complete specifications, see the NI WAP-37x1 User Manual Interface Antenna............................................... 2 dBi diversity antenna with an R-SMA connector RJ45 port............................................. 10/100BASE-T(X) autonegotiation speed LED indicators ..................................... PWR1, PWR2, WLAN, LAN (Link/ACT) at ni.com/manuals. WLAN Standards ............................................ IEEE 802.11g/b for Wireless LAN, IEEE 802.3u 10/100BASE-T(X) for Ethernet LAN, IEEE 802.3af for Power-over-Ethernet Frequency range.................................. 2.4 to 2.4835 GHz, direct sequence spread spectrum (DSSS) Data rate and modulation................... OFDM @ 54 Mb/s, CCK @ 11/5.5 Mb/s, DQPSK @ 2 Mb/s, and DBSK @ 1 Mb/s Operating channels North American .............................. 1-11 Europe............................................. 1-13 Security ............................................... 64- and 128-bit WEP encryption, WPA (IEEE 802.1X/RADIUS and TKIP) Data rates ........................................... 1 Mb/s, 2 Mb/s, 5.5 Mb/s, 6 Mb/s, 9 Mb/s, 11 Mb/s, 12 Mb/s, 18 Mb/s, 24 Mb/s, 36 Mb/s, 48 Mb/s, 54 Mb/s Transmit power ................................... Typical +18 dBm (±1.5 dBm) @ 11 Mb/s, +14 dBm (±1.5 dBm) @ 54 Mb/s RX sensitivity 802.11b ........................................... -81 dBm @ 11 Mb/s, -85 dBm @ 5.5 Mb/s, -86 dBm @ 2 Mb/s, -87 dBm @ 1 Mb/s 802.11g ........................................... -68 dBm @ 54 Mb/s, -70 dBm @ 48 Mb/s, -74 dBm @ 36 Mb/s, -78 dBm @ 24 Mb/s, -81 dBm @ 18 Mb/s, -84 dBm @ 12 Mb/s, -85 dBm @ 9 Mb/s, -86 dBm @ 6 Mb/s Power Input voltage ....................................... 12 to 45 VDC, redundant dual DC power inputs or 48 VDC Power-over-Ethernet (IEEE 802.3af) Input current........................................ 0.3 A (@ 24 V) Overload current protection................ 1.6 A Connection .......................................... Removable terminal block Reverse polarity protection................. Present Mechanical Casing.................................................. IP30 protection, metal case Dimensions (w by h by d).................... 53.6 by 135 by 105 mm (2.11 by 5.31 by 4.13 in.) Weight................................................. 800 g Installation .......................................... DIN-rail or wall mounting optional kit Environmental Operating temperature ....................... 0 to 60 °C (32 to 140 °F) Storage temperature........................... -20 to 70 °C (-4 to 158 °F) Ambient relative humidity .................. 5 to 95% (noncondensing) Regulatory Approvals Safety .................................................. UL60950-1, CSA C22.2 No. 60950-1, EN60950-1, TUV Hazardous locations............................ UL/cUL Class I, Division 2, Groups A, B, C, and D Emissions ............................................ FCC, CE, SRRC Radio ................................................... EN300 328 EMC .................................................... EN301489-1/-17 EMI .................................................... FCC Part 15C MTBF ................................................... 200,000 hrs Database ............................................. MIL-HDBK-217F, GB 25 °C Software Features Protocols.............................................. HTTP, DHCP, TCP/IP, RADIUS, DNS, NetBIOS, AppleTalk, and IPX/SPX Configuration....................................... Web-based management Client OS support................................ Windows XP/2000/Me/9x/NT, Unix, and Macintosh BUY ONLINE a t ni.com o r CALL 800 813 3693 (U.S.) 2 NI Services and Support NI has the services and support to meet your needs around the globe and through the application life cycle – from planning and development through deployment and ongoing maintenance. We offer services and service levels to meet customer requirements in research, design, validation, and manufacturing. Visit ni.com/services. Local Sales and Technical Support In offices worldwide, our staff is local to the country, giving you access to engineers who speak your language. NI delivers industry-leading technical support through online knowledge bases, our applications engineers, and access to 14,000 measurement and automation professionals within NI Developer Exchange forums. Find immediate answers to your questions at ni.com/support. We also offer service programs that provide automatic upgrades to your application development environment and higher levels of technical support. Visit ni.com/ssp. Training and Certification NI training is the fastest, most certain route to productivity with our products. NI training can shorten your learning curve, save development time, and reduce maintenance costs over the application life cycle. We schedule instructor-led courses in cities worldwide, or we can hold a course at your facility. We also offer a professional certification program that identifies individuals who have high levels of skill and knowledge on using NI products. Visit ni.com/training. Hardware Services NI Factory Installation Services NI Factory Installation Services (FIS) is the fastest and easiest way to use your PXI or PXI/SCXI combination systems right out of the box. Trained NI technicians install the software and hardware and configure the system to your specifications. NI extends the standard warranty by one year on hardware components (controllers, chassis, modules) purchased with FIS. To use FIS, simply configure your system online with ni.com/pxiadvisor. Professional Services Our NI Professional Services team is composed of NI applications and systems engineers and a worldwide National Instruments Alliance Partner program of more than 600 independent consultants and integrators. Services range from start-up assistance to turnkey system integration. Visit ni.com/alliance. Calibration Services NI recognizes the need to maintain properly calibrated devices for high-accuracy measurements. We provide manual calibration procedures, services to recalibrate your products, and automated calibration software specifically designed for use by metrology laboratories. Visit ni.com/calibration. OEM Support We offer design-in consulting and product integration assistance if you want to use our products for OEM applications. For information about special pricing and services for OEM customers, visit ni.com/oem. Repair and Extended Warranty NI provides complete repair services for our products. Express repair and advance replacement services are also available. We offer extended warranties to help you meet project life-cycle requirements. Visit ni.com/services. ni.com • 800 813 3693 National Instruments • info@ni.com *351532A-01* 351532A-01 2007-9141-161-101-D © 2007 National Instruments Corporation. All rights reserved. CompactRIO, FieldPoint, LabVIEW, National Instruments, National Instruments Alliance Partner, NI, ni.com, and SCXI are trademarks of National Instruments. Other product and company names listed are trademarks or trade names of their respective companies. A National Instruments Alliance Partner is a business entity independent from NI and has no agency, partnership, or joint-venture relationship with NI.
