P01-06-F-2G

Complement to MLW Rockers P01 Indicators 1 A BEZEL COLORS A B C D E F G H Black White Red Orange Yellow Green Blue Gray TYPICAL INDICATOR ORDERING EXAMPLE P01 LAMPS Incandescent 06 12 18 24 28 N 6-volt 12-volt 18-volt 24-volt 28-volt Neon 110-volt B C D E *F *G 12 CAP COLORS White Red Orange Yellow Green Blue C BEZELS 1 2 .787” (20.0mm) Wide .937” (23.8mm) Wide *F & G not suitable with neon. DESCRIPTION FOR TYPICAL ORDERING EXAMPLE P01-12-C-1A Red Cap 12-volt Incandescent Lamp Black .787” (20.0mm) Bezel LAMP CODES & SPECIFICATIONS Incandescent & Neon Lamps for Solid & Design Caps AT602 Incandescent AT602N Neon L(+) L(-) 06 6V 80mA .159 I 12 12V 50mA .215 18 18V 35mA .398 2,000 Average 24 24V 25mA .215 28 28V 22mA .247 N 110V 1.5mA NA 15,000 Avg. Voltage Current MSCP Endurance T- 1 ⁄ 2 Pilot Slide Base 1 V Hours Ambient Temperature Range –10° ~ +50°C Recommended Resistor for Neon: 33K ohms for 110V AC & 100K ohms for 220V AC Electrical specifications are determined at a basic temperature of 25°C. For dimension drawings of lamps, see Accessories & Hardware Index. If the source voltage is greater than rated voltage, a ballast resistor is required. The ballast resistor calculation and more lamp detail are shown in the Supplement section. CAP COLORS B C White Red D E Orange Yellow F G Green Blue AT429 (15.8) .622 (16.2) .638 (9.78) .385 Material: Polycarbonate Finish: Glossy F & G not suitable for neon (13.5) .531 N KK Switches • email: sales@nkkswitches.com • Phone (480) 991-0942 • Fax (480) 998-1435 • www.nkkswitches.com 03-07 Complement to MLW Rockers OPTIONAL BEZELS & COLORS P01 Indicators 1A 1E 1F 1G 1H AT204 .787” (20.0mm) Wide Bezel (16.4) .646 (2.2) .087 (16.0) .630 (20.0) .787 (25.5) 1.004 2A 2E 2F 2G 2H AT9201 .937” (23.8mm) Wide Bezel (16.4) .646 (2.5) .098 1B 1C 1D 2B 2C 2D (23.8) .937 (16.0) .630 (26.3) 1.035 Material: Polycarbonate Color Codes: A Black B White C Red Standard Finish: Glossy E Yellow F Green G Blue H Gray D Orange T YPICAL INDICATOR DIMENSIONS Without Bezel (1.2) Dia Typ .047 L1 (21.0) .827 (15.8) .622 (4.7) Typ .185 (17.0) .669 L2 (18.7) .736 (16.6) .654 (1.8) .071 (0.5) .020 (0.5) .020 (23.3) .917 (5.9) .232 (0.4) Typ .016 (3.0) Typ .118 (16.7) .657 P01-12-C Panel Thickness: .039” ~ .157” (1.0mm ~ 4.0mm) With Bezel (16.0) .630 (25.5) 1.004 (1.2) Dia Typ .047 L1 (15.8) .622 (4.7) Typ .185 (17.0) .669 L2 (18.7) .736 (16.2) .638 (20.0) .787 (2.8) .110 (2.2) .087 (0.5) .020 (22.3) .877 (5.9) .232 (0.4) Typ .016 (16.6) .654 (3.0) Typ .118 (16.7) .657 P01-12-C-1A Panel Thickness: .039” ~ .157” (1.0mm ~ 4.0mm) With Large Bezel (16.0) .630 (26.3) 1.035 (1.2) Dia Typ .047 L1 (15.8) .622 (4.7) Typ .185 (17.0) .669 L2 (0.5) .020 (16.2) .638 (23.8) .937 (2.8) .110 (2.5) .098 (22.3) .877 (5.9) .232 (0.4) Typ .016 (16.6) .654 (3.0) Typ .118 (19.2) Sq .755 P01-12-C-2A Panel Thickness: .039” ~ .157” (1.0mm ~ 4.0mm) 03-07 N KK Switches • email: sales@nkkswitches.com • Phone (480) 991-0942 • Fax (480) 998-1435 • www.nkkswitches.com
