CFC-5.5

CEILING FAN SINGLE & DUAL VERSIONS CFC SERIES The CFC series is a range of metallized polyester film capacitors designed expressly for ceiling fan use. They are a self–healing flat capacitor winding with polyester film dielectric. They are mounted in a flame retardent plastic case with an epoxy resin end–seal. The CFC series are also used in other electric fans and in fluorescent lamps. The NTE CFC series is available in 2 wire (single) and 3 wire (dual) capacitor versions. 2 WIRE SERIES NTE Type No. CFC–1 CFC–2 CFC–3 CFC–4 CFC–5 CFC–6 Cap µf 1.0 2.0 3.0 4.0 5.0 6.0 Case Dimensions – inch (mm) W 1.260 (32) 1.260 (32) 1.260 (32) 1.535 (39) 1.535 (39) 1.535 (39) H .826 (21) .826 (21) .905 (23) .905 (23) .945 (24) 1.020 (26) T .413 (10.5) .413 (10.5) .512 (13) .512 (13) .590 (15) .669 (17) FEATURES: • Small size/light weight • High Insulation resistance • Small dissipation factor 3 WIRE SERIES NTE Type No. Cap µf 2.0/4.0 2.0/5.5 3.0/6.5 3.5/1.5 5.0/8.2 6.0/14 Case Dimensions – inch (mm) W 1.535 (39) 1.978 (50) 2.017 (51) 1.535 (39) 2.017 (51) 2.017 (51) H 1.141 (29) 1.180 (30) 1.258 (32) 1.141 (29) 1.574 (40) 1.574 (40) T .748 (19) .787 (20) .866 (22) .748 (19) 1.180 (30) 1.180 (30) RATINGS Capacitance Range: 2 wire 125/250VAC – 1µfd to 6µfd 3 wire 125/250VAC – 2/4µfd to 6/14µfd CFC–2/4 CFC–2/5.5 CFC–3/6.5 CFC–3.5/1.5 CFC–5/8.2 CFC–6/14 PERFORMANCE SPECIFICATIONS Operating Temperature Range: –25°C to +70°C Insulation Resistance (at 20°C): Between Terminals: ≥ 1000MΩ Between Terminals and Case: ≥ 2000MΩ F T W .393 (10) 2 Wire Series 3 Wire Series W NOTE: F (lead space) = W – .196 (5.0) ±.039 (1.0) NTE Electronics, Inc. D Voice (800) 631–1250 (973) 748–5089 D FAX (973) 748–6224 D http://www.nteinc.com Í Í ÍÍ ÍÍ 3.965 (100) H 29
