26-12-1CE-X

O/E/N 26 MINIATURE HIGH POWER RELAY Sensitive Version Low Height Direct PCB type Dust Protected / Sealed SPECIFICATIONS Contact Arrangement Contact Material Contact Rating 1 Form C : 10 A 2 Form C : 8 A 1 Form C K-tpe : 16 A Rated Voltage Max. Switching Voltage Max. Switching Current :230VAC / 24VDC :440VAC / 125VDC : 10 A (1C), 5 A (2C) : 16 A (1CK) Contact Resistance Initial Nominal Coil Power Operating Power Life Expectancy Mechanical Electrical Dielectric Strength Between coil and contacts Between Open contacts Insulation Resistance : 5000VAC : 1000VAC : 1000Meg.Ohms @ 500 VDC,25 0C, RH 50 Operate time at nom. Volt Release time at nom. Volt Ambient Temperature Weight : 15 milli sec max : 8 milli sec max : -40oC to + 85o C : 14 g Typical Applications Industrial Electronics, UPS, Office Automation, Home Appliances All dimensions are in mm. Specifications subject to change without notice. COIL DATA HOW TO ORDER 1C,2C,1CK Pick-up Voltage (VDC) Nominal Voltage (VDC) Ohms+10% : AgNi Coil Resistance DIMENSIONS 6 12 4.2 8.4 16.8 77 90 360 1440 25200 1 Form C : 100 m Ohms 24 : 0.4 W 110 : 0.2 W : 1 x 107 operations : 1 x 105 operations CIRCUIT DIAGRAMS 1C 1 Form C(K) / 2 Form C 1CK 2C DRILLING PATTERN 1 Form C 1 Form C(K) / 2 Form C O/E/N India Ltd
