V3B-4

R Manual Swipe Magnetic Card Reader Low Cost, Compact, Manual Swipe Reader H H H H H Low power C-MOS technology Multiple configurations Same size as the Omron HSR series TTL-compatible interface (clock & data) Available with or without cover V3B Ordering Information Magnetic Tracks Supported (R, R/W) 1 R R R R — — — — R R — — 2 R R — — R R — — R R R R 3 R R — — — — R R — — R R Center — — — — — — — — — — — — JIS II — — — — — — — — — — — — IC Contact No No No No No No No No No No No No Interface TTL TTL TTL TTL TTL TTL TTL TTL TTL TTL TTL TTL Cover Yes No Yes No Yes No Yes No Yes No Yes No Cable Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Color Black Black Black Black Black Black Black Black Black Black Black Black Part Number V3B-1K V3B-1 V3B-3K V3B-3 V3B-4K V3B-4 V3B-5K V3B-5 V3B-6K V3B-6 V3B-7K V3B-7 Note: Cable harness is included with all V3B models. It is optional for V3A. J TYPICAL APPLICATIONS · Point-of Sale (POS) systems · ID card checkers · Club membership · Access management · Remote terminals for computers V3B V3B Specifications Part number Recommended card type Recording method Card feeding speed Service life of magnetic head Operating power supply Current consumption Current consumption Single track Dual track Triple track Mounting location Ambient temperature Ambient temperature Ambient humidity Ambient humidity Vibration Shock Dimensions Dimensions Weight With cover Without cover Operation Storage Operation Storage V3B-jj ISO 7810, 7811/1-6 FM decoding (F2F) 10 to 120 cm/second (10 to 100 cm/sec triple track) 300,000 passes +5 VDC ±10% 3 mA typical, 5 mA maximum 6 mA typical, 10 mA maximum 9 mA typical, 15 mA maximum Indoors—away from direct sunlight or wet, humid environment --10_ to 55_C (14_F to 131_F) --30_ to 70_C (--22_F to 158_F) 30% to 85% RH without condensation 20% to 90% RH 10 to 150 Hz, single vibration, width of 0.15 mm Peak acceleration 19.6 m/sec2 100 W x 32 H x 32.5 D mm (3.94 W x 1.26 H x 1.28 D in) 100 W x 29.5 H x 27 D mm (3.94 W x 1.16 H x 1.06 D in) Approx. 82 g with cover (52 g without cover) Engineering Data J INPUT CIRCUIT DIAGRAM +5 VDC J OUTPUT CIRCUIT DIAGRAM DC+5 V Input R1 Output R1: 100 k¦p 0V 0V 2 V3B J I/O INFORMATION Single Track Connector Harness 5-pin Molex connector part number 51102--0500. Pin # 1 2 3 4 5 Signal RDP RCP CLS +5 VDC 0 VDC Input/Output Output Output Output — — Description Read data Read clock Card loaded — — V3B Triple Track Connector Harness 12-pin Molex connector part number 51102--1200. Pin # 1 2 3 4 5 6 7 8 9 10 11 12 Description Read data 1/3 Read clock 1/3 Card loaded 1/3 Read data 2 Read clock 2 Card loaded 2 Current save — — Signal RDP1 RCP1 CLS1 RDP2 RCP2 CLS2 RDP3 RCP3 CLS3 CSV 5V 0V Input/Output Output Output Output Output Output Output Output Output Output Input — — Description Read data 1 Read clock 1 Card loaded 1 Read data 2 Read clock 2 Card loaded 2 Read data 3 Read clock 3 Card loaded 3 Current save — — Double Track Connector Harness 9-pin Molex connector part number 51102--0900. Pin # 1 2 3 4 5 6 7 8 9 Signal RDP1 RCP1 CLS1 RDP2 RCP2 CLS2 CSV 5V 0V Input/Output Output Output Output Output Output Output Input — — 3 V3B V3B Dimensions Unit: mm (inch) J V3B-VK 100 (3.94) 33 (1.30) Card Feed Direction 32 (1.26) 25 (0.98) 250 ± 20 (9.84 ± 0.79) 92 ± 0.2 (3.62 ± 0.008) 4 -- f 2.5 Depth 7 For Mounting Screw (Applicable Screw: M3 Tapping) 16 ± 0.2 (0.63 ± 0.008) 8.5 (0.33) Note: Tolerances ±0.3mm unless specified 4 V3B J V3B-V V3B Card Feed Direction Mag. head 27 (1.06) Circuit board 100 (3.94) 29.5 (1.16) 22.5 (0.89) 250 ± 20 (9.84 ± 0.79) 92 ± 0.2 (3.62 ± 0.008) 4 (0.16) For Mounting Screw (Applicable Screw: M3 Tapping) 16 ± 0.2 (0.63 ± 0.008) 5.5 (0.22) Note: Tolerances ±0.3mm unless specified 5 V3B V3B NOTE: DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters to inches divide by 25.4. R One East Commerce Drive Schaumburg, IL 60173 OMRON ELECTRONICS, INC. OMRON CANADA, INC. 1-800-55-OMRON Cat. No. GC CR3 7/00 Specifications subject to change without notice. 416-286-6465 885 Milner Avenue Scarborough, Ontario M1B 5V8 Printed in U.S.A. 6
