MM3Z2V4B-MM3Z75VB
Zener Diodes
Features
•
•
•
•
Wide Zener Voltage Range Selection, 2.4V to 75V
VZ Tolerance Selection of ±2% (B Series)
Very Small and Thin SMD package
Matte Tin(Sn) finish, Pb Free
Connection Diagram
1
2
1
2
SOD-323F
* Band Denotes Cathode
Absolute Maximum Ratings
Symbol
PD
TSTG
TJ
TA = 25°C unless otherwise noted
Parameter
Value
Units
200
mW
-65 to +150
°C
150
°C
Power Dissipation
Storage Temperature Range
Maximum Junction Temperature
Maximum Regulator Current
PD/VZ
IZM
* These ratings are limiting values above which the serviceability of the diode may be impaired.
mA
Thermal Characteristics
Symbol
RθJA
Parameter
Thermal Resistance, Junction to Ambient
Value
Unit
595
°C/W
* Device mounted on FR-4 PCB minimum land pad.
Electrical Characteristics
Symbol
VF
TA = 25°C unless otherwise specified
Parameter/ Test condition
Forward Voltage / IF=10mA
Min.
Typ.
Max.
Unit
--
--
1.0
V
Package Marking and Ordering Information
Device Marking
Device
Package
Packing
Reel Size
Tape Width
Quantity
Refer to
Product table list
Refer to
Product table list
SOD-323F
Tape & Reel
7’
12mm
3,000
© 2010 Fairchild Semiconductor Corporation
MM3Z2V4B-MM3Z75VB Rev. A4
www.fairchildsemi.com
1
MM3Z2V4B-MM3Z75VB — Zener Diodes
October 2010
TA=25°C unless otherwise noted
ZZT(Ω)
@ IZT
ZZK(Ω)
@ IZK
IZK
(mA)
IR(μA)
@ VR
VR(V)
-
Max.
-
Max
-
94
5
564
1
45
1
94
5
564
1
18
1
3.06
89
5
564
1
9
1
3.37
89
5
564
1
4.5
1
3.6
3.67
84
5
564
1
4.5
1
3.9
3.98
84
5
564
1
2.7
1
4.21
4.3
4.39
84
5
564
1
2.7
1
4.61
4.7
4.79
75
5
470
1
2.7
2
8Z
5.00
5.1
5.20
56
5
451
1
1.8
2
9Z
5.49
5.6
5.71
37
5
376
1
0.9
2
VZ (V) @ IZT
Device
Device
Type
Marking
Min.
Typ.
Max.
Max.
MM3Z2V4B
0Z
2.35
2.4
2.45
MM3Z2V7B
1Z
2.65
2.7
2.75
MM3Z3V0B
2Z
2.94
3.0
MM3Z3V3B
3Z
3.23
3.3
MM3Z3V6B
4Z
3.53
MM3Z3V9B
5Z
3.82
MM3Z4V3B
6Z
MM3Z4V7B
7Z
MM3Z5V1B
MM3Z5V6B
IZT
(mA)
MM3Z6V2B
AZ
6.08
6.2
6.32
9
5
141
1
2.7
4
MM3Z6V8B
BZ
6.66
6.8
6.94
14
5
75
1
1.8
4
MM3Z7V5B
CZ
7.35
7.5
7.65
14
5
75
1
0.9
5
MM3Z8V2B
DZ
8.04
8.2
8.36
14
5
75
1
0.63
5
MM3Z9V1B
EZ
8.92
9.1
9.28
14
5
94
1
0.45
6
MM3Z10VB
FZ
9.80
10
10.20
18
5
141
1
0.18
7
MM3Z11VB
GZ
10.78
11
11.22
18
5
141
1
0.09
8
MM3Z12VB
HZ
11.76
12
12.24
23
5
141
1
0.09
8
MM3Z13VB
JZ
12.74
13
13.26
28
5
160
1
0.09
8
MM3Z15VB
KZ
14.70
15
15.30
28
5
188
1
0.045
10.5
MM3Z16VB
LZ
15.68
16
16.32
37
5
188
1
0.045
11.2
MM3Z18VB
MZ
17.64
18
18.36
42
5
212
1
0.045
12.6
MM3Z20VB
NZ
19.60
20
20.40
51
5
212
1
0.045
14.0
MM3Z22VB
PZ
21.56
22
22.44
51
5
235
1
0.045
15.4
MM3Z24VB
RZ
23.52
24
24.48
65
5
235
1
0.045
16.8
MM3Z27VB
SZ
26.46
27
27.54
75
2
282
0.5
0.045
18.9
MM3Z30VB
TZ
29.40
30
30.60
75
2
282
0.5
0.045
21.0
MM3Z33VB
UZ
32.34
33
33.66
75
2
306
0.5
0.045
23.0
MM3Z36VB
VZ
35.28
36
36.72
84
2
329
0.5
0.045
25.2
MM3Z39VB
WZ
38.22
39
39.78
122
2
329
0.5
0.045
27.3
MM3Z43VB
XZ
42.14
43
43.86
141
2
353
0.5
0.045
30.1
MM3Z47VB
YZ
46.06
47
47.94
160
2
353
0.5
0.045
33.0
MM3Z51VB
Z
49.98
51
52.02
169
2
376
0.5
0.045
35.7
MM3Z56VB
Z
54.88
56
57.12
188
2
400
0.5
0.045
39.2
MM3Z62VB
Z
60.76
62
63.24
202
2
423
0.5
0.045
43.4
MM3Z68VB
>Z
66.64
68
69.36
226
2
447
0.5
0.045
47.6
MM3Z75VB
