NSR01L30MX
Schottky Barrier Diode
These Schottky barrier diodes are optimized for low forward
voltage drop and low leakage current.
Features
•
•
•
•
•
•
Very Low Forward Voltage Drop − 350 mV @ 1 mA
Low Reverse Current − 0.2 mA @ 10 V
100 mA of Continuous Forward Current
ESD Rating − Human Body Model: Class 3B
ESD Rating − Machine Model: Class C
This is a Halide−Free Device
This is a Pb−Free Device
www.onsemi.com
30 V SCHOTTKY
BARRIER DIODE
1
CATHODE
2
ANODE
Typical Applications
LCD and Keypad Backlighting
Camera Photo Flash
Buck and Boost dc−dc Converters
Reverse Voltage and Current Protection
Clamping & Protection
MARKING
DIAGRAM
Markets
•
•
•
•
•
PIN 1
X3DFN2
CASE 152AF
L
Mobile Handsets
MP3 Players
Digital Camera and Camcorders
Notebook PCs & PDAs
GPS
M
L
•
•
•
•
•
M
= Specific Device Code
(Rotated 180°)
= Date Code
ORDERING INFORMATION
Device
Package
Shipping†
NSR01L30MXT5G
X3DFN2
(Pb−Free)
10000 /
Tape & Reel
MAXIMUM RATINGS
Rating
Symbol
Value
Unit
Reverse Voltage
VR
30
V
Forward Current (DC)
IF
100
mA
Forward Surge Current
IFSM
(60 Hz @ 1 cycle)
ESD Rating:
Human Body Model
Machine Model
A
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
2.0
ESD
>8.0
>400
kV
V
Stresses exceeding those listed in the Maximum Ratings table may damage the
device. If any of these limits are exceeded, device functionality should not be
assumed, damage may occur and reliability may be affected.
© Semiconductor Components Industries, LLC, 2016
April, 2016 − Rev. 2
1
Publication Order Number:
NSR01L30MX/D
NSR01L30MX
THERMAL CHARACTERISTICS
Characteristic
Max
Unit
RqJA
PD
695
180
°C/W
mW
Storage Temperature Range
Tstg
−55 to +150
°C
Junction Temperature
TJ
+150
°C
Max
Unit
Thermal Resistance
Junction−to−Ambient (Note 1)
Total Power Dissipation @ TA = 25°C
Symbol
Min
Typ
1. Mounted onto a 4 in square FR−4 board 100 mm sq. 2 oz. Cu 0.06” thick single−sided. Operating to steady state.
ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted)
Characteristic
Symbol
Reverse Leakage
(VR = 10 V)
(VR = 30 V)
IR
Forward Voltage
(IF = 1 mA)
(IF = 10 mA)
VF
Total Capacitance
(VR = 5.0 V, f = 1 MHz)
CT
Min
Typ
mA
0.2
0.5
V
0.35
0.46
0.8
pF
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
www.onsemi.com
2
NSR01L30MX
TYPICAL CHARACTERISTICS
100
1000
Ir, REVERSE CURRENT (mA)
150°C
10
75°C
25°C
125°C
1
−25°C
10
75°C
125°C
1
25°C
0.1
0.01
−25°C
0.001
−55°C
0.0001
0.1
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
0
5
10
15
20
VF, FORWARD VOLTAGE (V)
VR, REVERSE VOLTAGE (V)
Figure 1. Forward Voltage
Figure 2. Leakage Current
2.5
CT, TOTAL CAPACITANCE (pF)
IF, FORWARD CURRENT (mA)
150°C
100
TA = 25°C
2
1.5
1
0.5
0
0
5
10
15
20
VR, REVERSE VOLTAGE (V)
Figure 3. Total Capacitance
www.onsemi.com
3
25
30
25
30
MECHANICAL CASE OUTLINE
PACKAGE DIMENSIONS
X3DFN2, 0.62x0.32, 0.355P, (0201)
CASE 152AF
ISSUE A
DATE 17 FEB 2015
SCALE 8:1
NOTES:
1. DIMENSIONING AND TOLERANCING PER
ASME Y14.5M, 1994.
2. CONTROLLING DIMENSION: MILLIMETERS.
A B
D
PIN 1
INDICATOR
(OPTIONAL)
DIM
A
A1
b
D
E
e
L2
E
TOP VIEW
0.05 C
A
2X
0.05 C
A1
SIDE VIEW
C
MILLIMETERS
MIN
MAX
0.25
0.33
−−−
0.05
0.22
0.28
0.58
0.66
0.28
0.36
0.355 BSC
0.17
0.23
GENERIC
MARKING DIAGRAM*
SEATING
PLANE
PIN 1
XM
e
1
2X
0.05
M
2
2X
b
X = Specific Device Code
M = Date Code
0.05
L2
M
C A B
RECOMMENDED
MOUNTING FOOTPRINT*
C A B
BOTTOM VIEW
0.74
2X
0.30
1
2X
0.31
DIMENSIONS: MILLIMETERS
See Application Note AND8398/D for more mounting details
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
DOCUMENT NUMBER:
DESCRIPTION:
98AON56472E
Electronic versions are uncontrolled except when accessed directly from the Document Repository.
Printed versions are uncontrolled except when stamped “CONTROLLED COPY” in red.
X3DFN2, 0.62X0.32, 0.355P, (0201)
PAGE 1 OF 1
