PD-1100-N

Optoway InGaAs PIN PHOTODIODES FEATURES High responsivity for dual windows at 1310 nm and 1550 nm Low dark current Quick pulse response Hermetically sealed 3-pin metal case Active diameter 75 μm PD-1100 **************************************************************************************************************************************************************** PD-1100 SERIES **************************************************************************************************************************************************************** DESCRIPTION PD-1100 series InGaAs Photodiode are suited to receive the light at the wavelength range from 1100 nm to 1600 nm. With high reliability, PD-1100 series are the best choice for telecom and datacom application. ELECTRICAL AND OPTICAL CHARACTERISTICS (TC=25ºC) Symbol Parameter Test Conditions Min. Typ. Max. Unit Active Area Detection Range R Idark C Tr /Tf BW Responsivity Dark Current Capacitance Rise/Fall Time Bandwidth VR=5V, λ=1300nm VR=5V, λ=1550nm VR=5V VR=5V VR=5V, 10~90% VR=5V 2 1100 0.85 0.90 75 1600 0.3 0.7 0.7 1.0 0.3 μm nm A/W nA pF ns GHz ABSOLUTE MAXIMUM RATINGS (TC=25 ºC) Symbol Parameter Po VRD IFD Topr Tstg Input Optical Power Reverse Voltage Forward Current Operating Temperature Storage Temperature Ratings 10 20 10 -40~+85 -40~+85 Unit mW V mA ºC ºC *************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT PD-1100 **************************************************************************************************************************************************************** Focal Plane PHOTOSENSITIVE SURFACE PHOTOSENSITIVE SURFACE Basic Plane CASE PD(+) CASE PD(+) PD(-) PD(-) Note: 1. Specifications subject to change without notice. 2. Other PIN assignment is available upon request. ORDER INFORMATION Part No.: P D− 1 1 0 □ − □ □ Code 1 3 5 Code 0 5 Wavelength 1310 / 1550 nm 1310 nm 1550 nm Package Ball Lens Cap Flat Window Cap Code Blank 100 150 Diameter 75 μm 100 μm 150 μm Code Blank N Package Flat Window Cap Ball Lens Cap *************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway Revision History Version 1.0 2.0 Initial datasheet Revise mechanical drawing PD-1100 **************************************************************************************************************************************************************** Subject Release Date 2002/12/1 2009/4/9 *************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 4/9/2009 V2.0
