PD-1100

Optoway 1.3 µm WDM PIN PHOTODIODES FEATURES ² ² ² ² ² ² High responsivity at 1310 nm High attenuation at 1550 nm Low dark current Quick pulse response Hermetically sealed 3-pin metal case Active diameter 75 μm PD-3100 **************************************************************************************************************************************************************** PD-3100 SERIES **************************************************************************************************************************************************************** DESCRIPTION PD-3100 series InGaAsP Photodiode are suited to receive the light at the wavelength 1310 nm. With high reliability and high isolation between 1310 nm and 1550 nm (at least 30 dB), PD-3100 series are the best choice for 1310 nm / 1550 nm WDM telecom and datacom application. ELECTRICAL AND OPTICAL CHARACTERISTICS (TC=25ºC) Symbol Parameter Active Area Detection Range R Idark C Tr /Tf BW Responsivity Dark Current Capacitance Rise/Fall Time Bandwidth VR=5V, λ=1300nm λ=1550nm VR=5V VR=5V VR=5V, 10~90% VR=5V 2 1260 0.8 0.3 0.7 Test Conditions Min. Typ. 75 1310 1360 0.005 0.7 0.9 0.3 Max. Unit μm nm A/W nA pF ns GHz ABSOLUTE MAXIMUM RATINGS (TC=25 ºC) Symbol Parameter Po VRD IFD Topr Tstg Input Optical Power Reverse Voltage Forward Current Operating Temperature Storage Temperature Ratings 10 20 10 -40~+85 -40~+85 Unit mW V mA ºC ºC **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 6/1/2002 V1.0 Optoway MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT PD-3100 **************************************************************************************************************************************************************** C ASE PD( + ) C ASE P D( + ) P D( - ) PD( - ) Note: 1. Specifications subject to change without notice. 2. Other PIN assignment is available upon request. ORDER INFORMATION Part No.: P D− 3 1 □ Code 0 □ Diameter 75 µm Code 0 5 Package Ball Lens Cap Flat Window Cap Code Wavlength 1 1310 / 1550 nm 3 5 1310 nm 1550 nm **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 6/1/2002 V1.0
