PD-1110_09

Optoway InGaAs PIN PHOTODIODES FEATURES High responsivity for dual windows at 1310 nm and 1550 nm Low dark current Quick pulse response Hermetically sealed 3-pin metal case Active diameter 300 μm PD-1110 **************************************************************************************************************************************************************** PD-1110 SERIES **************************************************************************************************************************************************************** DESCRIPTION PD-1110 series InGaAs Photodiode are suited to receive the light at the wavelength range from 1100 nm to 1620 nm. With high reliability, PD-1110 series are the best choice for telecom and datacom application. ELECTRICAL AND OPTICAL CHARACTERISTICS (TC=25ºC) Symbol Parameter Active Area Detection Range R Responsivity VR=5V, λ=1300nm VR=5V, λ=1550nm Idark C Tr /Tf BW Dark Current Capacitance Rise/Fall Time Bandwidth VR=5V VR=5V VR=5V, 10~90% VR=5V 500 1100 0.85 0.90 2 6 5 10 2 nA pF ns MHz Test Conditions Min. Typ. 300 1620 Max. Unit μm nm A/W ABSOLUTE MAXIMUM RATINGS (TC=25 ºC) Symbol Parameter Po VRD IFD Topr Tstg Input Optical Power Reverse Voltage Forward Current Operating Temperature Storage Temperature Ratings 10 20 10 -40~+85 -40~+85 Unit mW V mA ºC ºC **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT PD-1110 **************************************************************************************************************************************************************** Focal Plane PHOTOSENSITIVE SURFACE PHOTOSENSITIVE SURFACE Basic Plane CASE PD(+) CASE PD(+) PD(-) PD(-) Note: 1. Specifications subject to change without notice. 2. Other PIN assignment is available upon request. ORDER INFORMATION Part No.: P D− 1 1 1 □−□ Code 0 5 Package Ball Lens Cap Flat Window Cap Code Blank N Package Flat Window Cap Ball Lens Cap **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway Revision History Version 1.0 2.0 Initial datasheet Revise mechanical drawing PD-1110 **************************************************************************************************************************************************************** Subject Release Date 2002/6/1 2009/4/9 **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw 4/9/2009 V2.0
