Optoway
InGaAs PIN PHOTODIODES
FEATURES
High responsivity for dual windows at 1310 nm and 1550 nm Low dark current Quick pulse response Hermetically sealed 3-pin metal case Active diameter 300 μm
PD-1110
****************************************************************************************************************************************************************
PD-1110 SERIES
****************************************************************************************************************************************************************
DESCRIPTION
PD-1110 series InGaAs Photodiode are suited to receive the light at the wavelength range from 1100 nm to 1620 nm. With high reliability, PD-1110 series are the best choice for telecom and datacom application.
ELECTRICAL AND OPTICAL CHARACTERISTICS (TC=25ºC)
Symbol Parameter Active Area Detection Range R Responsivity VR=5V, λ=1300nm VR=5V, λ=1550nm Idark C Tr /Tf BW Dark Current Capacitance Rise/Fall Time Bandwidth VR=5V VR=5V VR=5V, 10~90% VR=5V 500 1100 0.85 0.90 2 6 5 10 2 nA pF ns MHz Test Conditions Min. Typ. 300 1620 Max. Unit μm nm A/W
ABSOLUTE MAXIMUM RATINGS (TC=25 ºC)
Symbol Parameter Po VRD IFD Topr Tstg Input Optical Power Reverse Voltage Forward Current Operating Temperature Storage Temperature Ratings 10 20 10 -40~+85 -40~+85 Unit mW V mA ºC ºC
****************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw
4/9/2009 V2.0
Optoway
MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT
PD-1110
****************************************************************************************************************************************************************
Focal Plane PHOTOSENSITIVE SURFACE PHOTOSENSITIVE SURFACE Basic Plane
CASE
PD(+)
CASE
PD(+)
PD(-)
PD(-)
Note: 1. Specifications subject to change without notice. 2. Other PIN assignment is available upon request.
ORDER INFORMATION
Part No.: P D− 1 1 1 □−□
Code 0 5
Package Ball Lens Cap Flat Window Cap
Code Blank N
Package Flat Window Cap Ball Lens Cap
****************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw
4/9/2009 V2.0
Optoway
Revision History
Version
1.0 2.0 Initial datasheet Revise mechanical drawing
PD-1110
****************************************************************************************************************************************************************
Subject
Release Date
2002/6/1 2009/4/9
****************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax: 886-3-5979737 http: // www.optoway.com.tw
4/9/2009 V2.0
