PD-1500-SB

Optoway GaAs PIN PD MODULES GaAs PIN PHOTODIODE WITH RECEPTACLE FEATURES ² ² ² High responsivity at 850 nm Low dark current Quick pulse response PD-8500 **************************************************************************************************************************************************************** PD-8500 SERIES ****************************************************************************************************************************** ********************************** APPLICATION SDH, ATM, LAN DESCRIPTION PD-8500 series are designed for coupling a fiber with high reliable GaAs PIN photodiodes. are specially designed as detector for Datacom and Telecom application. ELECTRICAL AND OPTICAL CHARACTERISTICS (TC=25ºC) Symbol Parameter Detection Range R Idark C Tr /Tf BW Responsivity Dark Current Capacitance Rise/Fall Time Bandwidth λ VR=5V, λ=850 nm VR =5V VR =5V VR =5V, 10~90% VR =5V 2 0.45 Test Conditions Min. Typ. 850 0.5 0.2 0.4 0.5 0.6 0.15 Max. Unit nm A/W nA pF ns GHz PD-8500 series Absolute Maximum Ratings (TC=25 ºC) Symbol Po VRD IFD Topr Tstg Parameter Input Optical Power PD Reverse Voltage PD Forward Current Operating Temperature Storage Temperature Ratings 2 20 2 -40~+85 -40~+85 Unit mW V mA ºC ºC **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax:886-3-5979737 http: // www.optoway.com.tw 2/1/2003 V1.0 Optoway MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT PD-8500 **************************************************************************************************************************************************************** T hru Holes 2.2 dia. Note: 1. Specifications subject to change without notice. 2. Other PIN assignment is available upon request. ORDER INFORMATION Part No.: P D − 8 5 0 0− □□ Code F FB T S SB Connector Type FC/PC FC/PC (Board Mount) ST/PC SC/PC SC/PC (Board Mount) Code Wavelength 1 1310/1550 nm 3 1310 nm 5 1550 nm 8 850 nm **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax:886-3-5979737 http: // www.optoway.com.tw 2/1/2003 V1.0
