PD-8100_09

Optoway GaAs PIN PHOTODIODES FEATURES High responsivity at 850 nm Low dark current Quick pulse response Hermetically sealed 3-pin metal case Active diameter 100 μm PD-8100 **************************************************************************************************************************************************************** PD-8100 SERIES **************************************************************************************************************************************************************** DESCRIPTION PD-8100 series InGaAs Photodiode are suited to receive the light at the wavelength 850 nm. With high reliability, PD-8100 series are the best choice for telecom and datacom application. ELECTRICAL AND OPTICAL CHARACTERISTICS (TC=25ºC) Symbol Parameter Active Area Detection Range R Idark C Tr /Tf BW Responsivity Dark Current Capacitance Rise/Fall Time Bandwidth VR=5V, λ=850nm VR=5V VR=5V VR=5V, 10~90% VR=5V 2 0.45 Test Conditions Min. Typ. 100 850 0.50 0.1 0.4 0.7 0.7 0.15 Max. Unit μm nm A/W nA pF ns GHz ABSOLUTE MAXIMUM RATINGS (TC=25 ºC) Symbol Parameter Po VRD IFD Topr Tstg Input Optical Power Reverse Voltage Forward Current Operating Temperature Storage Temperature Ratings 2 20 2 -40~+85 -40~+85 Unit mW V mA ºC ºC **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT PD-8100 **************************************************************************************************************************************************************** Focal Plane PHOTOSENSITIVE SURFACE PHOTOSENSITIVE SURFACE Basic Plane CASE PD(+) CASE PD(+) PD(-) PD(-) Note: 1. Specifications subject to change without notice. 2. Other PIN assignment is available upon request. ORDER INFORMATION Part No.: P D− 8 1 0 □ Code 0 Diameter 100 μm Code 0 5 Package Ball Lens Cap Flat Window Cap **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway Revision History Version 1.0 2.0 Initial datasheet Revise mechanical drawing PD-8100 **************************************************************************************************************************************************************** Subject Release Date 2002/9/1 2009/4/9 **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 4/9/2009 V2.0
