PD-8150-100

Optoway GaAs PIN PHOTODIODES PIN Photodiode with Mini-Size TO Package FEATURES High Responsivity for 850 nm Low Dark Current Quick Pulse Response 2.4 mm Mini-Size Package Active Diameter 100μm PD-8150 ************************************************************************************************************************************************************** PD-8150 Series ************************************************************************************************************************************************************ DESCRIPTION PD-8150 series InGaAs Photodiode are suited to receive the light at the wavelength range from 600 nm to 1000 nm. With high reliability, PD-8150 series are the best choice for datacom application. ELECTRICAL AND OPTICAL CHARACTERISTICS (TC=25ºC) Symbol Parameter Active Area Detection Range R Idark C Tr /Tf BW Responsivity Dark Current Capacitance Rise/Fall Time Bandwidth VR=5V, λ=850nm VR=5V VR=5V VR=5V, 10~90% VR=5V 2 600 0.45 0.5 0.1 0.4 Test Conditions Min. Typ. 100 1000 0.7 0.7 0.15 Max. Unit μm nm A/W nA pF ns GHz ABSOLUTE MAXIMUM RATINGS (TC=25 ºC) Symbol Parameter Po VRD IFD Topr Tstg Input Optical Power Reverse Voltage Forward Current Operating Temperature Storage Temperature Ratings 10 20 10 -40~+85 -40~+85 Unit mW V mA ºC ºC ************************************************************************************************************************************************************ OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 e-mail: sales@optoway.com.tw http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT Focal Plane PD-8150 ************************************************************************************************************************************************************** Photosensitive surface 2.0±0.3 Convex 0.1 Concave 0.1 Basic Plane Photosensitive surface PD-8150 ORDER INFORMATION Part No.: P D− 8 1 5 PD-8155 □ − □□□ Code 0 5 Cap Flat Window Ball lens Code 100 Chip Diameter 100 μm ************************************************************************************************************************************************************ OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 e-mail: sales@optoway.com.tw http: // www.optoway.com.tw 4/9/2009 V2.0 Optoway Revision History Version 1.0 2.0 Initial datasheet Revise mechanical drawing PD-8150 ************************************************************************************************************************************************************** Subject Release Date 2004/8/1 2009/4/9 ************************************************************************************************************************************************************ OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 e-mail: sales@optoway.com.tw http: // www.optoway.com.tw 4/9/2009 V2.0
