PD-8300_07

Optoway GaAs PIN PD MODULES GaAs PIN PHOTODIODE WITH 62.5/125 μm MULTI-MODE FIBER PIGTAIL FEATURES High responsivity at 850 nm Low dark current Quick pulse response Coaxial Module with 50/125 μm Multi-Mode Fiber: PD-8300 Coaxial Module with 9/125 μm Multi-Mode Fiber: PD-8310 Coaxial Module with 62.5/125 μm Multi-Mode Fiber: PD-8320 PD-8300 **************************************************************************************************************************************************************** PD-8300 SERIES **************************************************************************************************************************************************************** APPLICATION SDH, ATM, LAN DESCRIPTION PD-8300 series are designed for coupling a multi-mode or single-mode fiber with high reliable GaAs PIN photodiodes. PD-8300 series are specially designed as detector for Datacom and Telecom application. ELECTRICAL AND OPTICAL CHARACTERISTICS (Tc=25ºC) Symbol Parameter Detection Range R Idark C Tr/Tf BW Responsivity Dark Current Capacitance Rise/Fall Time Bandwidth λ VR=5V, λ=850nm VR=5V VR=5V VR=5V, 10~90% VR=5V 2 0.45 Test Conditions Min. Typ. 850 0.5 0.1 0.7 1.0 0.2 Max. Unit nm A/W nA pF ns GHz Absolute Maximum Ratings (Tc=25 ºC) Symbol Po VRD IFD Topr Tstg Parameter Input Optical Power PD Reverse Voltage PD Forward Current Operating Temperature Storage Temperature Ratings 2 20 2 -40~+85 -40~+85 Unit mW V mA ºC ºC **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax:886-3-5979737 http: // www.optoway.com.tw 6/1/2007 V1.0 Optoway MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT PD-8300 **************************************************************************************************************************************************************** Note: 1. Specifications subject to change without notice. 2. Other PIN assignment is available upon request. ORDER INFORMATION Part No.: P D − 8 3 □ 0 − □ □□ Code 0 1 2 Code V H X Fiber 50/125 μm 9/125 μm 62.5/125 μm Flange Vertical Horizontal No Flange Code S F T X SA FA Connector Type SC/PC FC/PC ST/PC No Connector SC/APC FC/APC **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax:886-3-5979737 http: // www.optoway.com.tw 6/1/2007 V1.0 Optoway Revision History Version 1.0 Initial datasheet PD-8300 **************************************************************************************************************************************************************** Subject Release Date 2007/6/1 **************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 E-mail: sales@optoway.com.tw Fax:886-3-5979737 http: // www.optoway.com.tw 6/1/2007 V1.0
