Optoway FEATURES DESCRIPTION SPM-7100WG 1 *********************************************************************************************************************************************************************** SPM-7100WG (RoHS Compliant) 3.3V / 850 nm / 1.25 Gbps Digital Diagnostic LC SFP MULTI-MODE TRANSCEIVER ********************************************************************************************************************************************************************* l Hot-Pluggable SFP Footprint LC Optical Transceiver l Small Form-Factor Pluggable (SFP) MSA compatible l Compliant with IEEE 802.3z Gigabit Ethernet 1000BASE-SX l Compliant with Fiber Channel FC-PH-2 for 100-M5-SN-1 and 100-M6-SN-1 l SFF-8472 Digital Diagnostic Function l 300 m links with 62.5/125 µ m MMF Cables l 550 m links with 50/125 µ m MMF Cables l AC/AC Coupling according to MSA l Single +3.3 V Power Supply l RoHS Compliant l -10 to 85oC Operation l Class 1 Laser International Safety Standard IEC 60825 Compliant The SPM-7100WG series multi-mode transceivers is small form factor pluggable module for bi-directional serial optical data communications such as Gigabit Ethernet 1000BASE-SX and Fiber Channel FC-PH-2 for 100-M5-SN-1 and 100-M6-SN-1. It is with the SFP 20-pin connector to allow hot plug capability. Digital diagnostic functions are available via an I2C series bus specified in the SFP MSA SFF-8472. This module is designed for multi-mode fiber and operates at a nominal wavelength of 850 nm. The transmitter section uses a Vertical Cavity Surface Emitted Laser (VCSEL) and is a Class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated GaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. APPLICATIONS l l l l Gigabit Ethernet Switches and Routers Fiber Channel Switch Infrastructure XDSL Applications Metro Edge Switching LASER SAFETY This multi-mode transceiver is a Class 1 laser product. It complies with IEC 60825 and FDA 21 CFR 1040.10 and 1040.11. The transceiver must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug. Temp. (oC) -10 to 85 TX Power (dBm) -4 to -9 RX Sens. (dBm) -17 RoHS Compliant Yes ORDER INFORMATION P /No. SPM-7100WG Bit Rate (Gb/s) 1.25 Distance Wavelength Package (m) (nm) 300 / 550* 850 LC SFP with DMI *: 300 meter for 62.5/125 µm MM fiber; 550 meter for 50/125 µm MM Fiber. Absolute Maximum Ratings Parameter Storage Temperature Operating Case Temperature Power Supply Voltage Symbol Tstg Topr Vcc Min -40 -10 -0.5 Max 85 85 3.6 Units o C o C V Notes Recommended Operating Conditions Parameter Power Supply Voltage Operating Case Temperature Power Supply Current Data Rate Symbol Vcc Topr ICC (TX+RX) 1063 1250 Min 3.1 -10 Typ 3.3 Max 3.5 85 250 Units / Notes V o C mA Mb/s *********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway Transmitter Specifications (-10 oC < Topr < 85 oC, 3.1V < Vcc < 3.5V) Parameter Optical Optical Transmit Power Output Center Wavelength Output Spectrum Width Extinction Ratio Optical Rise Time Optical Fall Time Relative Intensity Noise Electrical Data Input Current – Low Data Input Current – High Differential Input Voltage TX Disable Input Voltage – Low TX Disable Input Voltage – High TX Disable Assert Time TX Disable Deassert Time TX Fault Output Voltage -- Low TX Fault Output Voltage -- High Symbol Po λ ∆λ ER tr tf RIN IIL IIH VIH - V IL TDIS, L TDIS, H T ASSERT TDEASSERT TFaultL TFaultH Min -9 830 --9 Typ ------Max -4 860 0.85 --260 260 -117 Units dBm nm nm dB ps ps dB/Hz µA µA V V V µs ms V V SPM-7100WG Notes 1 RMS (σ) 20 % to 80% Values 20 % to 80% Values 2 *********************************************************************************************************************************************************************** -350 0.5 0 2.0 350 2.4 0 .5 Vcc 10 1 0 .5 Vcc+0.3 Peak-to-Peak 2 2 0 2.0 3 3 1. Output power is power coupled into a 62.5/125 µm MM fiber. 2. There is an internal 4.7K to 10K ohm pull-up resistor to VccTX. 3. Open collector compatible, 4.7K to 10K ohm pull-up to Vcc (Host Supply Voltage). Receiver Specifications (-10oC < Topr < 85oC, 3.1V < Vcc < 3.5V) Parameter Optical Sensitivity Maximum Input Power Signal Detect -- Asserted Signal Detect -- Deasserted Signal detect -- Hysteresis Wavelength of Operation Electrical Differential Output Voltage Output LOS Voltage -- Low Output LOS Voltage -- High Symbol Sens Pin Pa Pd Min Typ Max -17 -3 ---30 1.0 700 0.6 0 2.0 0 -------17 --900 2.0 0.5 Vcc+0.3 Units dBm dBm dBm dBm dB nm V V V Notes 4 4 Transition: low to high Transition: high to low VOH – VOL VOL VOH 5 5 4. Measured at 2 7-1 PRBS at BER 1E-12. 5. Open collector compatible, 4.7K to 10K ohm pull-up to Vcc (Host Supply Voltage). ************************************************************************************************************************************************************************ OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway CONNECTION DIAGRAM SPM-7100WG 3 *********************************************************************************************************************************************************************** PIN 1 2 3 4 5 6 7 8 9 10 Signal Name TX GND TX Fault TX Disable MOD-DFE2 MOD-DEF1 MOD-DEF0 N/C LOS RX GND RX GND Description Transmitter Ground Transmitter Fault Indication T ransmitter Disable (Module disables on high or open) Modulation Definition 2 – Two wires serial ID Interface Modulation Definition 1 – Two wires serial ID Interface Modulation Definition 0 – Ground in Module Not Connected Loss of Signal Receiver Ground Receiver Ground PIN 11 12 13 14 15 16 17 18 19 20 Signal Name Description RX GND Receiver Ground RX DATA OUT- Inverse Receiver Data Out RX DATA OUT+ Receiver Data Out RX GND Vcc RX Vcc TX TX GND TX DATA IN+ TX DATA INTX GND Receiver Ground Receiver Power – 3 .3V±5% Transmitter Power – 3 .3V±5% Transmitter Ground Transmitter Data In Inverse Transmitter Data In Transmitter Ground Module Definition Module Definition 4 MOD-DEF2 PIN 4 SDA MOD-DEF1 PIN 5 SCL MOD-DEF0 PIN 6 LV-TTL Low Interpretation by Host Serial module definition protocol Module Definition 4 specifies a serial definition protocol. For this definition, upon power up, MOD-DEF(1:2) appear as no connector (NC) and MOD-DEF(0) is TTL LOW. When the host system detects this condition, it activates the serial protocol. The protocol uses the 2-wire serial CMOS E 2PROM protocol of the ATMEL AT24C01A/02/04 family of components. ************************************************************************************************************************************************************************ OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway RECOMMENDED CIRCUIT SCHEMATIC VeeT Tx_DISABLE Tx_FAULT (1,17,20) 3 2 4.7K to 10KΩ TD + 18 Z=50Ω TD 19 Z=50Ω VccT 16 10nF 1μH Vcc 3.3V 10μF 10nF 1μH VccR 15 10nF 10μF 10μF TD TD + SPM-7100WG 4 *********************************************************************************************************************************************************************** Tx_DISABLE Tx_FAULT LD Driver 100Ω SerDes IC Protocol IC RD - 12 Z=50Ω 100Ω RD - POST Amp RD + 13 Z=50Ω 4.7K to 10KΩ RD + depending on SERDES LOSS OF SINGAL LOS VeeR MOD_DEF(0) 8 (9,10,11,14) 6 5 4 4.7K to 10KΩ Vcc 3.3V 4.7K to 10KΩ MODULE DETECT SCL SDA 4.7K to 10KΩ EEPROM MOD_DEF(1) MOD_DEF(2) SFP module PACKAGE DIAGRAM Units in mm Note: Specifications subject to change without notice. ************************************************************************************************************************************************************************ OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway Revision History V ersion 1 .0 2 .0 SPM-7100WG 5 *********************************************************************************************************************************************************************** Subject Initial datasheet Revise package diagram for high port density use Release Date 2005/12/1 2008/1/1 ************************************************************************************************************************************************************************ OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0
