SPS-9102MWG_08

Optoway SPS-9102MWG / SPS-9102AMWG FEATURES l l l l l l l l l l l l l SPS-9102MWG 1 *********************************************************************************************************************************************************************** (RoHS Compliant) DESCRIPTION 3.3V / 1310 nm / Multirate Digital Diagnostic SFP LC SINGLE-MODE TRANSCEIVER ********************************************************************************************************************************************************************** Hot-Pluggable SFP Footprint LC Optical Transceiver Small Form-Factor Pluggable (SFP) MSA compatible Up to 2.67 Gb/s bi-directional data links Compliant with Intra-Office SONET OC-48 SR / SDH STM-16 (I-16) Compliant with Fibre Channel 1X/2X SM-LC-L FC-PI Compliant with IEEE 802.3z 1000BASE-LX SFF-8472 Digital Diagnostic Function AC/AC Coupling according to MSA Single +3.3 V Power Supply RoHS Compliant -10 to 85oC Operation: SPS-9102MWG -40 to 85oC Operation: SPS-9102AMWG Class 1 Laser International Safety Standard IEC-60825 Compliant The SPS-9102MWG series single mode transceivers is small form factor pluggable module for bi-directional serial optical data communications such as SONET OC-48 / SDH STM-16 (I-16), Gigabit Ethernet 1000BASE-LX and Fibre Channel 1x/2x SM-LC-L FC-PI. It is with the SFP 20-pin connector to allow hot plug capability. Digital diagnostic functions are available via an I2C. This module is designed for single mode fiber and operates at a nominal wavelength of 1310 nm. The transmitter section uses a multiple quantum well laser and is a class 1 laser compliant according to International Safety Standard IEC-60825. The receiver section uses an integrated InGaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC. APPLICATIONS l l l l SONET OC-48 SR / SDH STM-16 I-16 SONET OC-12 / SDH STM-4 SONET OC-3 / SDH STM-1 Gigabit Ethernet / 1X/2X Fibre Channel LASER SAFETY This single mode transceiver is a Class 1 laser product. It complies with IEC-60825 and FDA 21 CFR 1040.10 and 1040.11. The transceiver must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug. Package LC SFP with DMI LC SFP with DMI ORDER INFORMATION P /No. SPS-9102MWG SPS-9102AMWG Bit Rate (Mb/s) Multirate* Multirate* SONET /SDH SR / I-16 SR / I-16 Distance Wavelength (km) (nm) 2 2 1310 1310 Temp. (oC) -10 to 85 -40 to 85 TX Power RX Sens. RoHS (dBm) (dBm) Compliant -3 to -9.5 -3 to -9.5 -18 -18 Yes Yes Multirate*: 2.67 Gb/s / OC-48 / 2X FC / GbE / 1X FC / OC-12 / OC-3 Absolute Maximum Ratings Parameter Storage Temperature Operating Case Temperature Power Supply Voltage Symbol Tstg Topr Vcc Min -40 -10 -40 -0.5 Max 85 85 85 3.6 Units o C o C V Notes SPS-9102MWG SPS-9102AMWG Recommended Operating Conditions Parameter Power Supply Voltage Operating Case Temperature Power Supply Current Data Rate Symbol Vcc Topr ICC (TX+RX) 125 Min 3.1 -10 -40 Typ 3.3 Max 3.5 85 85 300 2670 Units / Notes V o C / SPS-9102MWG o C / SPS-9102AMWG mA Mb/s 200 2488 *********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway Transmitter Specifications (-10 oC < Topr < 85 oC, 3.1V < Vcc < 3.5V) SPS-9102MWG 2 *********************************************************************************************************************************************************************** Parameter Symbol Min Typ Max Units Notes Optical Optical Transmit Power Po -9.5 ---3 dBm 1 Output Center Wavelength 1270 1310 1350 nm λ Output Spectrum Width ----3 nm RMS (σ) ∆λ Extinction Ratio ER 8.2 ----dB Output Eye Compliant with Telecordia GR-253-GORE and ITU-T Recommendation G.957 Optical Rise Time tr 150 ps 20 % to 80% Values Optical Fall Time tf 150 ps 20 % to 80% Values Relative Intensity Noise RIN -120 dB/Hz Electrical Data Input Current – Low IIL -350 µA Data Input Current – High IIH 350 µA Differential Input Voltage VIH - V IL 0.5 2.4 V Peak-to-Peak TX Disable Input Voltage – Low TDIS, L 0 0 .5 V 2 TX Disable Input Voltage – High TDIS, H 2.0 Vcc V 2 TX Disable Assert Time T_off 10 µs TX Disable Negate Time T_on 1 ms TX Fault Output Voltage -- Low TFaultL 0 0 .5 V 3 TX Fault Output Voltage -- High TFaultH 2.0 Vcc+0.3 V 3 1. Output power is power coupled into a 9/125 µm single mode fiber. 2. There is an internal 4.7K to 10K ohm pull-up resistor to VccTX. 3. Open collector compatible, 4.7K to 10K ohm pull-up to Vcc (Host Supply Voltage). Receiver Specifications (-10oC < Topr < 85oC, 3.1V < Vcc < 3.5V) Parameter Symbol Min Typ Max Optical Sensitivity @ OC-48 Sens1 -3 -18 Sensitivity @2X Fibre Channal Sens2 -3 -19 Sensitivity @Gigabit Ethernet Sens3 -3 -20 Sensitivity @OC-12 Sens4 -3 -22 Sensitivity @OC-3 Sens5 -10 -22 Signal Detect -- Asserted Pa ---18 Signal Detect -- Deasserted Pd -33 ----Signal detect -- Hysteresis 1.0 --Wavelength of Operation 1100 --1600 Electrical Differential Output Voltage VOH – VOL 0.6 2.0 Output LOS Voltage -- Low VOL 0 0.5 Output LOS Voltage -- High VOH 2.0 Vcc+0.3 LOS Assert Time T_loss_on 100 LOS Deassert Time T_loss_off 100 4. Measured at 2 23-1 PRBS at BER 1E-10 @ 1300 nm. 5. Measured at 2 7-1 PRBS at BER 1E-12 @1300nm. 6. Open collector compatible, 4.7K to 10K ohm pull-up to Vcc (Host Supply Voltage). Units dBm dBm dBm dBm dBm dBm dBm dB nm V V V µs µs Notes 4 5 5 4 4 Transition: low to high Transition: high to low 6 6 *********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway CONNECTION DIAGRAM SPS-9102MWG 3 *********************************************************************************************************************************************************************** PIN 1 2 3 4 5 6 7 8 9 10 Signal Name TX GND TX Fault TX Disable MOD-DFE2 MOD-DEF1 MOD-DEF0 N/C LOS RX GND RX GND Description Transmitter Ground Transmitter Fault Indication Transmitter Disable (Module disables on high or open) Modulation Definition 2 – Two wires serial ID Interface Modulation Definition 1 – Two wires serial ID Interface Modulation Definition 0 – Ground in Module Not Connected Loss of Signal Receiver Ground Receiver Ground PIN 11 12 13 14 15 16 17 18 19 20 Signal Name Description RX GND Receiver Ground RX DATA OUT- Inverse Receiver Data Out RX DATA OUT+ Receiver Data Out RX GND Vcc RX Vcc TX TX GND TX DATA IN+ TX DATA INTX GND Receiver Ground Receiver Power – 3 .3V±5% Transmitter Power – 3 .3V±5% Transmitter Ground Transmitter Data In Inverse Transmitter Data In Transmitter Ground Module Definition Module Definition 4 MOD-DEF2 PIN 4 SDA MOD-DEF1 PIN 5 SCL MOD-DEF0 PIN 6 LV-TTL Low Interpretation by Host Serial module definition protocol Module Definition 4 specifies a serial definition protocol. For this definition, upon power up, MOD-DEF(1:2) appear as no connector (NC) and MOD-DEF(0) is TTL LOW. When the host system detects this condition, it activates the serial protocol. The protocol uses the 2-wire serial CMOS E 2PROM protocol of the ATMEL AT24C01A/02/04 family of components. *********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway RECOMMENDED CIRCUIT SCHEMATIC VeeT Tx_DISABLE Tx_FAULT (1,17,20) 3 2 4.7K to 10KΩ TD + 18 Z=50Ω TD 19 Z=50Ω VccT 16 10nF 1μH Vcc 3.3V 10μF 10nF 1μH VccR 15 10nF 10μF 10μF TD TD + SPS-9102MWG 4 *********************************************************************************************************************************************************************** Tx_DISABLE Tx_FAULT LD Driver 100Ω SerDes IC Protocol IC RD - 12 Z=50Ω 100Ω RD - POST Amp RD + 13 Z=50Ω 4.7K to 10KΩ RD + depending on SERDES LOSS OF SINGAL LOS VeeR MOD_DEF(0) 8 (9,10,11,14) 6 5 4 4.7K to 10KΩ 4.7K to 10KΩ 4.7K to 10KΩ Vcc 3.3V MODULE DETECT SCL SDA EEPROM MOD_DEF(1) MOD_DEF(2) SFP module PACKAGE DIAGRAM Units in mm Note: Specifications subject to change without notice. *********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0 Optoway Revision History V ersion 1 .0 2 .0 SPS-9102MWG 5 *********************************************************************************************************************************************************************** Subject Initial datasheet Revise package diagram for high port density use Release Date 2005/12/1 2008/1/1 *********************************************************************************************************************************************************************** OPTOWAY TECHNOLOGY INC. No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303 Tel: 886-3-5979798 Fax: 886-3-5979737 E-mail: sales@optoway.com.tw http: // www.optoway.com.tw 1/1/2008 V2.0
