560-12.0M-5DN-TP210

Oscilent Corporation | 560 Series VCXO - Voltage Control Crystal Oscillator Page 1 of 2 VCXO Surface Mount Series Number Package Description Last Modified 560 FEATURES - 2.0mm low profile - Wave form symmetry of 40/60% - SMD Version - 3.3V operation (optional) - Tape and Reel - RoHs / Lead Free compliant 5 x 7 Ceramic SMD HCMOS / TTL Jan. 01 2007 OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS PARAMETERS Output Logic Input Voltage (VDD) Frequency Range (fO) Operating Temperature (TOPR) Storage Temperature (TSTG) Overall Frequency Stability CONDITIONS a+b+c+d (a) Frequency Tolerance (b) Temperature Stability (c) Input Voltage Stability (d) Load Stability Input Current (IDD) Aging Rise Time (TR) / Fall Time (TF) Pin 1 Control Voltage Range Output Voltage High "1" VOH Output Voltage Low "0" VOL Duty Cycle Start-Up Time (TS) Jitter Linearity @ 25°C TTL Load HCMOS Load TTL Load HCMOS Load (One Sigma) 2.7 min. 0.4 max. 0.5 max. 50 ±10 (Std.) / 50 ±5 (Option) 10 max. ±25 max. ±20 (Std.) / ±10 (Option) CHARACTERISTICS HCMOS / TTL Output 3.3 ±10% 1.5440 ~ 52.0 0 ~ +70 (Std.) / -40 ~ 85 (Option) -55 ~ +125 ±20, ±25, ±50, ±100 max. Inclusive of Overall Stability Inclusive of Overall Stability (Operating Temperature) Inclusive of Overall Stability (VDD ±5%) Inclusive of Overall Stability (RL ±5%) 10 ~ 25 max. ±3 max. 10 max. (0.4V to 2.4V / TTL; Waveform / HCMOS) 1.65 ±1.35 2.4 min. VDD-0.5 min. 2.5 ±2 15 ~ 35 max. 5.0 ±10% UNITS VDC MHz °C °C PPM mA PPM/Y nS V VDC VDC % ms ps % PIN CONNECTIONS #1 Control Voltage Oscilent Corporation | 560 Series VCXO - Voltage Control Crystal Oscillator Page 2 of 2 #2 #3 #4 CASE GND OUTPUT VDD PART NUMBER GUIDE Series Number Frequency Voltage Supply Option Frequency Tolerance & Stability (max.) Operating Temp. (°C) Duty Cycle Pulling Range Linearity 560 Oscilent VCXO - 12.0 M -3 D= E= F= G= E ±100 PPM ±50 PPM ±25 PPM ±20 PPM N Blank* = 0~+70 N = -40~+85 -T Blank*= 50±10% T = 50±5% P1 P1 = 50PPM P2 = 100PPM P3 = 150PPM 20 20 = 20% 10 = 10% 05 = 5% Enter your desired 5 = 5VDC frequency e.g. 3 = 3.3VDC 12.0M for 12.000MHz NOTE: - Deviations on all parameters available. Please consult Oscilent for details. DEFINITIONS: - Click on the characteristic names above for definitions of that particular characteristic. *STANDARDS: - "Blank" part number selections indicate standard variables for that particular characteristic. PACKAGING: - Standard tube packaging, add -TR for Tape/Reel. Click here for tape/reel specifications Series No.: 560 Crystal Oscillators | Quartz Crystal | TCXO | VCXO | IF SAW Filter | RF SAW Filter | Ceramic Resonator Crystal Filter | Ceramic Filter | SAW Filter / SAW Devices | Site Map
