745-450-DU

Oscilent Corporation | 745 Series Ceramic Filter Page 1 of 2 Filters Series Number Package Description Last Modified 745 SMD Ceramic Filter 450 KHz Dec. 22 2008 Filter FEATURES - Surface Mount - RoHS Compliant OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS / PART NUMBER GUIDE PART NO. 6dB Bandwidth KHz min. 40dB Bandwidth KHz max. ±30 ±25 ±20 ±15 ±12 ±10 ±9 ±7.5 Pass Band Ripple dB max. 2 2 2 2 2 2 2 2 Spurious Attenuation fn ±100KHz dB min. 27 27 27 27 27 25 25 25 Insertion Loss dB max. 4 4 4 6 6 6 6 6 In/Output Impedance Kohm 1 1 1.5 1.5 1.5 1.5 1.5 1.5 745-450-BU 745-450-CU 745-450-DU 745-450-EU 745-450-FU 745-450-GU 745-450-HU 745-450-IU ±15 ±12.5 ±10 ±7.5 ±6 ±4.5 ±3 ±2 NOTE: Deviations on all parameters available. Please consult Oscilent for details. DEFINITIONS: Click on the characteristic names above, for definitions of the particular characteristic. . Oscilent Corporation | 745 Series Ceramic Filter Page 2 of 2 Oscilent Corporation - CALL 949.252.0522 18195 East McDurmott Street . Building D . Irvine . CA 92614 . USA Fax: 949.252.0599 . E-Mail: Sales@Oscilent.com Series No.: 745 Crystal Oscillators | Quartz Crystal | TCXO | VCXO | IF SAW Filter | RF SAW Filter | Ceramic Resonator Crystal Filter | Ceramic Filter | SAW Filter / SAW Devices | Site Map
