1SS355

1SS355 SURFACE MOUNT SWITCHING DIODE VOLTAGE FEATURES • Small surgace mounting type (SOD-323) .045(1.15) .054(1.35) .078(1.95) .068(1.75) 90 Volts POWER 200 mW SOD-323 Unit: inch (mm) .014(.35) • High reliability with surge current handing capability • In compliance with EU RoHS 2002/95/EC directives .009(.25) • High Speed (TRR=1.2ns Typ) .038(.95) .027(.70) .006(.15) .107(2.7) .090(2.3) MECHANICAL DATA Case: SOD-323 plastic Terminals : Solderable per MIL-STD-750,Method 2026 Polarity : Color band cathode Approx Weight: 0.0041 grams Silicon epitaxial planar .012(.30)MIN. 1 2 Cathode Anode MAXIMUM RATINGS PA RA ME TE R M a xi m um Re c ur r e nt P e a k Re ve rs e Vo lta g e M a xi m um D C Re ve r s e Vo lta g e Ma xi mum P e a k F o r wa r d C ur re nt Me a n Re c ti fyi ng C urr e nt S urg e C ur re nt tp = 1 0 0 0 ms ( 1 s e c ) Op e r a ti ng J unc ti o n a nd S to ra g e Te mp e r a tur e Ra ng e S YMB OL V RM VR IF M IO IF S M T J ,T S TG L IMITS 90 80 225 100 0 .5 -5 5 to + 1 5 0 .002(.05) UNITS V V mA mA A O C ELECTRICAL CHARACTERISTICS PA RA M E TE R F o rwa rd Vo lta g e R e ve r s e C ur r e nt C a p a c i t a n c e B e t w e e n Te r m i n a l s R e v e r s e R e c o v e r y Ti m e S YM B O L VF IR CT T RR M IN . ----- T YP. ----- MA X . 1 .2 0 .1 3 .0 4 .0 U N IT S V μA pF ns C O N D IT O N S IF = 1 0 0 m A V R= 8 0 V V R= 0 V, f = 1 M H Z V R = 6 V , IF = 1 0 m A , R L = 1 0 0 Ω Note : 1.Mounted on min pad conditions using FR-4 PCB REV.0.5-MAR.5.2010 PAGE . 1 1SS355 300 P D , POWER DISSIPATION (mW) 10 TJ =125 OC REVERSE CURRENT, u A 200 1.0 0.1 TJ =75 OC 100 0.01 TJ =25 OC 0 50 100 150 200 AMBIENT TEMPERATURE( C) O 0.001 0 20 40 60 80 100 REVERSE VOLTAGE, Volts FIG. 1 POWER DERATING CURVE FIG. 2-TYPICAL REVERSE CHARACTERISTICS 100 100 IFSM Forward Current, IF, Amperes TJ = 150°C Peak Surge Forward Current (IFSM), A 10 TJ = 25°C TJ = 75°C 10 t 1 1 0.1 0 0.2 0.4 0.6 0.8 Forward Voltage, VF, Volts 1 0.1 0.1 1 10 Pulse width, ms 100 1000 FIG. 3 TYPICAL FORWARD CHARACTERI S TIC FIG.4-SURGE CURRENT REV.0.5-MAR.5.2010 PAGE . 2 1SS355 MOUNTING PAD LAYOUT ORDER INFORMATION • Packing information T/R - 12K per 13" plastic Reel T/R - 5K per 7" plastic Reel LEGAL STATEMENT Copyright PanJit International, Inc 2010 The information presented in this document is believed to be accurate and reliable. The specifications and information herein are subject to change without notice. Pan Jit makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose. Pan Jit products are not authorized for use in life support devices or systems. Pan Jit does not convey any license under its patent rights or rights of others. REV.0.5-MAR.5.2010 PAGE . 3
