BZT52-C6V8FN2 SURFACE MOUNT ZENER DIODE FEATURES • Ultra-Small Leadless Surface Mount Package • Ideally Suited for Automated Assembly Processes • In compliance with EU RoHS 2002/95/EC directives DFN 2L Unit : inch(mm) MECHANICAL DATA Case: DFN 2L, Plastic Polarity : Color band cathode Terminals: Solderable per MIL-STD-750, Method 2026 3 2 0.008(0.22) 2 7 5 4 MAX. PIN NO.1 IDENTIFICATION 1 Cathode 2 Anode M a x im u m R a tin g s @ T A = 2 5 o C u n le s s o th e r w is e s p e c ifie d C ha ra c te ri s ti c S ym b o l Value 0.9 2 47 5 4 Unit V Forward Voltage (Note 1) @I F=10mA VF Thermal Characteristics C ha ra c te ri s ti c S ym b o l Value 250 500 -65 to + 150 Unit mW O Power Dissipation (Note 2) Thermal Resistance, Junciton to Ambient Air (Note 2) Operating and Storage Temperature Range TA=25OC TA=25OC PD RJA TJ,TSTG C/W O C Notes : 1. Short duration pulse test used to minimize self-heating effect 2. Device mounted on FR-4 PCB Electrical Characteristics@TA=25oC unless otherwise specifie Zener Voltage Range (Note 1) Maximum Zener Impedance f=1KHz Maximum Reverse Current(Note 1) Part Number Marking Code Nom. V V Z @I 6.8 6.46 ZT I Ma x. V ZT Z ZT@ I 15 ZT Z ZK @ I  80 ZK I ZK I R VR V Mi n. V I Z (mA ) 5 mA 1.0 A 2.0 BZT52-C6V8FN2 WC 7.14 4.0 PAN JIT RESERVES THE RIGHT TO IMPROVE PRODUCT DESIGN,FUNCTIONS AND RELIABILITY WITHOUT NOTICE REV.0.2-JUL.23.2009 PAGE . 1 BZT52-C6V8FN2 50 40 IZ, ZENER CURRENT (mA) 30 20 10 0 0 3 4 5 6 8 9 10 7 VZ, ZENER VOLTAGE (V) Fig. 1 Typical Zener Breakdown Characteristics 1 2 REV.0.2-JUL.23.2009 PAGE . 2 BZT52-C6V8FN2 MOUNTING PAD LAYOUT DFN 2L 0.017 (0.42) 0.043 (1.10) 0.010 (0.26) 0.028 (0.70) 0.027 (0.68) ORDER INFORMATION • Packing information T/R - 8K per 7" plastic Reel LEGAL STATEMENT Copyright PanJit International, Inc 2009 The information presented in this document is believed to be accurate and reliable. The specifications and information herein are subject to change without notice. Pan Jit makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose. Pan Jit products are not authorized for use in life support devices or systems. Pan Jit does not convey any license under its patent rights or rights of others. REV.0.2-JUL.23.2009 PAGE . 3
