BZX84C3

BZX84-C2V4 SERIES SURFACE MOUNT SILICON ZENER DIODES VOLTAGE 2.4 to 75 Volts POWER 410 mWatts SOT- 23 Unit: inch (mm) FEATURES • Planar Die construction • 410mW Power Dissipation .056(1.40) .119(3.00) .110(2.80) • Zener Voltages from 2.4~75V • Ideally Suited for Automated Assembly Processes • Pb free product : 99% Sn above can meet RoHS environment substance diective request .047(1.20) .007(.20)MIN .103(2.60) .083(2.10) .066(1.70) .006(.15) .002(.05) MECHANICAL DATA .044(1.10) • Case: SOT-23, Molded Plastic • Terminals: Solderable per MIL-STD-750, Method 2026 • Polarity: See Diagram Below • Approx. Weight: 0.008 grams • Mounting Position: Any .006(.15)MAX .020(.50) .013(.35) MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS Parameter Maximum Power Dissipation (Notes A) at 25O C Operating Junction and StorageTemperature Range Symbol Value 410 -50 to +150 .035(0.90) Units mW O PD TJ C NOTES: A. Mounted on 5.0mm2(.013mm thick) land areas. STAD-JAN.13.2006 .086(2.20) PAGE . 1 BZX84-C2V4 SERIES N ominal Zener Voltage Part N umber No m. V Max. Zener Impedance Z ZT @ IZT Z ZK @ IZK Ω mA Max R everse Leakage C urrent IR @ V R uA V V Z @ IZT M i n. V M a x. V Marking C ode W1 W2 W3 W4 W5 W6 W7 W8 W9 WA WB WC WD WE WF WG WH WI WK WJ WL WM 17C WN WO WP WR WS 28C WT WU WW WX WY WZ XA X2 X3 X4 X5 Package Ω mA BZX84C 2V4 BZX84C 2V7 BZX84C 3 BZX84C 3V3 BZX84C 3V6 BZX84C 3V9 BZX84C 4V3 BZX84C 4V7 BZX84C 5V1 BZX84C 5V6 BZX84C 6V2 BZX84C 6V8 BZX84C 7V5 BZX84C 8V2 BZX84C 9V1 BZX84C 10 BZX84C 11 BZX84C 12 BZX84C 13 BZX84C 14 BZX84C 15 BZX84C 16 BZX84C 17 BZX84C 18 BZX84C 20 BZX84C 22 BZX84C 24 BZX84C 27 BZX84C 28 BZX84C 30 BZX84C 33 BZX84C 36 BZX84C 39 BZX84C 43 BZX84C 47 BZX84C 51 BZX84C 56 BZX84C 62 BZX84C 68 BZX84C 75 2.4 2.7 3 3.3 3.6 3.9 4.3 4.7 5.1 5.6 6.2 6.8 7.5 8.2 9.1 10 11 12 13 14 15 16 17 18 20 22 24 27 28 30 33 36 39 43 47 51 56 62 68 75 2.28 2.57 2.85 3.14 3.42 3.71 4.09 4.47 4.85 5.32 5.89 6.46 7.13 7.79 8.65 9.50 10.45 11.40 12.35 13.30 14.25 15.20 16.15 17.10 19.00 20.90 22.80 25.65 26.60 28.50 31.35 34.20 37.05 40.85 44.65 48.45 53.20 58.90 64.60 71.25 2.52 2.84 3.15 3.47 3.78 4.10 4.52 4.94 5.36 5.88 6.51 7.14 7.88 8.61 9.56 10.50 11.55 12.60 13.65 14.70 15.75 16.80 17.85 18.90 21.00 23.10 25.20 28.35 29.40 31.50 34.65 37.80 40.95 45.15 49.35 53.55 58.80 65.10 71.40 78.75 100 100 95 95 90 90 90 80 60 40 10 15 15 15 15 20 20 25 30 30 30 40 40 45 55 55 70 80 80 80 80 90 130 150 170 100 135 150 200 250 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 2.5 2.5 2.5 2.5 600 600 600 600 600 600 600 500 480 400 150 80 80 80 100 150 150 150 170 170 200 200 200 225 225 250 250 300 300 300 325 350 350 375 375 400 1000 1000 1000 1000 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 50 20 10 5.0 5.0 3.0 3.0 3.0 2.0 1.0 3.0 2.0 1.0 0.7 0.5 0.2 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 1.0 1.0 1.0 1.0 1.0 1.0 1.0 2.0 2.0 2.0 4.0 4.0 5.0 5.0 6.0 7.0 8.0 8.0 8.0 10.0 10.5 11.2 12.2 12.6 14.0 15.4 16.8 18.9 20.50 21.00 23.10 25.20 27.30 30.10 32.90 35.70 42.0 46.0 51.0 56.0 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 STAD-JAN.13.2006 PAGE . 2 BZX84-C2V4 SERIES TEMPERATURE COEFFICIENT,(mA/ OC) 100 0.6 POWER DISSIPATION, Watts 0.5 0.4 0.3 T A =25 OC 10 0.2 0.1 0 0 25 50 75 O 100 125 150 1 10 100 TEMPERATURE ( C) NOMINAL ZENER VOLTAGE,VOLTS Fig.1 STEADY STATE POWER DERATING Fig.2 TEMPERATURE COEFFICENTS 1000 1000 LEAKAGE CURRENT,uA 10 1 0.1 0.01 0.001 0.0001 0.00001 0 10 20 30 40 50 60 70 FORWARD CURRENT,mA 100 100 +150 C O +25 C -55 C 80 90 O O 10 150OC O 75 C 25OC 5OC 1 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 NORMAL ZENER VOLTAGE, VOLTS FORWARD VOLTAGE, VOLTS F i g . 3 TYPICAL LEAKAGE CURRENT Fig.4 TYPICAL FORWARD VOLTAGE STAD-JAN.13.2006 PAGE . 3 BZX84-C2V4 SERIES MOUNTING PAD LAYOUT ORDER INFORMATION • Packing information T/R - 12K per 13" plastic Reel T/R - 3K per 7" plastic Reel LEGAL STATEMENT Copyright PanJit International, Inc 2006 The information presented in this document is believed to be accurate and reliable. The specifications and information herein are subject to change without notice. Pan Jit makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose. Pan Jit products are not authorized for use in life support devices or systems. Pan Jit does not convey any license under its patent rights or rights of others. STAD-JAN.13.2006 PAGE . 3
