ER1002FCT

ER1000FCT~ER1006FCT SUPERFAST RECOVERY RECTIFIERS VOLTAGE FEATURES • Plastic package has Underwriters Laboratory Flammability Classification 94V-O. Flame Retardant Epoxy Molding Compound. • Exceeds environmental standards of MIL-S-19500/228 • Low power loss, high efficiency. • Low forwrd voltge, high current capability • High surge capacity. • Super fast recovery times, high voltage. • In compliance with EU RoHS 2002/95/EC directives 50 to 600 Volts CURRENT 10 Amperes MECHANICAL DATA • Case: ITO-220AB Molded plastic • Terminals: Lead solderable per MIL-STD-750, Method 2026 • Polarity: As marked. • Standard packaging: Any • Weight: 0.0655 ounces, 1.859grams. .177(4.5) .137(3.5) .027(.67) .022(.57) MAXIMUM RATING AND ELECTRICAL CHARACTERISTICS Ratings at 25°C ambient temperature unless otherwise specified. Single phase, half wave, 60 Hz, resistive or inductive load. For capacitive load, derate current by 20% PA RA M E TE R M a xi m um Re c urre nt P e a k Re ve rs e Vo lta g e M a xi m um RM S Vo lta g e M a xi m um D C B lo ck i ng Vo lta g e M a xi m um A ve ra g e F o rwa rd C urre nt a t Tc =1 0 0 O C P e a k F o rwa rd S urg e C urre nt, 8 .3 ms si ng le ha lf s i ne -wa ve s up e ri m p o se d o n ra te d lo a d (JE D E C me tho d ) M a xi m um F o rwa rd Vo lta g e a t 5 A , p e r e le me nt M a xi m um D C Re ve rs e C urre nt a t T J =2 5 O C Ra te d D C B lo cki ng Vo lta g e T J =1 0 0 O C M a xi m um Re ve rse Re co ve ry Ti m e (No te 2 ) Typ i ca l Juncti o n c a p a ci ta nce (No te 1 ) Typ i c a l The rm a l Re s i s ta nc e Op e ra ti ng J uncti o n a nd S to ra g e Te m p e ra ture Ra ng e S YMB OL V RRM V RMS V DC IF (AV ) IF S M VF IR t rr CJ R θ JC T J ,T STG E R1 00 0 F C T E R1 0 01 F C T E R1 00 1 A F C T E R10 02 F C T E R1 00 3F C T E R1 00 4F C T E R1 00 6F C T UNITS V V V A A 50 35 50 100 70 100 150 105 150 200 140 200 1 0 .0 150 300 210 300 400 280 400 600 420 600 0 .9 5 1 .0 500 35 62 3 .0 -5 5 to +1 5 0 1 .3 0 1.7 V μA 50 ns pF O C/ W C O NOTES: 1. Measured at 1 MHz and applied reverse voltage of 4.0 VDC. 2. Reverse Recovery Test Conditions: IF=.5A, IR=1A, Irr=.25A. 3. Both Bonding and Chip structure are available. May 5,2010-REV.02 PAGE . 1 ER1000FCT~ER1006FCT RATING AND CHARACTERISTIC CURVES AVERAGE FORWARD CURRENT, AMPERES 8 6 4 LEADLENGHTS RESISTIVEORINDUCTIVE LOAD PEAK FORWARD SURGE CURRENT, 10 150 125 100 75 50 25 0 8.3ms Single Half Since-Wave JEDEC Method 2 0 0 20 40 60 80 100 O 120 140 160 1 2 5 10 20 50 100 CASE TEMPERAURE, C Fig.1- FORWARD CURRENT DERATING CURVE NO. OF CYCLE AT 60HZ Fig.2- MAXIMUM NON - REPETITIVE SURGE CURRENT 40 INSTANTANEOUS REVERSE CURRENT, μA 10 INSTNTANEOUS FORWARD CURRENT AMPERES TJ = 125°C 10 200V 300-400V Per Diode 1 TJ = 75°C 600V 1 TJ = 25°C 0.1 20 30 40 50 60 70 80 90 100 T J =25 C Pulse Width=200us .1 O PERCENT OF RATED PEAK REVERSE VOLTAGE, (%) .6 .8 1.0 1.2 1.4 1.6 1.8 2.0 INSTANTANEOUS FORWARD VOLTAGE ,VOLTS Fig.3- TYPICAL REVERSE CHARACTERISTIC Fig.4- TYPICAL INSTANTANEOUS FORWARD CHARACTERISTIC May 5,2010-REV.02 PAGE . 2
