ER1000FCT~ER1006FCT
SUPERFAST RECOVERY RECTIFIERS
VOLTAGE
50 to 600 Volt
10 Ampere
CURRENT
FEATURES
• Plastic package has Underwriters Laboratory
Flammability Classification 94V-O.
Flame Retardant Epoxy Molding Compound.
• Low power loss, high efficiency.
• Low forward voltge, high current capability
• High surge capacity.
• Super fast recovery times, high voltage.
• Lead free in compliance with EU RoHS 2.0
• Green molding compound as per IEC 61249 standard
MECHANICAL DATA
• Case: ITO-220AB Molded plastic
• Terminals: Lead solderable per MIL-STD-750, Method 2026
• Polarity: As marked.
• Standard packaging: Any
• Weight: 0.056 ounces, 1.6 grams.
MAXIMUM RATING AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified. Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
PA RA ME TE R
S YMB OL
E R1 0 0 0F C T E R1 0 0 1 F C T E R1 0 0 1A F C T E R1 0 0 2 F C T E R1 0 0 3 F C T E R1 0 04 F C T E R1 0 0 6F C T
UNITS
Ma xi mum Rec urre nt P e a k Re ve rs e Volta g e
V RRM
50
1 00
1 50
20 0
3 00
4 00
6 00
V
Ma xi mum R MS Vo lta ge
V RMS
35
70
1 05
1 40
2 10
2 80
4 20
V
Ma xi mum D C B loc ki ng Voltag e
V DC
50
1 00
1 50
20 0
3 00
4 00
6 00
V
Ma xi mum A ve ra ge F o rward C urre nt a t T C = 1 0 0 O C
IF(AV )
10
A
P ea k F orwa rd S urg e C urre nt, 8 .3 ms s i ngle ha lf s i ne -wa ve
s up eri mpo s ed on rate d lo a d
IF S M
150
A
Ma xi mum F orwa rd Vo lta ge a t 5 A , p e r e le ment
VF
Ma xi mum D C Reverse C urre nt a t Ra te d D C B lo ck i ng T J =2 5 O C
T J =1 0 0 O C
Voltag e
IR
1
50 0
μA
Ma xi mum R everse Re co ve ry Ti me ( Note 2 )
t rr
35
ns
Typ i ca l J unc ti o n C a p a c i ta nc e (No te 1 )
CJ
62
pF
R θJ C
3
T J ,T S TG
-5 5 t o +1 50
Typ i ca l Thermal R es i stance
Ope ra ti ng J uncti on a nd S to ra g e Te mpe ra ture Ra ng e
0.9 5
1 .3
1.7
V
O
C /
W
O
C
NOTES
1. Measured at 1 MHz and applied reverse voltage of 4 VDC.
2. Reverse Recovery Test Conditions: I F=0.5A, I R=1A, Irr=0.25A.
3. Both Bonding and Chip structure are available.
June 4,2019-REV.06
PAGE . 1
ER1000FCT~ER1006FCT
10
8
6
4
LEADLENGHTS
RESISTIVEORINDUCTIVE LOAD
2
0
0
20
40
60
80
100
120
140
160
PEAK FORWARD SURGE CURRENT,
AVERAGE FORWARD CURRENT,
AMPERES
RATING AND CHARACTERISTIC CURVES
150
125
8.3ms Single
Half Since-Wave
JEDEC Method
100
75
50
25
0
O
1
2
5
CASE TEMPERAURE, C
10
20
50
100
NO. OF CYCLE AT 60HZ
Fig.2- MAXIMUM NON - REPETITIVE SURGE CURRENT
Fig.1- FORWARD CURRENT DERATING CURVE
10
TJ = 125°C
Per Diode
1
TJ = 75°C
TJ = 25°C
0.1
20
30
40
50
60
70
80
90
100
PERCENT OF RATED PEAK REVERSE
VOLTAGE, (%)
INSTNTANEOUS FORWARD CURRENT
AMPERES
INSTANTANEOUS REVERSE
CURRENT, μA
40
10
300-400V
200V
600V
1
T J =25 OC
Pulse Width=200us
.1
.6
.8
1.0
1.2
1.4
1.6
1.8
2.0
INSTANTANEOUS FORWARD VOLTAGE ,VOLTS
Fig.3- TYPICAL REVERSE CHARACTERISTIC
June 4,2019-REV.06
Fig.4- TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTIC
PAGE . 2
ER1000FCT~ER1006FCT
Part No_packing code_Version
ER1000FCT_T0_00001
For example :
RB500V-40_R2_00001
Serial number
Version code means HF
Part No.
Packing size code means 13"
Packing type means T/R
Packing Code XX
Packing type
Tape and Ammunition Box
(T/B)
Tape and Reel
(T/R)
Bulk Packing
(B/P)
Tube Packing
(T/P)
Tape and Reel (Right Oriented)
(TRR)
Tape and Reel (Left Oriented)
(TRL)
FORMING
June 4,2019-REV.06
Version Code XXXXX
1st Code
Packing size code
A
N/A
0
HF
0
serial number
R
7"
1
RoHS
1
serial number
B
13"
2
T
26mm
X
S
52mm
Y
L
F
PANASERT T/B CATHODE UP
(PBCU)
PANASERT T/B CATHODE DOWN
(PBCD)
2nd Code HF or RoHS 1st Code 2nd~5th Code
U
D
PAGE . 3
ER1000FCT~ER1006FCT
Disclaimer
• Reproducing and modifying information of the document is prohibited without permission
from Panjit International Inc..
• Panjit International Inc. reserves the rights to make changes of the content herein the
document anytime without notification. Please refer to our website for the latest
document.
• Panjit International Inc. disclaims any and all liability arising out of the application or use of
any product including damages incidentally and consequentially occurred.
• Panjit International Inc. does not assume any and all implied warranties, including warranties
of fitness for particular purpose, non-infringement and merchantability.
• Applications shown on the herein document are examples of standard use and operation.
Customers are responsible in comprehending the suitable use in particular applications.
Panjit International Inc. makes no representation or warranty that such applications will be
suitable for the specified use without further testing or modification.
•
The products shown herein are not designed and authorized for equipments requiring high
level of reliability or relating to human life and for any applications concerning life-saving
or life-sustaining, such as medical instruments, transportation equipment, aerospace
machinery et cetera. Customers using or selling these products for use in such applications
do so at their own risk and agree to fully indemnify Panjit International Inc. for any damages
resulting from such improper use or sale.
• Since Panjit uses lot number as the tracking base, please provide the lot number for tracking
when complaining.
June 4,2019-REV.06
PAGE . 4
