MMDT3904_R1_00001

MMDT3904 DUAL NPN GENERAL PURPOSE SWITCHING TRANSISTOR VOLTAGE 40 Volt POWER 225 mWatt FEATURES • NPN epitaxial silicon, planar design • Collector-emitter voltage V CE = 40V • Collector current I C = 200mA • Lead free in compliance with EU RoHS 2011/65/EU directive • Green molding compound as per IEC61249 Std. . (Halogen Free) MECHANICAL DATA • Case: SOT-363, Plastic • Terminals: Solderable per MIL-STD-750, Method 2026 • Approx. Weight: 0.0002 ounces, 0.006 grams • Marking: S1A ABSOLUTE RATINGS PARAMETER SYMBOL VALUE UNITS Collector - Emitter Voltage VCEO 40 V Collector - Base Voltage VCBO 60 V Emitter - Base Voltage VEBO 6.0 V IC 200 mA Collector Current - Continuous THERMAL CHARACTERISTICS PARAMETER SYMBOL VALUE UNITS Max Power Dissipation (Note 1) P TOT 225 mW Thermal Resistance , Junction to Ambient RθJA 625 Junction Temperature TJ -55 to 150 O Storage Temperature TSTG -55 to 150 O O C/W C C Note 1: Transistor mounted on FR-4 board 70 x 60 x 1mm. May 26,2016­REV.03 PAGE . 1 MMDT3904 ELECTRICAL CHARACTERISTICS PA RA M E TE R S YMB OL TE S T C OND ITION MIN. TYP. MA X. UNITS C o lle c to r - E m i tte r B r e a k d o wn Vo lta g e V (B R) C E O I C = 1 .0 m A , I B =0 40 - - V C o lle c to r - B a s e B re a k d o wn Vo lta g e V (B R) C B O I C = 1 0 uA , I E =0 60 - - V E m i tte r - B a s e B re a k d o wn Vo lta g e V (B R)E B O I E = 1 0 uA , I C =0 6 .0 - - V B a s e C uto ff C ur r e nt C o lle c to r C uto ff C urr e nt D C C urr e nt Ga i n (No te 2 ) I I Bl V C E = 3 0 V, V E B =3 .0 V - - 50 nA CEX V C E = 3 0 V, V E B =3 .0 V - - 50 nA 40 70 100 60 30 - 300 - - hFE I I I I I = 0 .1 m A , V C E =1 .0 V = 1 .0 m A , V C E =1 .0 V = 1 0 m A , V C E =1 .0 V C = 5 0 m A , V C E =1 .0 V C = 1 0 0 m A , V C E = 1 .0 V C C C C o lle c to r - E m i tte r S a tur a ti o n Vo lta g e ( No te 2 ) V C E (S AT) I C = 1 0 m A , I B =1 .0 m A I C = 5 0 m A , I B =5 .0 m A - - 0 .2 0 .3 V B a s e - E m i tte r S a tura ti o n Vo lta g e ( No te 2 ) V B E (S AT) I C = 1 0 m A , I B =1 .0 m A I C = 5 0 m A , I B =5 .0 m A 0 .6 5 - - 0 .8 5 0 .9 5 V C o lle c to r - B a s e C a p a c i ta nc e C CBO V C B = 5 V, I E =0 , f= 1 MHz - - 4 .0 pF E m i tte r - B a s e C a p a c i ta nc e C EBO V C B = 0 .5 V, I C = 0 , f= 1 M Hz - - 8 .0 pF D e la y Ti m e td V C C = 3 V,V B E = -0 .5 V, I C = 1 0 m A ,I B =1 .0 m A - - 35 ns Ri s e Ti m e tr V C C = 3 V,V B E = -0 .5 V, I C = 1 0 m A ,I B =1 .0 m A - - 35 ns S to ra g e Ti m e ts V C C = 3 V,I C = 1 0 m A I B 1 = I B 2 = 1 .0 m A - - 200 ns F a ll Ti m e tf V C C = 3 V,I C = 1 0 m A I B 1 = I B 2 = 1 .0 m A - - 50 ns Note 2: Pulse Test: Pulse Width < 300 us, Duty Cycle < 2.0%. May 26,2016­REV.03 PAGE . 2 MMDT3904 ELECTRICAL CHARACTERISTICS CURVE 300 1.400 250 200 1.200 1.000 T J =100 oC 150 o V BE (V) h FE V CE =1V T J =150 oC o T J =25 C 100 T J =100 C 0.800 o T J =25 C 0.600 0.400 50 o T J =150 C 0.200 V CE =1V 0 0.01 0.1 1 10 100 0.000 0.01 1000 0.1 Collector Current, I C (mA) 1 10 100 1000 Collector Current, I C (mA) Fig. 1. Typical h FE vs. Collector Current Fig. 2. Typical VBE vs. Collector Current 1.000 1.0 o T J =25 C o T J =150 C 0.100 V BE (sat) (V) V CE (sat)(mV) I C / I B =10 T J =25 oC T J =100 oC o T J =150 C I C / I B =10 0.010 0.01 0.1 1 10 100 0.1 0.01 1000 0.1 Collector Current, I C (mA) 1.0 10 100 Collector Current, I C (mA) Fig. 3. Typical V CE (sat) vs. Collector Current Fig. 4. Typical V BE(sat) vs Collector Current 10 Capacitance (pF) C IB (EB) o T J =150 C C OB (CB) 1 0.1 1 10 100 Reverse Voltage, V R (V) Fig. 5. Typical Capacitances vs. Reverse Voltage May 26,2016­REV.03 PAGE . 3 MMDT3904 MOUNTING PAD LAYOUT ORDER INFORMATION • Packing information T/R - 10K per 13" plastic Reel T/R - 3K per 7" plastic Reel May 26,2016-REV.03 PAGE . 4 MMDT3904 Part No_packing code_Version MMDT3904_R1_00001 MMDT3904_R2_00001 For example : RB500V-40_R2_00001 Serial number Version code means HF Part No. Packing size code means 13" Packing type means T/R Packing Code XX Packing type Tape and Ammunition Box (T/B) Tape and Reel (T/R) Bulk Packing (B/P) Tube Packing (T/P) Tape and Reel (Right Oriented) (TRR) Tape and Reel (Left Oriented) (TRL) FORMING May 26,2016­REV.03 Version Code XXXXX 1st Code Packing size code A N/A 0 HF 0 serial number R 7" 1 RoHS 1 serial number B 13" 2 T 26mm X S 52mm Y L F PANASERT T/B CATHODE UP (PBCU) PANASERT T/B CATHODE DOWN (PBCD) 2nd Code HF or RoHS 1st Code 2nd~5th Code U D PAGE . 5 MMDT3904 Disclaimer • Reproducing and modifying information of the document is prohibited without permission from Panjit International Inc.. • Panjit International Inc. reserves the rights to make changes of the content herein the document anytime without notification. Please refer to our website for the latest document. • Panjit International Inc. disclaims any and all liability arising out of the application or use of any product including damages incidentally and consequentially occurred. • Panjit International Inc. does not assume any and all implied warranties, including warranties of fitness for particular purpose, non-infringement and merchantability. • Applications shown on the herein document are examples of standard use and operation. Customers are responsible in comprehending the suitable use in particular applications. Panjit International Inc. makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification. • The products shown herein are not designed and authorized for equipments requiring high level of reliability or relating to human life and for any applications concerning life-saving or life-sustaining, such as medical instruments, transportation equipment, aerospace machinery et cetera. Customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Panjit International Inc. for any damages resulting from such improper use or sale. • Since Panjit uses lot number as the tracking base, please provide the lot number for tracking when complaining. May 26,2016­REV.03 PAGE . 6
