SS1040

DATA SHEET SS1040 SURFACE MOUNT SCHOTTKY BARRIER VOLTAGE FEATURES • Fast switching speed • Surface mount package ideally suited for automatic insertion • Electrical identical standard JEDEC. • High conductor • Both normal and Pb free product are available : Normal : 80~95% Sn, 5~20% Pb .008(.20)MAX .053(1.35) .037(0.95) .016(.40)MIN .154(3.90) .141(3.60) .110(2.8) .098(2.5) 40 Volts CURRENT 1.0 Ampers SOD-123 Unit: inch (mm) Pb free: 98.5% Sn above MECHANICAL DATA Case: SOD-123, Plastic Terminals: Solderable per MIL-STD-202, Method 208 Approx. Weight: 0.0104 gram Marking : G5 .005(.12)MAX ABSOLUTE RATINGS PA RA M E TE R R e ve r s e V o l t a g e P e a k R e ve r s e V o l t a g e A v e r a g e R e c t i f i e d C u r r e n t a t Te m p = 7 5 O C N o n- r e p e t i t i ve P e a k F o r w a r d S ur g e C ur r e nt a t t = 8 . 3 m s S ym b o l VR V RRM I Va l ue 40 40 1 .0 30 U ni t s V V A A O IF S M THERMAL CHARACTERISTICS PA RA M E TE R The r m a l R e s i s t a nc e , J unc t i o n t o A m b i e nt J u n c t i o n Te m p e r a t u r e S t o r a g e Te m p e r a t u r e a t Te m p = 2 5 O C S ym b o l R θJ A TJ T I S TG Va l ue 325 125 -5 5 to 1 5 0 U ni t s O .028(0.7) .019(0.5) .071(1.8) .055(1.4) C /W O C C O Note.1 Mounted with minimum recommended pad size, PC Board FR4. STAD-JUN.24.2004 PAGE . 1 ELECTRICAL CHARACTERISTICS PARAMETER Reverse Breakdown Voltage Reverse Current Forward Voltage Diode Capacitance Symbol V(BR) IR VF CT IR=500 uA VR=40 V IF=1.0A VR=0V, f=1.0MHZ Test Condition MIN. 40 ---TYP. ----MAX. -500 0.55 230 Units V uA V pF RATING AND CHARACTERISTIC CURVES AVERAGEFORWARD RECITIFIED CURRENT AMPERES 1.0 1000 CAPACITANCE, (pF) SINGLEPHASEHALFWAVE60Hz RESISTIVEORINDUCTIVELOAD P .C.B MOUNTED ON 0.2 X 0.2"( 5.0 X 5. 0mm) COPPERPADAREAS .75 .50 100 TJ=25 OC .25 0 10 0 25 50 75 100 125 150 175 0 10 20 30 40 LEAD TEMPERAURE, OC VR, REVERSE VOLTAGE (VOLTS) Fig.1- FORWARD CURRENT DERATING CURVE Fig.2- TYPICAL JUNCTION CHARACTERISTIC 10 REVERSE CURRENT, uA 4 10 4 FORWARD CURRENT, mA 10 3 10 2 10 1.0 0.1 0 20 40 125 OC 10 3 125 C 10 2 O 75 OC 75 OC 10 25 OC 0 200 400 600 800 1000 25 OC 60 1.0 REVERSE VOLTAGE, VR(V) FORWARD VOLTAGE, mV Fig.3- TYPICAL REVERSE CHARACTERISTIC Fig.4- TYPICAL FORWARD CHARACTERISTIC STAD-JUN.24.2004 PAGE . 2 MOUNTING PAD LAYOUT SOD-123 Unit: inch ( mm ) .0.059(1.5) 0.094(2.4) 0.059(1.5) ORDER INFORMATION • Packing information T/R - 1 0 K per 13" plastic Reel T/R - 3.0K per 7" plastic Reel LEGAL STATEMENT IMPORTANT NOTICE This information is intended to unambiguously characterize the product in order to facilitate the customer's evaluation of the device in the application. The information will help the customer's technical experts determine that the device is compatible and interchangeable with similar devices made by other vendors. The information in this data sheet is believed to be reliable and accurate. The specifications and information herein are subject to change without notice. New products and improvements in products and product characterization are constantly in process. Therefore, the factory should be consulted for the most recent information and for any special characteristics not described or specified. Copyright Pan Jit International Inc. 2003 All rights reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner. The information presented in this document does not form part of any quotation or contract. The information presented is believed to be accurate and reliable, and may change without notice in advance. No liability will be accepted by the publisher for any consequence of use.Publication thereof does not convey nor imply any license under patent or other industrial or intellectual property rights. STAD-JUN.24.2004 PAGE . 3
