Product Specification PE9702 Product Description Peregrine’s PE9702 is a high-performance integer-N PLL capable of frequency synthesis up to 3000 MHz. The device is designed for superior phase noise performance while providing an order of magnitude reduction in current consumption, when compared with existing commercial space PLLs. The PE9702 features a 10/11 dual modulus prescaler, counters and a phase comparator as shown in Figure 1. Counter values are programmable through either a serial or parallel interface and can also be directly hard wired. The PE9702 is optimized for commercial space applications. Single Event Latch up (SEL) is physically impossible and Single Event Upset (SEU) is better than 10-9 errors per bit / day. It is manufactured on Peregrine’s UltraCMOS™ process, a patented variation of silicon-oninsulator (SOI) technology on a sapphire substrate, offering excellent RF performance and intrinsic radiation tolerance. Figure 1. Block Diagram 3000 MHz UltraCMOS™ Integer-N PLL Rad Hard for Space Applications Features • 3000 MHz operation • ÷10/11 dual modulus prescaler • Internal phase detector • Serial, parallel or hardwired programmable • Ultra-low phase noise • SEU < 10-9 errors / bit-day • 100 Krad (Si) total dose • 44-lead CQFJ Fin Fin Prescaler 10 / 11 Main Counter 13 fp D(7:0) 8 Sdata Pre_en M(6:0) A(3:0) R(3:0) fr Primary 20-bit 20 Latch Secondary 20-bit Latch 20 20 20 16 Phase Detector PD_U PD_D 6 6 fc R Counter Document No. 70-0036-02 │ www.psemi.com ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 1 of 13 PE9702 Product Specification Figure 2. Pin Configurations (Top View) GND GND GND Enh VDD LD R3 R2 R1 R0 fr Figure 3. Package Type 44-lead CQFJ 6 D0, M0 D1, M1 D2, M2 D3, M3 VDD VDD S_W R, D4, M4 Sdata, D5, M5 Sclk, D6, M6 FSELS, D7, Pre_en GND 5 4 3 2 1 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 fc VDD_fc PD_U PD_D VDD Cext VDD Dout VDD_fp fp GND 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 FSELP, A0 E_WR, A1 M2_WR, A2 Smode, A3 Bmode VDD M1_WR A_WR Hop_WR Fin Fin Table 1. Pin Descriptions Pin No. 1 2 3 4 5 6 7 M0 8 D1 M1 9 D2 M2 10 D3 M3 11 12 VDD VDD S_WR 13 D4 M4 Parallel Direct Input Input Direct Parallel Direct Parallel Direct Parallel Direct ALL ALL Serial Input Input Input Input Input Input Input (Note 1) (Note 1) Input M C ounter bit0 (LSB). Parallel data bus bit1. M C ounter bit1. Parallel data bus bit2. M C ounter bit2. Parallel data bus bit3. M C ounter bit3. Same as pin 1. Same as pin 1. Serial load enable input. While S_WR is “low”, Sdata can be serially clocked. Primary register data is transferred to the secondary register on S_WR or Hop_WR rising edge. Parallel data bus bit4 M C ounter bit4 Document No. 70-0036-02 │ UltraCMOS™ RFIC Solutions Pin Name VDD R0 R1 R2 R3 GND D0 Interface Mode ALL Direct Direct Direct Direct ALL Parallel Type (Note 1) Input Input Input Input (Note 1) Input Description Power supply input. Input may range from 2.85 V to 3.15 V. Bypassing recommended. R Counter bit0 (LSB). R Counter bit1. R Counter bit2. R Counter bit3. Ground. Parallel data bus bit0 (LSB). ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 2 of 13 PE9702 Product Specification Table 1. Pin Descriptions (continued) Pin No. Pin Name Sdata 14 D5 M5 Sclk 15 D6 M6 FSELS 16 D7 Pre_en 17 GND FSELP 18 A0 Direct Serial E_WR 19 A1 M2_WR 20 A2 Smode 21 A3 22 23 24 25 26 27 28 29 30 Bmode VDD M1_WR A_WR Hop_WR Fin Fin GND fp Direct ALL ALL Parallel Parallel Serial, Parallel ALL ALL ALL ALL Output Input Input (Note 1) Input Input Input Input Input Direct Serial, Parallel Input Input Parallel Direct Parallel Input Input Input Input Input Interface Mode Serial Parallel Direct Serial Parallel Direct Serial Parallel Direct ALL Parallel Type Input Input Input Input Input Input Input Input Input Description Binary serial data input. Input data entered MSB first. Parallel data bus bit5. M C ounter bit5. Serial clock input. Sdata is clocked serially into the 20-bit primary register (E_WR “low”) or the 8-bit enhancement register (E_WR “high”) on the rising edge of Sclk. Parallel data bus bit6. M C ounter bit6. Selects contents of primary register (FSELS=1) or secondary register (FSELS=0) for programming of internal counters while in Serial Interface Mode. Parallel data bus bit7 (MSB). Prescaler enable, active “low”. When “high”, Fin bypasses the prescaler. Ground. Input Selects contents of primary register (FSELP=1) or secondary register (FSELP=0) for programming of internal counters while in Parallel Interface Mode. A Counter bit0 (LSB). Enhancement register write enable. While E_WR is “high”, Sdata can be serially clocked into the enhancement register on the rising edge of Sclk. Enhancement register write. D[7:0] are latched into the enhancement register on the rising edge of E_WR. A Counter bit1. M2 write. D[3:0] are latched into the primary register (R[5:4], M[8:7]) on the rising edge of M2_WR. A Counter bit2. Selects serial bus interface mode (Bmode=0, Smode=1) or Parallel Interface Mode (Bmode=0, Smode=0). A Counter bit3 (MSB). Selects direct interface mode (Bmode=1). Same as pin 1. M1 write. D[7:0] are latched into the primary register ( Pre_en, M[6:0]) on the rising edge of M1_WR. A write. D[7:0] are latched into the primary register (R[3:0], A[3:0]) on the rising edge of A_WR. Hop write. The contents of the primary register are latched into the secondary register on the rising edge of Hop_WR. Prescaler input from the VCO. 3.0 GHz max frequency. Prescaler complementary input. A bypass capacitor in series with a 51 Ω resistor should be placed as close as possible to this pin and be connected directly to the ground plane. Ground. Monitor pin for main divider output. Switching activity can be disabled through enhancement register programming or by floating or grounding VDD pin 31. Document No. 70-0036-02 │ www.psemi.com ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 3 of 13 PE9702 Product Specification Table 1. Pin Descriptions (continued) Pin No. 31 32 33 Pin Name VDD-fp Dout VDD Interface Mode ALL Serial, Parallel ALL Type (Note 1) Output (Note 1) Description VDD for fp. Can be left floating or connected to GND to disable the fp output. Data Out. The MSEL signal and the raw prescaler output are available on Dout through enhancement register programming. Same as pin 1. Logical “NAND” of PD_U and PD_D terminated through an on chip, 2 kΩ series resistor. Connecting Cext to an external capacitor will low pass filter the input to the inverting amplifier used for driving LD. Same as pin 1. PD_D is pulse down when fp leads fc. PD_U is pulse down when fc leads fp. 34 Cext ALL Output 35 36 37 38 39 40 41 42 43 44 Note 1: Note 2: VDD PD_D PD_U VDD-fc fc GND GND fr LD Enh ALL ALL ALL ALL ALL ALL ALL ALL ALL Serial, Parallel (Note 1) Output (Note 1) Output VDD for fc. Can be left floating or connected to GND to disable the fc output. Monitor pin for reference divider output. Switching activity can be disabled through enhancement register programming or by floating or grounding VDD pin 38. Ground. Ground. Input Output, OD Input Reference frequency input. Lock detect and open drain logical inversion of CEXT. When the loop is in lock, LD is high impedance, otherwise LD is a logic low (“0”). Enhancement mode. When asserted low (“0”), enhancement register bits are functional. VDD pins 1, 11, 12, 23, 31, 33, 35, and 38 are connected by diodes and must be supplied with the same positive voltage level. VDD pins 31 and 38 are used to enable test modes and should be left floating. All digital input pins have 70 kΩ pull-down resistors to ground. ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 4 of 13 Document No. 70-0036-02 │ UltraCMOS™ RFIC Solutions PE9702 Product Specification Table 2. Absolute Maximum Ratings Symbol VDD VI II IO Tstg Table 4. ESD Ratings Units V V mA mA °C Parameter/Conditions Supply voltage Voltage on any input DC into any input DC into any output Storage temperature range Min -0.3 -0.3 -10 -10 -65 Max 4.0 VDD + 0.3 +10 +10 150 Symbol VESD Note 1: Parameter/Conditions ESD voltage (Human Body Model) – Note 1 Level 1000 Units V Periodically sampled, not 100% tested. Tested per MILSTD-883, M3015 C2 Electrostatic Discharge (ESD) Precautions When handling this UltraCMOS™ device, observe the same precautions that you would use with other ESD-sensitive devices. Although this device contains circuitry to protect it from damage due to ESD, precautions should be taken to avoid exceeding the specified rating in Table 4. Latch-Up Avoidance Unlike conventional CMOS devices, UltraCMOS™ devices are immune to latch-up. Table 3. Operating Ratings Symbol VDD TA Parameter/Conditions Supply voltage Operating ambient temperature range Min 2.85 -40 Max 3.15 85 Units V °C Table 5. DC Characteristics: VDD = 3.0 V, -40° C < TA < 85° C, unless otherwise specified Symbol IDD Parameter Operational supply current; Prescaler disabled Prescaler enabled Conditions VDD = 2.85 to 3.15 V Min Typ 10 24 Max Units mA mA 31 Digital Inputs: All except fr, Fin, Fin VIH VIL IIH IIL High level input voltage Low level input voltage High level input current Low level input current VDD = 2.85 to 3.15 V VDD = 2.85 to 3.15 V VIH = VDD = 3.15 V VIL = 0, VDD = 3.15 V -1 0.7 x VDD 0.3 x VDD +70 V V µA µA Reference Divider input: fr IIHR IILR R0 Input: R0 IIHR IILR High level input current Low level input current VIH = VDD = 3.15 V VIL = 0, VDD = 3.15 V -5 +70 µA µA High level input current Low level input current VIH = VDD = 3.15 V VIL = 0, VDD = 3.15 V -100 +100 µA µA Counter and phase detector outputs: fc, fp. VOLD VOHD Output voltage LOW Output voltage HIGH Iout = 6 mA Iout = - 3 mA VDD - 0.4 0.4 V V Lock detect outputs: Cext, LD VOLC VOHC VOLLD Output voltage LOW, Cext Output voltage HIGH, Cext Output voltage LOW, LD Iout = 100 µA Iout = - 100 µA Iout = 6 mA VDD - 0.4 0.4 0.4 V V V Document No. 70-0036-02 │ www.psemi.com ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 5 of 13 PE9702 Product Specification Table 6. AC Characteristics: VDD = 3.0 V, -40° C < TA < 85° C, unless otherwise specified Symbol Parameter Conditions Min Max Units Control Interface and Latches (see Figures 4, 5, 6) fClk tClkH tClkL tDSU tDHLD tPW tCWR tCE tWRC tEC tMDO Serial data clock frequency Serial clock HIGH time Serial clock LOW time Sdata set-up time after Sclk rising edge, D[7:0] set-up time to M1_WR, M2_WR, A_WR, E_WR rising edge Sdata hold time after Sclk rising edge, D[7:0] hold time to M1_WR, M2_WR, A_WR, E_WR rising edge S_WR, M1_WR, M2_WR, A_WR, E_WR pulse width Sclk rising edge to S_WR rising edge. S_WR, M1_WR, M2_WR, A_WR falling edge to Hop_WR rising edge Sclk falling edge to E_WR transition S_WR falling edge to Sclk rising edge. Hop_WR falling edge to S_WR, M1_WR, M2_WR, A_WR rising edge E_WR transition to Sclk rising edge MSEL data out delay after Fin rising edge CL = 12 pf (Note 1) 30 30 10 10 30 30 30 30 30 8 10 MHz ns ns ns ns ns ns ns ns ns ns Main Divider (Including Prescaler) Fin PFin Operating frequency Input level range External AC coupling 500 -5 3000 5 MHz dBm Main Divider (Prescaler Bypassed) Fin PFin Operating frequency Input level range External AC coupling 50 -5 300 5 MHz dBm Reference Divider fr Pfr Phase Detector fc Note 1: Note 2: Note 3: Comparison frequency (Note 3) 20 MHz Operating frequency Reference input power (Note 2) (Note 3) Single-ended input -2 100 MHz dBm Fclk is verified during the functional pattern test. Serial programming sections of the functional pattern are clocked at 10 MHz to verify Fclk specification. CMOS logic levels can be used to drive reference input if DC coupled. Voltage input needs to be a minimum of 0.5Vp-p. Parameter is guaranteed through characterization only and is not tested. ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 6 of 13 Document No. 70-0036-02 │ UltraCMOS™ RFIC Solutions PE9702 Product Specification Functional Description The PE9702 consists of a prescaler, counters, a phase detector, and control logic. The dual modulus prescaler divides the VCO frequency by either 10 or 11, depending on the value of the modulus select. Counters “R” and “M” divide the reference and prescaler output, respectively, by integer values stored in a 20-bit register. An additional counter (“A”) is used in the modulus select logic. The phase-frequency detector generates up and down frequency control signals. The control logic includes a selectable chip interface. Data can be written via serial bus, parallel bus, or hardwired directly to the pins. There are also various operational and test modes and a lock detect output. Figure 4. Functional Block Diagram fr R C ounter (6-bit) fc D(7:0) Sdata Control Pins C ontrol Logic R(5:0) M(8:0) A(3:0) Phase Detector PD_U PD_D LD Cext Modulus Select Fin Fin 10/11 Prescaler M C ounter (9-bit) fp Document No. 70-0036-02 │ www.psemi.com ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 7 of 13 PE9702 Product Specification Main Counter Chain Normal Operating Mode The main counter chain divides the RF input frequency, Fin, by an integer derived from the user-defined values in the “M” and “A” counters. It is composed of the 10/11 dual modulus prescaler, modulus select logic, and 9-bit M counter. Setting Pre_en “low” enables the 10/11 prescaler. Setting Pre_en “high” allows Fin to bypass the prescaler and powers down the prescaler. The output from the main counter chain, fp, is related to the VCO frequency, Fin, by the following equation: fp = Fin / [10 x (M + 1) + A] where A ≤ M + 1, 1 ≤ M ≤ 511 (1) Reference Counter The reference counter chain divides the reference frequency, fr, down to the phase detector comparison frequency, fc. The output frequency of the 6-bit R Counter is related to the reference frequency by the following equation: fc = fr / (R + 1) where 0 ≤ R ≤ 63 (4) Note that programming R with “0” will pass the reference frequency, fr, directly to the phase detector. In Direct Interface Mode, R Counter inputs R4 and R5 are internally forced low (“0”). In this mode, the R value is limited to 0 ≤ R ≤ 15. Register Programming Parallel Interface Mode Parallel Interface Mode is selected by setting the Bmode input “low” and the Smode input “low”. Parallel input data, D[7:0], are latched in a parallel fashion into one of three 8-bit primary register sections on the rising edge of M1_WR, M2_WR, or A_WR per the mapping shown in Table 7 on page 9. The contents of the primary register are transferred into a secondary register on the rising edge of Hop_WR according to the timing diagram shown in Figure 6. Data is transferred to the counters as shown in Table 7 on page 9. The secondary register acts as a buffer to allow rapid changes to the VCO frequency. This double buffering for “ping-pong” counter control is programmed via the FSELP input. When FSELP is “high”, the primary register contents set the counter inputs. When FSELP is “low”, the secondary register contents are utilized. Parallel input data, D[7:0], are latched into the enhancement register on the rising edge of E_WR according to the timing diagram shown in Figure 5. This data provides control bits as shown in Table 8 on page 9 with bit functionality enabled by asserting the Enh input “low”. When the loop is locked, Fin is related to the reference frequency, fr, by the following equation: Fin = [10 x (M + 1) + A] x (fr / (R+1)) where A ≤ M + 1, 1 ≤ M ≤ 511 (2) A consequence of the upper limit on A is that Fin must be greater than or equal to 90 x (fr / (R+1)) to obtain contiguous channels. Programming the M Counter with the minimum value of “1” will result in a minimum M Counter divide ratio of “2”. In Direct Interface Mode, main counter inputs M7 and M8 are internally forced low. In this mode, the M value is limited to 1 ≤ M ≤ 127. Prescaler Bypass Mode Setting Pre_en “high” allows Fin to bypass and power down the prescaler. In this mode, the 10/11 prescaler and A register are not active, and the input VCO frequency is divided by the M counter directly. The following equation relates Fin to the reference frequency, fr: Fin = (M + 1) x (fr / (R+1)) ) where 1 ≤ M ≤ 511 (3) In Direct Interface Mode, main counter inputs M7 and M8 are internally forced low. In this mode, the M value is limited to 1 ≤ M ≤ 127. ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 8 of 13 Document No. 70-0036-02 │ UltraCMOS™ RFIC Solutions PE9702 Product Specification Serial Interface Mode Serial Interface Mode is selected by setting the Bmode input “low” and the Smode input “high”. While the E_WR input is “low” and the S_WR input is “low”, serial input data (Sdata input), B0 to B19, is clocked serially into the primary register on the rising edge of Sclk, MSB (B0) first. The contents from the primary register are transferred into the secondary register on the rising edge of either S_WR or Hop_WR according to the timing diagram shown in Figure 6. Data is transferred to the counters as shown in Table 7. The double buffering provided by the primary and secondary registers allows for “ping-pong” counter control using the FSELS input. When FSELS is “high”, the primary register contents set the counter inputs. When FSELS is “low”, the secondary register contents are utilized. While the E_WR input is “high” and the S_WR input is “low”, serial input data (Sdata input), B0 to Table 7. Primary Register Programming Interface Mode Parallel Enh 1 Bmode 0 Smode 0 R5 R4 M8 M7 Pre_en M6 M5 M4 B7, is clocked serially into the enhancement register on the rising edge of Sclk, MSB (B0) first. The enhancement register is double buffered to prevent inadvertent control changes during serial loading, with buffer capture of the serially-entered data performed on the falling edge of E_WR according to the timing diagram shown in Figure 5. After the falling edge of E_WR, the data provides control bits as shown in Table 8 with bit functionality enabled by asserting the Enh input “low”. Direct Interface Mode Direct Interface Mode is selected by setting the Bmode input “high”. Counter control bits are set directly at the pins as shown in Table 7. In Direct Interface Mode, main counter inputs M7 and M8, and R Counter inputs R4 and R5 are internally forced low (“0”). M3 M2 M1 M0 R3 R2 R1 R0 A3 A2 A1 A0 M2_WR rising edge load D3 B0 D2 B1 D1 B2 D0 B3 D7 B4 Pre_en D6 B5 M1_WR rising edge load D5 B6 D4 B7 D3 B8 D2 B9 D1 B10 D0 B11 D7 B12 D6 B13 A_WR rising edge load D5 B14 D4 B15 D3 B16 D2 B17 D1 B18 D0 B19 Serial* 1 0 1 Direct 1 1 X 0 0 0 0 M6 M5 M4 M3 M2 M1 M0 R3 R2 R1 R0 A3 A2 A1 A0 *Serial data clocked serially on Sclk rising edge while E_WR “low” and captured in secondary register on S_WR rising edge. MSB (first in) (last in) LSB Table 8. Enhancement Register Programming Interface Mode Parallel Enh Bmode Smode Reserved Reserved Reserved Power down Counter load MSEL output Prescaler output fc, fp OE E_WR rising edge load 0 0 0 D7 B0 D6 B1 D5 B2 D4 B3 D3 B4 D2 B5 D1 B6 D0 B7 Serial* 0 0 1 *Serial data clocked serially on Sclk rising edge while E_WR “high” and captured in the double buffer on E_WR falling edge. MSB (first in) (last in) LSB Document No. 70-0036-02 │ www.psemi.com ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 9 of 13 PE9702 Product Specification Figure 5. Parallel Interface Mode Timing Diagram tDSU tDHLD D [7 : 0] tPW tCWR tWRC M1_WR M2_WR A_WR E_WR tPW Hop_WR Figure 6. Serial Interface Mode Timing Diagram Sdata E_WR tEC tCE Sclk S_WR tDSU tDHLD tClkH tClkL tCWR tPW tWRC ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 10 of 13 Document No. 70-0036-02 │ UltraCMOS™ RFIC Solutions PE9702 Product Specification Enhancement Register The functions of the enhancement register bits are shown below with all bits active “high”. Table 9. Enhancement Register Bit Functionality Bit Function Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Reserved** Reserved** Reserved** Power down Counter load MSEL output Prescaler output fp, fc O E Power down of all functions except programming interface. Immediate and continuous load of counter programming as directed by the Bmode and Smode inputs. Drives the internal dual modulus prescaler modulus select (MSEL) onto the Dout output. Drives the raw internal prescaler output (fmain) onto the Dout output. fp, fc outputs disabled. Description ** Program to 0 Phase Detector The phase detector is triggered by rising edges from the main Counter (fp) and the reference counter (fc). It has two outputs, namely PD_U, and PD_D. If the divided VCO leads the divided reference in phase or frequency (fp leads fc), PD_D pulses “low”. If the divided reference leads the divided VCO in phase or frequency (fr leads fp), PD_U pulses “low”. The width of either pulse is directly proportional to phase offset between the two input signals, fp and fc. The phase detector gain is 430 mV / radian. PD_U and PD_D are designed to drive an active loop filter which controls the VCO tune voltage. PD_U pulses result in an increase in VCO frequency and PD_D results in a decrease in VCO frequency. A lock detect output, LD is also provided, via the pin Cext. Cext is the logical “NAND” of PD_U and PD_D waveforms, which is driven through a series 2k ohm resistor. Connecting Cext to an external shunt capacitor provides integration. Cext also drives the input of an internal inverting comparator with an open drain output. Thus LD is an “AND” function of PD_U and PD_D. See Figure 4 for a schematic of this circuit. Document No. 70-0036-02 │ www.psemi.com ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 11 of 13 PE9702 Product Specification Figure 7. Package Drawing 44-lead CQFJ All dimensions are in mils Table 10. Ordering Information Order Code 9702-01 9702-11 9702-00 Part Marking PE9702 ES PE9702 PE9702 EK Description Engineering Samples Flight Units Evaluation Kit Package 44-pin CQFJ 44-pin CQFJ Shipping Method 40 units / Tray 40 units / Tray 1 / Box ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 12 of 13 Document No. 70-0036-02 │ UltraCMOS™ RFIC Solutions PE9702 Product Specification Sales Offices The Americas Peregrine Semiconductor Corporation 9450 Carroll Park Drive San Diego, CA 92121 Tel: 858-731-9400 Fax: 858-731-9499 North Asia Pacific Peregrine Semiconductor K.K. Teikoku Hotel Tower 10B-6 1-1-1 Uchisaiwai-cho, Chiyoda-ku Tokyo 100-0011 Japan Tel: +81-3-3502-5211 Fax: +81-3-3502-5213 Europe Peregrine Semiconductor Europe Bâtiment Maine 13-15 rue des Quatre Vents F-92380 Garches, France Tel: +33-1-47-41-91-73 Fax : +33-1-47-41-91-73 Peregrine Semiconductor, Korea #B-2402, Kolon Tripolis, #210 Geumgok-dong, Bundang-gu, Seongnam-si Gyeonggi-do, 463-480 S. Korea Tel: +82-31-728-4300 Fax: +82-31-728-4305 South Asia Pacific Peregrine Semiconductor, China Shanghai, 200040, P.R. China Tel: +86-21-5836-8276 Fax: +86-21-5836-7652 Space and Defense Products Americas: Tel: 858-731-9453 Europe, Asia Pacific: 180 Rue Jean de Guiramand 13852 Aix-En-Provence Cedex 3, France Tel: +33(0) 4 4239 3361 Fax: +33(0) 4 4239 7227 For a list of representatives in your area, please refer to our Web site at: www.psemi.com Data Sheet Identification Advance Information The product is in a formative or design stage. The data sheet contains design target specifications for product development. Specifications and features may change in any manner without notice. The information in this data sheet is believed to be reliable. However, Peregrine assumes no liability for the use of this information. Use shall be entirely at the user’s own risk. No patent rights or licenses to any circuits described in this data sheet are implied or granted to any third party. Peregrine’s products are not designed or intended for use in devices or systems intended for surgical implant, or in other applications intended to support or sustain life, or in any application in which the failure of the Peregrine product could create a situation in which personal injury or death might occur. Peregrine assumes no liability for damages, including consequential or incidental damages, arising out of the use of its products in such applications. The Peregrine name, logo, and UTSi are registered trademarks and UltraCMOS and HaRP are trademarks of Peregrine Semiconductor Corp. Preliminary Specification The data sheet contains preliminary data. Additional data may be added at a later date. Peregrine reserves the right to change specifications at any time without notice in order to supply the best possible product. Product Specification The data sheet contains final data. In the event Peregrine decides to change the specifications, Peregrine will notify customers of the intended changes by issuing a DCN (Document Change Notice). Document No. 70-0036-02 │ www.psemi.com ©2003-2006 Peregrine Semiconductor Corp. All rights reserved. Page 13 of 13
