PSA-15-201

15W Universal Input PSA-15-201 Dual Output Adaptor ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○ ® UL Features • Compact Mini Size • CISPR 22B; FCC B EMI Applications • CD ROM Drives • Portable Equipment Safety Approvals • UL1950 [E127643] • CSA 22.2 234 [LR56927] • Non-vented/Spill-proof Case • ISO 9001 Quality System • Add-on Disk Drives • Networking • TUV IEC 950, EN60950 [S9552716] • Japan 91-55071 Mechanical Characteristics Dimensions: • Length: 112mm (4.4in) • Width: 60mm (2.36in) Output Specifications Model DC Output Voltage Min. Load Max. PK(2) • Height: 36mm (1.47in) • Weight: 260gm (9oz) Ripple (1) P-P (Max) Regulation Line Load PSA-15-201 5V 12V 0.4A 1A 1.5A 0.05A 0.75A 1.5A 50mV 120mV +1% +1% +5% -5%, +8% (1) Measured at 15W by using a 12 inch twisted pair terminated with a 10mfd capacitor and a 0.1mfd ceramic in parallel. (2) Peak output power not to exceed 23W. PHIHONG PSA-15-201 Dual Output Adaptor Characteristics AC Input Voltage 90 to 264 VAC AC Input Frequency 47 to 63Hz AC Input Current 0.3Arms (120VAC) 0.2Arms (240VAC) AC Inrush Current (Cold) 25A max. (120VAC) 50A max. (240VAC) Leakage Current Less than 3.5mA (240VAC) Efficiency 70% @ 15W 120VAC, 60Hz Hold-up Time 16msec, 15W load, 120VAC Switching Frequency 50KHz (nominal) Overvoltage Protection >120% Operation Temperature (Convection) -0 to 50°C Storage Temperature -25 to +75°C 20 to 90% RH (Non-condensing) MTBF 100,000 hrs. minimum (full load, 240VAC, 25°C) Emissions FCC Class B EN 50081-1: EN 55022 B Immunity EN 50082-1:IEC 801-2 Level 3 IEC 801-3 Level 2 IEC 801-4 Level 2 AC Input Connector IEC 320/13 DC Output Connector Mini-DIN, 5pin Pin 1 - +12 Pins 2,3 - +5 Pins 4,5 - Return Shield - Return ENTERPRISE CO., LTD. 16, Lane 530, Chung Cheng N. Rd. Sanchung City, Taipei Taiwan 24103, R.O.C. Phone: 886-2-988-2126 886-2-980-5255 Fax: 886-2-981-7086 886-2-983-3222 Dimension Diagram Unit: mm (inch) PHIHONG USA Western Office: 48607 Warm Springs Blvd. Fremont, CA 94539 Phone: (510) 445-0100 Fax: (510) 445-1678 Email: usasales@phihongusa.com Internet: http://www.phihongusa.com Eastern Office: 15-201/605 3005 Brodhead Road Bethlehem, PA 18017 Phone: (610) 866-9911 Fax: (610) 866-9920 ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○ ISO 9001 • BABT Facility Approvals 15W Universal Input Overcurrent Protection >110%, Auto Restart
