PSA-18-120

18W Plug-In Adaptor Series PSA-18 Double Insulated Switching Adaptor ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○ ® NRTL/C Features • Compact size • Light weight Applications • Portable electronics • Small computers, PDA’s Safety Approvals • UL 1310 Class II • Reliable design • Short circuit proof • Compact peripheral devices • Business machines • CSA 22.2 223 Class II • Height: 28mm (1.1in) • Weight: 141.75gm (5oz) Ripple (1) Max. P-P Regulation (2) Line Load Mechanical Characteristics Dimensions: • Length: 88mm (3.46in) • Width: 58mm (2.28in) Output Specifications Model DC Output Voltage Min. Load PSA-18-050 PSA-18-120 5.1V 12V 0A 0A 2.5A 1.5A 50mV 120mV +1% +1% +5% +5% (1) Measured by using a 12 inch twisted pair terminated with a 10µF capacitor and 0.1µF ceramic capacitor in parallel. (2) With one meter (39 in.) 18 AWG cord attached, output will be at the nominal voltage with a total regulation of +5%. PHIHONG PSA-18 Double Insulated Switching Adaptor Characteristics AC Input Voltage 90VAC-132VAC AC Frequency 47 to 63Hz AC Input Current 0.5A at 115VAC AC Leakage Current 0.5mA (max.) AC Inrush Current (Cold) 40A at 110VAC, 25˚C Efficiency 70-75% typical at full load Hold-up Time 16msec. at full load, 115VAC Overcurrent Protection Short circuit protected Operation Temperature 0 to 40˚C Storage Temperature -40 to +85˚C MTBF Calculated Greater than 150,000 hours, full load, 25˚C (MIL-HDBK-217) EMI FCC Class B AC Connector Flat blade, unpolarized DC Connector (2.1mm) Center positive; shell is return. ENTERPRISE CO., LTD. 16, Lane 530, Chung Cheng N. Rd. Sanchung City, Taipei Taiwan 24103, R.O.C. Phone: 886-2-988-2126 886-2-980-5255 Fax: 886-2-981-7086 886-2-983-3222 Dimension Diagram Unit: mm (inch) PHIHONG USA U.S. Headquaters: 48607 Warm Springs Blvd. Fremont, CA 94539 Phone: (510) 445-0100 Fax: (510) 445-1678 Email: usasales@phihongusa.com Internet: http://www.phihongusa.com Eastern Office: 3005 Brodhead Road Bethlehem, PA 18017 Phone: (610) 866-9911 Fax: (610) 866-9920 Southwestern Office: 3325 Cochran St., Suite 200 Simi Valley, CA 93063 Phone: (805) 520-8177 Fax: (805) 520-3907 18/703 ○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○ ISO 9001 • BABT Facility Approvals 18W Plug-In Adaptor Series Switching Frequency 50KHz, typical
