BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes Rev. 07 — 12 May 2006 Product data sheet 1. Product profile 1.1 General description General-purpose Schottky diodes in small Surface-Mounted Device (SMD) plastic packages. Table 1. Product overview Package Philips 1PS70SB40 1PS76SB40 1PS79SB40 BAS40 BAS40H BAS40L BAS40W 1PS70SB44 BAS40-04 BAS40-04W 1PS70SB45 1PS75SB45 BAS40-05 BAS40-05W 1PS70SB46 BAS40-06 BAS40-06W BAS40-07 BAS40-07V BAS40-05V 1PS88SB48 BAS40XY SOT323 SOD323 SOD523 SOT23 SOD123F SOD882 SOT323 SOT323 SOT23 SOT323 SOT323 SOT416 SOT23 SOT323 SOT323 SOT23 SOT323 SOT143B SOT666 SOT666 SOT363 SOT363 JEITA SC-70 SC-76 SC-79 SC-70 SC-70 SC-70 SC-70 SC-75 SC-70 SC-70 SC-70 SC-88 SC-88 single diode single diode single diode single diode single diode single diode single diode dual series dual series dual series dual common cathode dual common cathode dual common cathode dual common cathode dual common anode dual common anode dual common anode dual isolated dual isolated quadruple common cathode/ common cathode quadruple common cathode/ common cathode quadruple; 2 series Configuration Type number Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 1.2 Features I High switching speed I High breakdown voltage I Low leakage current I Low capacitance 1.3 Applications I Ultra high-speed switching I Voltage clamping 1.4 Quick reference data Table 2. Symbol Per diode IF VF VR [1] Quick reference data Parameter forward current forward voltage reverse voltage IF = 1 mA [1] Conditions Min - Typ - Max 120 380 40 Unit mA mV V Pulse test: tp ≤ 300 µs; δ ≤ 0.02. 2. Pinning information Table 3. Pin 1 2 Pinning Description cathode anode [1] Simplified outline Symbol BAS40H; 1PS76SB40; 1PS79SB40 1 1 001aab540 2 sym001 2 BAS40L 1 2 cathode anode [1] 1 1 2 2 sym001 Transparent top view BAS40; BAS40W; 1PS70SB40 1 2 3 anode not connected cathode 1 2 006aaa144 3 1 3 2 n.c. 006aaa436 BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 2 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes Pinning …continued Description anode (diode 1) cathode (diode 2) cathode (diode 1), anode (diode 2) 1 2 006aaa144 Table 3. Pin 1 2 3 Simplified outline Symbol BAS40-04; BAS40-04W; 1PS70SB44 3 1 3 2 006aaa437 BAS40-05; BAS40-05W; 1PS70SB45; 1PS75SB45 1 2 3 anode (diode 1) anode (diode 2) cathode (diode 1), cathode (diode 2) 1 2 006aaa144 3 1 3 2 006aaa438 BAS40-06; BAS40-06W; 1PS70SB46 1 2 3 cathode (diode 1) cathode (diode 2) anode (diode 1), anode (diode 2) 1 2 006aaa144 3 1 3 2 006aaa439 BAS40-07 1 2 3 4 cathode (diode 1) cathode (diode 2) anode (diode 2) anode (diode 1) 1 2 1 2 006aaa434 4 3 4 3 BAS40-07V 1 2 3 4 5 6 anode (diode 1) not connected cathode (diode 2) anode (diode 2) not connected cathode (diode 1) 1 2 3 1 2 3 006aaa440 6 5 4 6 5 4 BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 3 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes Pinning …continued Description anode (diode 1) anode (diode 2) cathode (diode 3), cathode (diode 4) anode (diode 3) anode (diode 4) cathode (diode 1), cathode (diode 2) anode (diode 1) cathode (diode 2) anode (diode 3), cathode (diode 4) anode (diode 4) cathode (diode 3) cathode (diode 1), anode (diode 2) 1 2 3 006aaa256 Table 3. Pin 1 2 3 4 5 6 BAS40XY 1 2 3 4 5 6 Simplified outline Symbol BAS40-05V; 1PS88SB48 6 5 4 6 5 4 1 2 3 001aab555 1 2 3 006aaa446 6 5 4 6 5 4 1 2 3 [1] The marking bar indicates the cathode. BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 4 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 3. Ordering information Table 4. Ordering information Package Name 1PS70SB40 1PS76SB40 1PS79SB40 BAS40 BAS40H BAS40L BAS40W 1PS70SB44 BAS40-04 BAS40-04W 1PS70SB45 1PS75SB45 BAS40-05 BAS40-05W 1PS70SB46 BAS40-06 BAS40-06W BAS40-07 BAS40-07V BAS40-05V 1PS88SB48 BAS40XY SC-70 SC-76 SC-79 SC-70 SC-70 SC-70 SC-70 SC-75 SC-70 SC-70 SC-70 SC-88 SC-88 Description plastic surface-mounted package; 3 leads plastic surface-mounted package; 2 leads plastic surface-mounted package; 2 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 2 leads leadless ultra small plastic package; 2 terminals; body 1.0 × 0.6 × 0.5 mm plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 3 leads plastic surface-mounted package; 4 leads plastic surface-mounted package; 6 leads plastic surface-mounted package; 6 leads plastic surface-mounted package; 6 leads plastic surface-mounted package; 6 leads Version SOT323 SOD323 SOD523 SOT23 SOD123F SOD882 SOT323 SOT323 SOT23 SOT323 SOT323 SOT416 SOT23 SOT323 SOT323 SOT23 SOT323 SOT143B SOT666 SOT666 SOT363 SOT363 Type number BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 5 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 4. Marking Table 5. Marking codes Marking code[1] 6*3 S4 T 43* AJ S6 63* 6*4 44* 64* 6*5 Type number 1PS75SB45 BAS40-05 BAS40-05W 1PS70SB46 BAS40-06 BAS40-06W BAS40-07 BAS40-07V BAS40-05V 1PS88SB48 BAS40XY Marking code[1] 45 45* 65* 6*6 46* 66* 47* 67 65 8*5 40* Type number 1PS70SB40 1PS76SB40 1PS79SB40 BAS40 BAS40H BAS40L BAS40W 1PS70SB44 BAS40-04 BAS40-04W 1PS70SB45 [1] * = -: made in Hong Kong * = p: made in Hong Kong * = t: made in Malaysia * = W: made in China 5. Limiting values Table 6. Limiting values In accordance with the Absolute Maximum Rating System (IEC 60134). Symbol Per diode VR IF IFRM IFSM Tj Tamb Tstg [1] Parameter reverse voltage forward current repetitive peak forward current non-repetitive peak forward current junction temperature ambient temperature storage temperature Conditions Min - Max 40 120 120 200 150 +150 +150 Unit V mA mA mA °C °C °C tp ≤ 1 s; δ ≤ 0.5 tp ≤ 10 ms [1] −65 −65 Tj = 25 °C prior to surge. BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 6 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 6. Thermal characteristics Table 7. Symbol Per device Rth(j-a) thermal resistance from junction to ambient SOT23 SOT143B SOT363 (1PS88SB48) SOT416 SOT666 (BAS40-05V) SOT666 (BAS40-07V) SOD123F SOD323 SOD523 SOD882 SOT323 Rth(j-sp) thermal resistance from junction to solder point SOT363 (BAS40XY) [1] [2] [3] [3] [2] [2] [2] [2] [2] Thermal characteristics Parameter Conditions in free air [1] Min Typ Max Unit - - 500 500 416 833 225 416 330 450 450 500 625 K/W K/W K/W K/W K/W K/W K/W K/W K/W K/W K/W - - 260 K/W Device mounted on an FR4 Printed-Circuit Board (PCB), single-sided copper, tin-plated and standard footprint. Reflow soldering is the only recommended soldering method. Soldering point at pins 2, 3, 5 and 6. 7. Characteristics Table 8. Characteristics Tamb = 25 °C unless otherwise specified. Symbol Per diode VF forward voltage IF = 1 mA IF = 10 mA IF = 40 mA IR Cd [1] [1] Parameter Conditions Min Typ Max Unit - - 380 500 1 1 10 5 mV mV V µA µA pF reverse current diode capacitance Pulse test: tp ≤ 300 µs; δ ≤ 0.02. VR = 30 V VR = 40 V VR = 0 V; f = 1 MHz BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 7 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 102 IF (mA) mlc361 103 IR (µA) (1) mlc362 102 10 10 (1) (2) (3) (4) (2) 1 1 10−1 10−1 (3) 10−2 0 0.2 0.4 0.6 0.8 VF (V) 1 10−2 0 10 20 30 VR (V) 40 (1) Tamb = 125 °C (2) Tamb = 85 °C (3) Tamb = 25 °C (4) Tamb = −40 °C (1) Tamb = 125 °C (2) Tamb = 85 °C (3) Tamb = 25 °C Fig 1. Forward current as a function of forward voltage; typical values 103 rdif (Ω) 102 mlc364 Fig 2. Reverse current as a function of reverse voltage; typical values mlc363 5 Cd (pF) 4 3 2 10 1 1 10−1 1 10 IF (mA) 102 0 0 10 20 30 VR (V) 40 f = 10 kHz Tamb = 25 °C; f = 1 MHz Fig 3. Differential resistance as a function of forward current; typical values Fig 4. Diode capacitance as a function of reverse voltage; typical values BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 8 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 8. Package outline 1.35 1.15 1 0.45 0.15 1.1 0.8 0.85 0.75 1 0.65 0.58 2.7 2.3 1.8 1.6 1.65 1.25 1.55 1.15 2 0.40 0.25 Dimensions in mm 0.25 0.10 03-12-17 Dimensions in mm 0.34 0.26 2 0.17 0.11 02-12-13 Fig 5. Package outline SOD323 (SC-76) Fig 6. Package outline SOD523 (SC-79) 1.7 1.5 1 1.2 1.0 3.0 2.8 3 1.1 0.9 0.45 0.15 2.5 1.4 2.1 1.2 3.6 3.4 2.7 2.5 0.55 0.35 1 2 1.9 Dimensions in mm 0.48 0.38 0.15 0.09 04-11-04 Dimensions in mm 2 0.70 0.55 0.25 0.10 04-11-29 Fig 7. Package outline SOT23 (TO-236AB) Fig 8. Package outline SOD123F 0.62 0.55 2 0.50 0.46 2.2 1.8 3 0.45 0.15 1.1 0.8 0.30 0.22 0.65 0.30 0.22 0.55 0.47 Dimensions in mm 1.02 0.95 2.2 1.35 2.0 1.15 1 1 cathode marking on top side 1.3 03-04-17 Dimensions in mm 2 0.4 0.3 0.25 0.10 04-11-04 Fig 9. Package outline SOD882 BAS40_1PSXXSB4X_SER_7 Fig 10. Package outline SOT323 (SC-70) © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 9 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 3.0 2.8 1.9 4 3 0.45 0.15 1.1 0.9 6 2.2 1.8 5 4 0.45 0.15 1.1 0.8 2.5 2.1 1.4 1.2 2.2 1.35 2.0 1.15 pin 1 index 1 0.88 0.78 1.7 Dimensions in mm 2 0.48 0.38 0.15 0.09 1 0.65 1.3 04-11-16 Dimensions in mm 2 3 0.3 0.2 0.25 0.10 04-11-08 Fig 11. Package outline SOT143B Fig 12. Package outline SOT363 (SC-88) 1.7 1.5 6 5 4 0.3 0.1 0.6 0.5 1.8 1.4 3 0.45 0.15 0.95 0.60 1.75 0.9 1.45 0.7 1.7 1.5 1.3 1.1 pin 1 index 1 2 0.30 0.15 1 0.25 0.10 04-11-04 Dimensions in mm 1 0.5 1 2 3 0.27 0.17 0.18 0.08 04-11-08 Dimensions in mm Fig 13. Package outline SOT416 (SC-75) Fig 14. Package outline SOT666 BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 10 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 9. Packing information Table 9. Packing methods The indicated -xxx are the last three digits of the 12NC ordering code.[1] Type number Package 1PS70SB40 1PS76SB40 1PS79SB40 BAS40 BAS40H BAS40L BAS40W 1PS70SB44 BAS40-04 BAS40-04W 1PS70SB45 1PS75SB45 BAS40-05 BAS40-05W 1PS70SB46 BAS40-06 BAS40-06W BAS40-07 BAS40-07V BAS40-05V 1PS88SB48 BAS40XY SOT323 SOD323 SOD523 SOT23 SOD882 SOT323 SOT323 SOT23 SOT323 SOT323 SOT416 SOT23 SOT323 SOT323 SOT23 SOT323 SOT666 SOT666 SOT363 SOT363 Description 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 2 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 2 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 2 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 2 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel 4 mm pitch, 8 mm tape and reel; T1 4 mm pitch, 8 mm tape and reel; T2 4 mm pitch, 8 mm tape and reel; T1 4 mm pitch, 8 mm tape and reel; T2 [1] [2] [3] [2] [3] [2] [3] Packing quantity 3000 4000 8000 10000 -115 -115 -115 -215 -115 -115 -115 -215 -115 -115 -115 -215 -115 -115 -215 -115 -215 -115 -125 -115 -125 -115 -115 -315 -315 -315 -135 -135 -135 -235 -135 -315 -135 -135 -235 -135 -135 -135 -235 -135 -135 -235 -135 -235 -135 -165 -135 -165 SOD123F 4 mm pitch, 8 mm tape and reel SOT143B 4 mm pitch, 8 mm tape and reel For further information and the availability of packing methods, see Section 13. T1: normal taping T2: reverse taping BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 11 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 10. Soldering 3.05 2.80 2.10 1.60 solder lands solder resist 1.65 0.95 0.50 0.60 occupied area solder paste 0.50 (2×) msa433 Dimensions in mm Fig 15. Reflow soldering footprint SOD323 (SC-76) 5.00 4.40 1.40 solder lands solder resist 2.75 1.20 occupied area MSA415 preferred transport direction during soldering Dimensions in mm Fig 16. Wave soldering footprint SOD323 (SC-76) 2.15 solder paste solder lands solder resist occupied area 1.20 0.50 0.60 0.30 0.40 1.80 1.90 MGS343 Reflow soldering is the only recommended soldering method. Dimensions in mm Fig 17. Reflow soldering footprint SOD523 (SC-79) BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 12 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 2.90 2.50 solder lands solder resist 0.85 3.00 0.85 1.30 3 0.60 (3x) 0.50 (3x) 0.60 (3x) 1.00 3.30 MSA439 2 1 2.70 occupied area solder paste Dimensions in mm Fig 18. Reflow soldering footprint SOT23 (TO-236AB) 3.40 1.20 (2x) solder lands solder resist occupied area 2 4.60 4.00 1.20 3 1 preferred transport direction during soldering 2.80 4.50 MSA427 Dimensions in mm Fig 19. Wave soldering footprint SOT23 (TO-236AB) BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 13 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 4.4 4 2.9 1.6 solder lands solder resist 2.1 1.6 1.1 1.2 solder paste occupied area 1.1 (2×) Reflow soldering is the only recommended soldering method. Dimensions in mm Fig 20. Reflow soldering footprint SOD123F 1.30 R = 0.05 (8×) 0.30 R = 0.05 (8×) solder lands solder resist occupied area solder paste 0.90 0.60 0.70 0.80 (2×) (2×) (2×) 0.30 (2×) 0.40 (2×) 0.50 (2×) MBL872 Reflow soldering is the only recommended soldering method. Dimensions in mm Fig 21. Reflow soldering footprint SOD882 BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 14 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 2.65 0.75 1.325 1.30 solder lands 2 solder resist 0.60 2.35 0.85 (3x) 3 0.50 (3x) 1.90 1 0.55 (3x) occupied area solder paste 2.40 MSA429 Dimensions in mm Fig 22. Reflow soldering footprint SOT323 (SC-70) 4.60 4.00 1.15 solder lands solder resist 2 occupied area 3.65 2.10 3 2.70 0.90 (2x) 1 MSA419 preferred transport direction during soldering Dimensions in mm Fig 23. Wave soldering footprint SOT323 (SC-70) BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 15 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 3.25 0.60 (3x) 0.50 (3x) solder lands 0.60 (4x) 4 2.70 1 2 3 1.30 3.00 occupied area solder paste solder resist msa441 0.90 1.00 2.50 Dimensions in mm Fig 24. Reflow soldering footprint SOT143B 4.45 1.20 (3x) solder lands solder resist occupied area 4 3 1.15 4.00 4.60 1 2 preferred transport direction during soldering 1.00 3.40 MSA422 Dimensions in mm Fig 25. Wave soldering footprint SOT143B BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 16 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 2.65 0.60 (2×) 2.35 0.40 0.90 2.10 (2×) 0.50 (4×) solder paste solder lands solder resist occupied area 0.50 (4×) 1.20 2.40 MSA432 Dimensions in mm Fig 26. Reflow soldering footprint SOT363 (SC-88) 5.25 4.50 0.30 1.00 4.00 solder lands solder resist occupied area 1.15 3.75 transport direction during soldering sot363 Dimensions in mm Fig 27. Wave soldering footprint SOT363 (SC-88) BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 17 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 2.20 0.60 1.10 0.70 solder lands 2 2.00 0.85 3 1 0.50 (3x) MSA438 solder resist 1.50 occupied area solder paste 0.60 (3x) 1.90 Dimensions in mm Fig 28. Reflow soldering footprint SOT416 2.75 2.45 2.10 1.60 0.15 (4×) 0.40 (6×) 2.00 1.70 1.00 0.55 (2×) 0.30 (2×) 0.375 (4×) 1.20 2.20 2.50 solder lands placement area occupied area 0.075 solder resist Dimensions in mm Reflow soldering is the only recommended soldering method. Fig 29. Reflow soldering footprint SOT666 BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 18 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 11. Revision history Table 10. Revision history Release date Data sheet status Product data sheet Change notice Supersedes BAS40_1PSXXSB4X_ SER_6 Document ID BAS40_1PSXXSB4X_ 20060512 SER_7 Modifications: • • • • • Type number BAS40XY added Table 9 “Packing methods”: added packing method 2 mm pitch for SOD523 Figure 27 “Wave soldering footprint SOT363 (SC-88)”: amended Figure 29 “Reflow soldering footprint SOT666”: amended Section 12 “Legal information”: updated Product data sheet 1PS70SB40_3 1PS75SB45_2 1PS76SB40_3 1PS79SB40_2 1PS88SB48_3 BAS40H_1 BAS40L_1 BAS40-05V_1 BAS40-07V_1 BAS40W_3 BAS40_SERIES_5 1PS70SB40_2 1PS75SB45_1 1PS76SB40_2 1PS79SB40_1 1PS88SB48_2 BAS40W_2 BAS40_4 BAS40_1PSXXSB4X_ 20050809 SER_6 1PS70SB40_3 1PS75SB45_2 1PS76SB40_3 1PS79SB40_2 1PS88SB48_3 BAS40H_1 BAS40L_1 BAS40-05V_1 BAS40-07V_1 BAS40W_3 BAS40_SERIES_5 19990426 19990426 20040126 19990426 20021107 20050425 20030520 20021121 20020327 19990426 20011010 Product specification Product specification Product specification Product specification Product specification Product data sheet Product specification Product specification Product specification Product specification Product specification - BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 19 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 12. Legal information 12.1 Data sheet status Document status[1][2] Objective [short] data sheet Preliminary [short] data sheet Product [short] data sheet [1] [2] [3] Product status[3] Development Qualification Production Definition This document contains data from the objective specification for product development. This document contains data from the preliminary specification. This document contains the product specification. Please consult the most recently issued document before initiating or completing a design. The term ‘short data sheet’ is explained in section “Definitions”. The product status of device(s) described in this document may have changed since this document was published and may differ in case of multiple devices. The latest product status information is available on the Internet at URL http://www.semiconductors.philips.com. 12.2 Definitions Draft — The document is a draft version only. The content is still under internal review and subject to formal approval, which may result in modifications or additions. Philips Semiconductors does not give any representations or warranties as to the accuracy or completeness of information included herein and shall have no liability for the consequences of use of such information. Short data sheet — A short data sheet is an extract from a full data sheet with the same product type number(s) and title. A short data sheet is intended for quick reference only and should not be relied upon to contain detailed and full information. For detailed and full information see the relevant full data sheet, which is available on request via the local Philips Semiconductors sales office. In case of any inconsistency or conflict with the short data sheet, the full data sheet shall prevail. malfunction of a Philips Semiconductors product can reasonably be expected to result in personal injury, death or severe property or environmental damage. Philips Semiconductors accepts no liability for inclusion and/or use of Philips Semiconductors products in such equipment or applications and therefore such inclusion and/or use is for the customer’s own risk. Applications — Applications that are described herein for any of these products are for illustrative purposes only. Philips Semiconductors makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification. Limiting values — Stress above one or more limiting values (as defined in the Absolute Maximum Ratings System of IEC 60134) may cause permanent damage to the device. Limiting values are stress ratings only and operation of the device at these or any other conditions above those given in the Characteristics sections of this document is not implied. Exposure to limiting values for extended periods may affect device reliability. Terms and conditions of sale — Philips Semiconductors products are sold subject to the general terms and conditions of commercial sale, as published at http://www.semiconductors.philips.com/profile/terms, including those pertaining to warranty, intellectual property rights infringement and limitation of liability, unless explicitly otherwise agreed to in writing by Philips Semiconductors. In case of any inconsistency or conflict between information in this document and such terms and conditions, the latter will prevail. No offer to sell or license — Nothing in this document may be interpreted or construed as an offer to sell products that is open for acceptance or the grant, conveyance or implication of any license under any copyrights, patents or other industrial or intellectual property rights. 12.3 Disclaimers General — Information in this document is believed to be accurate and reliable. However, Philips Semiconductors does not give any representations or warranties, expressed or implied, as to the accuracy or completeness of such information and shall have no liability for the consequences of use of such information. Right to make changes — Philips Semiconductors reserves the right to make changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice. This document supersedes and replaces all information supplied prior to the publication hereof. Suitability for use — Philips Semiconductors products are not designed, authorized or warranted to be suitable for use in medical, military, aircraft, space or life support equipment, nor in applications where failure or 12.4 Trademarks Notice: All referenced brands, product names, service names and trademarks are the property of their respective owners. 13. Contact information For additional information, please visit: http://www.semiconductors.philips.com For sales office addresses, send an email to: sales.addresses@www.semiconductors.philips.com BAS40_1PSXXSB4X_SER_7 © Koninklijke Philips Electronics N.V. 2006. All rights reserved. Product data sheet Rev. 07 — 12 May 2006 20 of 21 Philips Semiconductors BAS40 series; 1PSxxSB4x series General-purpose Schottky diodes 14. Contents 1 1.1 1.2 1.3 1.4 2 3 4 5 6 7 8 9 10 11 12 12.1 12.2 12.3 12.4 13 14 Product profile . . . . . . . . . . . . . . . . . . . . . . . . . . 1 General description. . . . . . . . . . . . . . . . . . . . . . 1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Quick reference data. . . . . . . . . . . . . . . . . . . . . 2 Pinning information . . . . . . . . . . . . . . . . . . . . . . 2 Ordering information . . . . . . . . . . . . . . . . . . . . . 5 Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Limiting values. . . . . . . . . . . . . . . . . . . . . . . . . . 6 Thermal characteristics. . . . . . . . . . . . . . . . . . . 7 Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Package outline . . . . . . . . . . . . . . . . . . . . . . . . . 9 Packing information. . . . . . . . . . . . . . . . . . . . . 11 Soldering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Revision history . . . . . . . . . . . . . . . . . . . . . . . . 19 Legal information. . . . . . . . . . . . . . . . . . . . . . . 20 Data sheet status . . . . . . . . . . . . . . . . . . . . . . 20 Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Disclaimers . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Contact information. . . . . . . . . . . . . . . . . . . . . 20 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Please be aware that important notices concerning this document and the product(s) described herein, have been included in section ‘Legal information’. © Koninklijke Philips Electronics N.V. 2006. All rights reserved. For more information, please visit: http://www.semiconductors.philips.com. For sales office addresses, email to: sales.addresses@www.semiconductors.philips.com. Date of release: 12 May 2006 Document identifier: BAS40_1PSXXSB4X_SER_7
