BZB984-C6V8

DISCRETE SEMICONDUCTORS DATA SHEET M3D793 BZB984 series Voltage regulator double diodes Product specification Supersedes data of 2001 Nov 28 2002 Jun 21 Philips Semiconductors Product specification Voltage regulator double diodes FEATURES • Total power dissipation: max. 425 mW • Approx. 5% VZ tolerance • Ultra small flat plastic SMD package • Working voltage range nom. 2.4 to 15 V (E24 range). APPLICATIONS • General regulation functions • ESD and surge protection. handbook, halfpage BZB984 series PINNING PIN 1 2 3 DESCRIPTION cathode 1 cathode 2 common anode 3 1 3 2 DESCRIPTION Low-power voltage regulator diodes in a SOT663 ultra small plastic SMD package. Fig.1 1 Top view 2 MHC314 Simplified outline (SOT663) and symbol. MARKING TYPE NUMBER BZB984-C2V4 BZB984-C2V7 BZB984-C3V0 BZB984-C3V3 BZB984-C3V6 MARKING CODE 91 92 93 94 95 TYPE NUMBER BZB984-C3V9 BZB984-C4V3 BZB984-C4V7 BZB984-C5V1 BZB984-C5V6 MARKING CODE 96 97 98 99 9A TYPE NUMBER BZB984-C6V2 BZB984-C6V8 BZB984-C7V5 BZB984-C8V2 BZB984-C9V1 MARKING CODE 9B 9C 9D 9E 9F TYPE NUMBER BZB984-C10 BZB984-C11 BZB984-C12 BZB984-C13 BZB984-C15 MARKING CODE 9G 9H 9J 9K 9L LIMITING VALUES In accordance with the Absolute Maximum Rating System (IEC 60134). SYMBOL IF IZSM Ptot PZSM Tstg Tj Note 1. Device mounted on an FR4 printed-circuit board. PARAMETER continuous forward current non-repetitive peak reverse current total power dissipation non-repetitive peak reverse dissipation storage temperature junction temperature tp = 100 µs; square wave; Tamb = 25 °C; prior to surge Tamb = 25 °C; 2 diodes loaded; note 1 Tamb = 25 °C; 1 diode loaded; note 1 tp = 100 µs; square wave; Tamb = 25 °C; prior to surge CONDITIONS − MIN. MAX. 200 UNIT mA see Table 1 − − − −65 − 425 265 40 +150 150 mW mW W °C °C 2002 Jun 21 2 Philips Semiconductors Product specification Voltage regulator double diodes ELECTRICAL CHARACTERISTICS Total BZB984-C series Tamb = 25 °C unless otherwise specified. SYMBOL VF IR PARAMETER forward voltage reverse current BZB984-C2V4 BZB984-C2V7 BZB984-C3V0 BZB984-C3V3 BZB984-C3V6 BZB984-C3V9 BZB984-C4V3 BZB984-C4V7 BZB984-C5V1 BZB984-C5V6 BZB984-C6V2 BZB984-C6V8 BZB984-C7V5 BZB984-C8V2 BZB984-C9V1 BZB984-C10 BZB984-C11 BZB984-C12 BZB984-C13 BZB984-C15 VR = 1 V VR = 1 V VR = 1 V VR = 1 V VR = 1 V VR = 1 V VR = 1 V VR = 2 V VR = 2 V VR = 2 V VR = 4 V VR = 4 V VR = 5 V VR = 5 V VR = 6 V VR = 7 V VR = 8 V VR = 8 V VR = 8 V VR = 10.5 V CONDITIONS IF = 10 mA; see Fig.2 BZB984 series MAX. 0.9 50 20 10 5 5 3 3 3 2 1 3 2 1 700 500 200 100 100 100 50 V UNIT µA µA µA µA µA µA µA µA µA µA µA µA µA nA nA nA nA nA nA nA 2002 Jun 21 3 This text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here in _white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader.This text is here inThis text is here in white to force landscape pages to be rotated correctly when browsing through the pdf in the Acrobat reader. white to force landscape pages to be ... Table 1 Per type BZB984-C2V4 to C15 Tj = 25 °C unless otherwise specified. WORKING VOLTAGE VZ (V) at IZ = 5 mA BZB984Cxxx Tol. ≈5% MIN. 2V4 2V7 3V0 3V3 3V6 3V9 4V3 4V7 5V1 5V6 6V2 6V8 7V5 8V2 9V1 10 11 12 13 15 4 2.2 2.5 2.8 3.1 3.4 3.7 4.0 4.4 4.8 5.2 5.8 6.4 7.0 7.7 8.5 9.4 10.4 11.4 12.4 13.8 MAX. 2.6 2.9 3.2 3.5 3.8 4.1 4.6 5.0 5.4 6.0 6.6 7.2 7.9 8.7 9.6 10.6 11.6 12.7 14.1 15.6 DIFFERENTIAL RESISTANCE rdif (Ω) at IZ = 1 mA TYP. 275 300 325 350 375 400 410 425 400 80 40 30 30 40 40 50 50 50 50 50 MAX. 600 600 600 600 600 600 600 500 480 400 150 80 80 80 100 150 150 150 170 200 at IZ = 5 mA TYP. 70 75 80 85 85 85 80 50 40 15 6 6 6 6 6 8 10 10 10 10 MAX. 100 100 95 95 90 90 90 80 60 40 10 15 15 15 15 20 20 25 30 30 −1.3 −1.4 −1.6 −1.8 −1.9 −1.9 −1.7 −1.2 −0.5 1.0 2.2 3.0 3.6 4.3 5.2 6.0 6.9 7.9 8.8 10.7 TEMP. COEFF. SZ (mV/K) at IZtest = 5 mA (see Figs 3 and 4) TYP. 450 450 450 450 450 450 450 300 300 300 200 200 150 150 150 90 90 85 80 75 DIODE CAP. Cd (pF) at f = 1 MHz; VR = 0 V MAX. 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 6.0 4.0 4.0 3.0 3.0 2.5 2.5 2.5 2.0 NON-REPETITIVE PEAK REVERSE CURRENT IZSM (A) at tp = 100 µs; Tamb = 25 °C MAX. 2002 Jun 21 Philips Semiconductors Voltage regulator double diodes BZB984 series Product specification Philips Semiconductors Product specification Voltage regulator double diodes THERMAL CHARACTERISTICS SYMBOL Rth j-s Rth j-a PARAMETER thermal resistance from junction to soldering point thermal resistance from junction to ambient CONDITIONS 2 diodes loaded; note 1 1 diode loaded; note 1 2 diodes loaded; note 2 1 diode loaded; note 2 Notes 1. Solder points on cathode tabs. 2. Device mounted on an FR4 printed-circuit board. Soldering The only recommended soldering method is reflow soldering. GRAPHICAL DATA BZB984 series VALUE 125 230 294 472 UNIT K/W K/W K/W K/W handbook, halfpage 300 MLD362 MLD363 handbook, halfpage 0.5 IF (mA) 200 SZ (mV/K) 0 4V7 4V3 −0.5 2V4 2V7 −1 3V9 100 3V6 −1.5 3V3 3V0 0 0.6 0.7 0.8 0.9 VF (V) 1 −2 10−1 1 10 IZ (mA) 102 BZB984-C2V4 to C4V7. Tj = 25 °C. Tj = 25 to 150 °C. Fig.2 Forward current as a function of forward voltage; typical values. Fig.3 Temperature coefficient as a function of working current; typical values. 2002 Jun 21 5 Philips Semiconductors Product specification Voltage regulator double diodes BZB984 series handbook, halfpage 12 MLD364 SZ (mV/K) 8 15 13 12 11 10 9V1 8V2 7V5 6V8 6V2 5V6 5V1 4 0 −4 10−1 1 10 IZ (mA) 102 BZB984-C5V1 to C15. Tj = 25 to 150 °C. Fig.4 Temperature coefficient as a function of working current; typical values. 2002 Jun 21 6 Philips Semiconductors Product specification Voltage regulator double diodes PACKAGE OUTLINE Plastic surface mounted package; 3 leads BZB984 series SOT663 D B E X Y HE 3 A 1 e1 e bp 2 wMB Lp detail X c 0 1 scale 2 mm DIMENSIONS (mm are the original dimensions) UNIT mm A 0.6 0.5 bp 0.33 0.23 c 0.18 0.08 D 1.7 1.5 E 1.3 1.1 e 1.0 e1 0.5 HE 1.7 1.5 Lp 0.3 0.1 w 0.1 y 0.1 OUTLINE VERSION SOT663 REFERENCES IEC JEDEC JEITA EUROPEAN PROJECTION ISSUE DATE 01-12-04 02-05-21 2002 Jun 21 7 Philips Semiconductors Product specification Voltage regulator double diodes DATA SHEET STATUS DATA SHEET STATUS(1) Objective data PRODUCT STATUS(2) Development DEFINITIONS BZB984 series This data sheet contains data from the objective specification for product development. Philips Semiconductors reserves the right to change the specification in any manner without notice. This data sheet contains data from the preliminary specification. Supplementary data will be published at a later date. Philips Semiconductors reserves the right to change the specification without notice, in order to improve the design and supply the best possible product. This data sheet contains data from the product specification. Philips Semiconductors reserves the right to make changes at any time in order to improve the design, manufacturing and supply. Changes will be communicated according to the Customer Product/Process Change Notification (CPCN) procedure SNW-SQ-650A. Preliminary data Qualification Product data Production Notes 1. Please consult the most recently issued data sheet before initiating or completing a design. 2. The product status of the device(s) described in this data sheet may have changed since this data sheet was published. The latest information is available on the Internet at URL http://www.semiconductors.philips.com. DEFINITIONS Short-form specification  The data in a short-form specification is extracted from a full data sheet with the same type number and title. For detailed information see the relevant data sheet or data handbook. Limiting values definition  Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 60134). Stress above one or more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation of the device at these or at any other conditions above those given in the Characteristics sections of the specification is not implied. Exposure to limiting values for extended periods may affect device reliability. Application information  Applications that are described herein for any of these products are for illustrative purposes only. Philips Semiconductors make no representation or warranty that such applications will be suitable for the specified use without further testing or modification. DISCLAIMERS Life support applications  These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury. Philips Semiconductors customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips Semiconductors for any damages resulting from such application. Right to make changes  Philips Semiconductors reserves the right to make changes, without notice, in the products, including circuits, standard cells, and/or software, described or contained herein in order to improve design and/or performance. Philips Semiconductors assumes no responsibility or liability for the use of any of these products, conveys no licence or title under any patent, copyright, or mask work right to these products, and makes no representations or warranties that these products are free from patent, copyright, or mask work right infringement, unless otherwise specified. 2002 Jun 21 8 Philips Semiconductors Product specification Voltage regulator double diodes NOTES BZB984 series 2002 Jun 21 9 Philips Semiconductors Product specification Voltage regulator double diodes NOTES BZB984 series 2002 Jun 21 10 Philips Semiconductors Product specification Voltage regulator double diodes NOTES BZB984 series 2002 Jun 21 11 Philips Semiconductors – a worldwide company Contact information For additional information please visit http://www.semiconductors.philips.com. Fax: +31 40 27 24825 For sales offices addresses send e-mail to: sales.addresses@www.semiconductors.philips.com. © Koninklijke Philips Electronics N.V. 2002 SCA74 All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner. The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof does not convey nor imply any license under patent- or other industrial or intellectual property rights. Printed in The Netherlands 613514/02/pp12 Date of release: 2002 Jun 21 Document order number: 9397 750 09768
