Datasheet for part number MS3101R24-2PZ Our Catalog Part Number: MS3101R242PZ Brand: Cannon Product Category: Circular Product Line: MIL-DTL 5015 Series I Series: MIL-C-5015 Product Datasheet Thread Shell Style Endbell Style Gender Shell Size Contact Arrangement Number of contacts Contact Type Contact Plating Shielding Insulator Rotation Contact Rating at +20 °C (68 °F) (Size 25/12) Contact Resistance (Size 25/12) Operating Voltage Insulator Resistance Test Voltage Air and Creepage Paths (Min) Ambient Temperature Safety Provisions Salt Spray Resistance Mating Cycles Sep. Force per Contact (Size 25/12) Gage Coupling Torque Contact Retention (Size 25/12) Shell Material Shell Plating Insulator and Gromet Material Contact Material Connector with threaded coupling Cable connecting plug Shortened light-weight endbell without cable clamp Pin 24 24-2 7 contacts size 12 Solder Cup Hard silver no 280° 41 A 3 mΩ In case of voltages greater than 50V the connector must be used in accordance with DIN VDE part 410, IEC 60364-4-41. Acc. To VG95319, part 2, test no. 5.12 and VG95210, part 32, test conditions B, standard insulator material > 1000 MΩ 2500 Vrms 2,8 mm Standard insulator material -55°/+125°C (-67/257°F) IP65 acc. to DIN 40 050 500 hours salt spray resistant 500 min 1,5 N For infos on Gage please see catalog VG95234, part 1 Closing: 14 Nm max / Opening: 0,8 Nm min 55 N Aluminium alloy Olive drab chromate coating over cadmium plating Neoprene Copper alloy Harnessing Info: Contact Cross-Section See assembly instruction Harnessing Info: Insulator Diameter See assembly instruction Wire Stripping (Size 25/12) General Info 6,2 mm All tests in accordance with VG95319 and/or if applicable with VG95210 Specifications and dimensions subject to change. Page 1 of 1
