Datasheet for part number MS3106E32-1P Our Catalog Part Number: MS3106E321P Our Global Manufacturing Part Number: 024276-0001 Brand: Cannon Product Category: Circular Product Line: MIL-DTL 5015 Series I Series: MIL-C-5015 Product Datasheet Thread Shell Style Endbell Style Gender Shell Size Contact Arrangement Number of contacts Contact Type Contact Plating Shielding Contact Rating at +20 °C (68 °F) (Size 25/12) Contact Rating at +20 °C (68 °F) (Size 500/0) Contact Resistance (Size 25/12) Contact Resistance (Size 500/0) Operating Voltage Insulator Resistance Test Voltage Air and Creepage Paths (Min) Ambient Temperature Safety Provisions Salt Spray Resistance Mating Cycles Sep. Force per Contact (Size 25/12) Sep. Force per Contact (Size 500/0) Gage Coupling Torque Contact Retention (Size 25/12) Contact Retention (Size 500/0) Shell Material Shell Plating Insulator and Gromet Material Contact Material Connector with threaded coupling Plug, straight Endbell with clamp and bushing Pin 32 32-1 2 contacts size 0, 3 contacts size 12 Solder Cup Hard silver no 41 A 245 A 3 mΩ 0,2 mΩ In case of voltages greater than 50V the connector must be used in accordance with DIN VDE part 410, IEC 60364-4-41. Acc. To VG95319, part 2, test no. 5.12 and VG95210, part 32, test conditions B, standard insulator material > 1000 MΩ 2500 Vrms 2,8 mm Standard insulator material -55°/+125°C (-67/257°F) IP65 acc. to DIN 40 050 500 hours salt spray resistant 500 min 1,5 N 8,5 N For infos on Gage please see catalog VG95234, part 1 Closing: 19 Nm max / Opening: 1,03 Nm min 55 N 95 N Aluminium alloy Olive drab chromate coating over cadmium plating Neoprene Copper alloy Harnessing Info: Contact Cross-Section See assembly instruction Harnessing Info: Insulator Diameter See assembly instruction Wire Stripping (Size 25/12) Wire Stripping (Size 500/0) 6,2 mm 13,7 mm Specifications and dimensions subject to change. Page 1 of 2 Datasheet for part number MS3106E32-1P Our Catalog Part Number: MS3106E321P Our Global Manufacturing Part Number: 024276-0001 Brand: Cannon Product Category: Circular Product Line: MIL-DTL 5015 Series I Series: MIL-C-5015 Product Datasheet General Info All tests in accordance with VG95319 and/or if applicable with VG95210 Specifications and dimensions subject to change. Page 2 of 2
