https://www.phoenixcontact.com/gb/products/1551529 Bus system flat-type plug - SACC-DSI-FSD-4CON-PG9/0,5 SCO - 1551529 Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's documentation. Our General Terms of Use for Downloads are valid (http://phoenixcontact.com/download) Bus system flush-type socket, PROFINET, 4-pos., M12 SPEEDCON, D-coded, front/screw mounting with Pg9 thread, with 0.5 m TPE litz wire, 4 x 0.34 mm² Why buy this product ■ ■ ■ ■ ■ ■ Pre-assembled with litz wires for immediate use Customer-specific assemblies and litz wire lengths available Sealed on the litz wire side for optimum leak-tightness All standard pin assignments and codings for signal, data, and power transmission with a uniform design-in design For high transmission safety: shield connection to the housing with optional EMC nut SPEEDCON fast locking system reduces cabling times Key Commercial Data Packing unit 1 STK GTIN Weight per Piece (excluding packing) 22.5 g Custom tariff number 85444290 Country of origin Germany Technical data Dimensions Length of cable 0.5 m Ambient conditions Ambient temperature (operation) -25 °C ... 85 °C (Plug / socket) -40 °C ... 85 °C (without mechanical actuation) Degree of protection IP67 08/06/2016   Page 1 / 6 https://www.phoenixcontact.com/gb/products/1551529 Bus system flat-type plug - SACC-DSI-FSD-4CON-PG9/0,5 SCO - 1551529 Technical data General Note The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of contamination, the connector must be sealed using a protective cap > IP54. Influences arising from litz wires, cables or PCB assembly must also be taken into consideration. This product corresponds to the PROFINET Cabling and Interconnection Technology Guideline for PROFINET regulations, version 2.00, order no: 2.252, Chapter 8.2 Connectors for Outside Environment (Balanced cabling) Rated current at 40°C 4A Rated voltage 250 V Rated surge voltage 2.5 kV Number of positions 4 Insulation resistance ≥ 100 MΩ Coding D - data Standards/regulations M12 connector IEC 61076-2-101 Status display No Overvoltage category II Degree of pollution 3 Connection method Individual wires Insertion/withdrawal cycles ≥ 100 Torque 3 Nm ... 4 Nm (Installation-side) Mounting type Rear mounting Pg9 With flat nut Material Flammability rating according to UL 94 V0 Contact material CuZn Contact surface material Ni/Au Contact carrier material PA 66 Material, knurls Zinc die-cast, nickel-plated Sealing material FKM Standards and Regulations Standard designation M12 connector Standards/regulations IEC 61076-2-101 Flammability rating according to UL 94 V0 Drawings 08/06/2016   Page 2 / 6 https://www.phoenixcontact.com/gb/products/1551529 Bus system flat-type plug - SACC-DSI-FSD-4CON-PG9/0,5 SCO - 1551529 Dimensional drawing Dimensional drawing Ø15,3 +0,1 PG9 Ø16 45 ° max.4,5 Housing cutout for M16 fastening thread, mounting panel with feedthrough hole (alternatively with area as anti-rotation protection for panel thicknesses > 2 mm up to max. 4.5 mm) 13,5 +0,1 1x45° Housing cutout for Pg9 fastening thread, mounting panel with feedthrough hole (alternatively with surface as protection against rotation) Schematic diagram Dimensional drawing 19,6 Pin assignment M12 socket, 4-pos., D-coded, female side 2 500 17 PG9 18 9,5 !4,5 M12 flush-type connector Circuit diagram 1 YE 2 WH 3 OG 4 BU Contact assignment of the M12 socket Classifications eCl@ss eCl@ss 4.0 27250313 eCl@ss 4.1 27250313 eCl@ss 5.0 27143423 eCl@ss 5.1 27143423 eCl@ss 6.0 27143423 eCl@ss 7.0 27449001 eCl@ss 8.0 27440103 eCl@ss 9.0 27440102 08/06/2016   Page 3 / 6 https://www.phoenixcontact.com/gb/products/1551529 Bus system flat-type plug - SACC-DSI-FSD-4CON-PG9/0,5 SCO - 1551529 Classifications ETIM ETIM 3.0 EC002061 ETIM 4.0 EC000830 ETIM 5.0 EC002061 UNSPSC UNSPSC 6.01 31261501 UNSPSC 7.0901 31261501 UNSPSC 11 31261501 UNSPSC 12.01 31261501 UNSPSC 13.2 31261501 Approvals Approvals Approvals cULus Recognized / EAC / UL Recognized / EAC Ex Approvals Approvals submitted Approval details cULus Recognized      mm²/AWG/kcmil 20 Nominal current IN 4A Nominal voltage UN 250 V EAC  UL Recognized      mm²/AWG/kcmil 26-20 08/06/2016   Page 4 / 6 https://www.phoenixcontact.com/gb/products/1551529 Bus system flat-type plug - SACC-DSI-FSD-4CON-PG9/0,5 SCO - 1551529 Approvals     Nominal current IN 4A Nominal voltage UN 250 V EAC  Accessories Accessories Protective cap Screw plug - PROT-M12 - 1680539 An M12 screw plug for the unoccupied M12 sockets of the sensor/actuator cable, boxes and flush-type connectors     Screw plug - PROT-M12 SH - 1503302 An M12 screw plug for the unoccupied M12 sockets of the shielded sensor/actuator cable, boxes and flush-type connectors     Screw plug - PROT-M12 FB - 1555538 M12 high-grade steel screw plug, for unoccupied M12 sockets of the sensor/actuator cables, boxes and flush-type connectors for the food industry     Seal Flat gasket - SACC-PG9-SEAL CLM - 1556320 Pg9 flat gasket for the rear mounting of M12 flush-type connectors with Pg9 fastening threads     08/06/2016   Page 5 / 6 https://www.phoenixcontact.com/gb/products/1551529 Phoenix Contact 2016 © - all rights reserved http://www.phoenixcontact.com 08/06/2016   Page 6 / 6
