2017-10-24
Product version 04
Data sheet
Document revision 0
Order No.: 1804959
Type: PC 4/ 7-ST-7,62
Plug component, Screw connection with tension
sleeve
Main features
No. of pos.
Conductor cross section
Color
Pitch
Connection method
7
4 mm²
green
7.62 mm
Screw connection with
tension sleeve
Nominal current
Nominal voltage
Connection direction
Type of packaging
20 A
630 V
0°
packed in cardboard
1
The figure shows a 5-pos. version of the product
Your advantages
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
Integrated double steel spring provides additional safety in the event of temperature and power fluctuations
Make sure you always use the latest documentation.
It can be downloaded at: phoenixcontact.net/product/1804959
© PHOENIX CONTACT 2017
2
2017-10-24
Product version 04
Main features........................................................................................................................... 1
2
Your advantages ..................................................................................................................... 1
3
Table of contents ..................................................................................................................... 2
4
3D model in PDF can be activated (Acrobat Reader only)....................................................... 3
5
item properties......................................................................................................................... 4
5.1
Connection capacity ............................................................................................................. 4
5.2
Material data ...................................................................................................................... 4
6
Dimensions.............................................................................................................................. 4
6.1
Dimensions for the product .................................................................................................... 4
7
Series drawing......................................................................................................................... 6
8
Packaging information ............................................................................................................. 6
9
Application............................................................................................................................... 6
9.1
Temperature limit values ....................................................................................................... 6
10
Mechanical tests...................................................................................................................... 7
10.1 Termination and connection method ......................................................................................... 7
10.2 Pull-out test ........................................................................................................................ 7
11
Electrical tests ......................................................................................................................... 8
11.1 Electrical data ..................................................................................................................... 8
11.2 Air and creepage distances .................................................................................................... 8
12
Current carrying capacity/derating curves ............................................................................... 9
13
Environmental and durability tests ......................................................................................... 10
13.1 Vibration test .................................................................................................................... 10
14
Classification for connectors.................................................................................................. 10
15
Approvals .............................................................................................................................. 10
16
Commercial Data................................................................................................................... 12
17
corresponding headers.......................................................................................................... 12
18
Accessories ........................................................................................................................... 12
19
Combination tests.................................................................................................................. 13
Table of contents
1
© PHOENIX CONTACT 2017
3
Document revision 0
1804959 PC 4/ 7-ST-7,62
REF 1804904
PHOENIX CONTACT 2 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
3D model in PDF can be activated (Acrobat Reader only)
© PHOENIX CONTACT 2017
4
Document revision 0
REF 1804904
PHOENIX CONTACT 3 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
item properties
Order No.
1804959
Type
PC 4/ 7-ST-7,62
Type of contact
Female connector
Range of articles
PC 4/..-ST
Pitch
7.62 mm
Number of positions
7
Connection method
Screw connection with tension sleeve
Screw thread
M3
Tightening torque
0.5 Nm ... 0.6 Nm
Locking
without
5.1
Connection capacity
Conductor cross section, solid
0.2 mm² to 4 mm²
Conductor cross section, flexible
0.2 mm² to 4 mm²
Conductor cross section AWG/kcmil
24 to 10
2 conductors with same cross section, solid
0.2 mm² to 2.5 mm²
2 conductors with same cross section, stranded
0.2 mm² to 1.5 mm²
Conductor cross section flexible, with ferrule without plastic sleeve
0.25 mm² to 4 mm²
Conductor cross section flexible, with ferrule with plastic sleeve
0.25 mm² to 4 mm²
2 conductors with same cross section, stranded, with ferrule without plastic
sleeve
0.25 mm² to 1.5 mm²
2 conductors with same cross section, stranded, with TWIN ferrules with
plastic sleeve
0.5 mm² to 2.5 mm²
Cylindrical gauge a x b / diameter
3.6 mm x 3.1 mm / 3.0 mm
Stripping length
7 mm
5.2
5
Document revision 0
Material data
Material of metal parts
Note
WEEE/RoHS-compliant, whisker-free acc. to IEC 60068-2-82/JEDEC JESD 201
Contact material
Cu alloy
Terminal point surface
Sn 4 µm ... 8 µm
Sn 4 µm ... 8 µm
Surface contact area
hot-dip tin-plated
Insulating material data
Housing
Insulating material
PA
CTI according to IEC 60112
600
Flammability rating according to UL 94
V0
Color
green (6021)
Glow wire flammability index GWFI according to EN 60695-2-12
850
Glow wire ignition temperature GWIT according to EN 60695-2-13
775
Temperature for the ball pressure test according to EN 60695-10-2
125 °C
6
Dimensions
6.1
Dimensions for the product
REF 1804904
© PHOENIX CONTACT 2017
Surface characteristics
PHOENIX CONTACT 4 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
Document revision 0
30.7 mm
Width
53.32 mm
Total height
18.1 mm
Dimension a
45.72 mm
© PHOENIX CONTACT 2017
Length
REF 1804904
PHOENIX CONTACT 5 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
7
Series drawing
8
Packaging information
Document revision 0
Type of packaging
packed in cardboard
Pieces per package
50
9
Application
9.1
Temperature limit values
-40 °C ... 70 °C
Ambient temperature (assembly)
-5 °C ... 100 °C
Ambient temperature (operation)
-40 °C (dependent on the derating curve)
© PHOENIX CONTACT 2017
Ambient temperature (storage/transport)
REF 1804904
PHOENIX CONTACT 6 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
10
Document revision 0
Mechanical tests
Mechanical test group A
Specification
IEC 61984:2008-10
Visual test
Test passed
Specification
IEC 60512-1-1:2002-02
Dimensional test
Test passed
Specification
IEC 60512-1-2:2002-02
Resistance of marking
Test passed
Specification
IEC 60068-2-70:1995-12
Insertion and withdrawal force
Test passed
Specification
IEC 60512-13-2:2006-02
No. of cycles
50
Insertion strength per pos. approx.
8N
Withdraw strength per pos. approx.
5N
Polarization and coding
Test passed
Specification
IEC 60512-13-5:2006-02
Test force
20 N
Contact retention in insert
Test passed
Specification
IEC 60512-15-1:2008-05
Test force per pos.
42 N
10.1
Termination and connection method
IEC 60999-1:1999-11
Check for damage to conductor or loosening
Test passed
10.2
Specification
Pull-out test
Termination and connection method: pull-out test
IEC 60999-1:1999-11
Result
Test passed
Specification
Conductor cross section/conductor type/tractive force actual value
0.2 mm² / solid / > 10 N
Conductor cross section/conductor type/tractive force actual value
0.2 mm² / stranded / > 10 N
4 mm² / solid / > 60 N
Conductor cross section/conductor type/tractive force actual value
4 mm² / stranded / > 60 N
© PHOENIX CONTACT 2017
Conductor cross section/conductor type/tractive force actual value
REF 1804904
PHOENIX CONTACT 7 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
11
Electrical tests
11.1
Electrical data
Rated current / conductor cross section
Document revision 0
20 A / 4 mm²
Rated insulation voltage (III/2)
630 V
Rated surge voltage (III/2)
6 kV
Contact resistance
0.5 mΩ
Degree of pollution
2
11.2
Air and creepage distances
Component
Plug component
Specification
IEC 60664-1:2007-04
Mains type
unearthed mains
Insulating material group
I
CTI 600
Rated insulation voltage
400 V
630 V
1000 V
Rated surge voltage
6 kV
6 kV
6 kV
Degree of pollution
3
2
2
Overvoltage category
III
III
II
Minimum clearance case A (inhomogeneous field)
5.5 mm
5.5 mm
5.5 mm
Minimum value of the creepage path requirement in acc. with table
5.5 mm
5.5 mm
5.5 mm
© PHOENIX CONTACT 2017
Comparative tracking index (IEC 60112:2003-01)
REF 1804904
PHOENIX CONTACT 8 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
12
Document revision 0
Current carrying capacity/derating curves
Specification
IEC 61984:2008-10
Note
Representation based on IEC 60512-5-2:2002-02
Reduction factor
0.8
Number of positions
See diagram
Conductor cross section
4 mm²
Current carrying capacity [A]
Type: PC 4/...-ST-7,62 with PC 4/...-G-7,62
40
35
30
25
20
15
10
5
0
2
3
1 = 2-pos.
2 = 5-pos.
3 = 12-pos.
0
20
1
40
60
80
100
© PHOENIX CONTACT 2017
Ambient temperature [°C]
REF 1804904
PHOENIX CONTACT 9 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
13
Environmental and durability tests
13.1
Vibration test
Document revision 0
Specification
IEC 60068-2-6:2007-12
Result
Test passed
Frequency
10 - 150 - 10 Hz
Sweep speed
1 octave/min
Amplitude
0.35 mm (10 - 60.1 Hz)
Acceleration
5 g (60.1 - 150 Hz)
Test duration per axis
2.5 h
Test directions
X-, Y- and Z-axis
14
Classification for connectors
Specification
IEC 61984:2008-10
Main features
Connectors without switching capacity (COC)
Construction form
Fixed connectors
Strain relief elements
without strain relief
Connection method
Can be reconnected
Protection against electric shock
not encapsulated - back of hand safety when plugged in
Protective conductor
without PE
Lock
no
Connection method
Screw terminal points
Approvals
15
CSA
Use group
B
C
mm²/AWG/kcmil
28-10
28-10
300 V
300 V
Current
20 A
20 A
Use group
B
C
D
mm²/AWG/kcmil
30-10
30-10
30-10
Voltage
300 V
300 V
600 V
Current
20 A
20 A
5A
Voltage
UL Recognized
Use group
B
C
D
mm²/AWG/kcmil
30-10
30-10
30-10
Voltage
300 V
300 V
600 V
Current
20 A
20 A
5A
© PHOENIX CONTACT 2017
cUL Recognized
BV
RS
REF 1804904
PHOENIX CONTACT 10 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
Document revision 0
EAC
© PHOENIX CONTACT 2017
cULus Recognized
REF 1804904
PHOENIX CONTACT 11 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
16
Document revision 0
Commercial Data
Order No.
1804959
Type
PC 4/ 7-ST-7,62
Pieces per package
50
Net weight
28.287 g
GTIN
4017918046392
Information that applies locally, see link on page 1
Country of origin
17
Information that applies locally, see link on page 1
corresponding headers
Order No.
Type
1804739
PCV 4/ 7-G-7,62
1804849
PC 4/ 7-G-7,62
18
Accessories
Description
Order No.
Type
Coding profile, for plugging into the coding ribs of the plug at a later date,
insulating material, color: Red
1701967
CP-PC RD
0804549
Actuation tool, for ST terminal blocks, insulated, also suitable for use as a 1205053
bladed screwdriver, size: 0.6 x 3.5 x 100 mm, 2-component grip, with nonslip grip
SK 7,62/3,8:SO
© PHOENIX CONTACT 2017
0805153
SK 7,62/3,8:FORTL.ZAHLEN
SZS 0,6X3,5
REF 1804904
PHOENIX CONTACT 12 / 13
2017-10-24
Product version 04
1804959 PC 4/ 7-ST-7,62
19
Document revision 0
Combination tests
PC 4/..-ST
PC 4/..-G
PCV 4/..-G
DFK-PC 4/..-G FS4,8
Specification
IEC 61984
IEC 61984
IEC 61984
Mechanical tests (A)
Insertion/withdrawal force per position
approx. 8 N / 5 N
Polarization when inserted
Requirement >20 N
Test passed
Contact holder in insert
Requirements >20 N
Test passed
Durability tests (B)
0.5 mΩ
Insertion/withdrawal cycles
50
Contact resistance R2
0.6 mΩ
Rated impulse voltage at sea level
Voltage waveform ≥ (1.2/50 μs)
7.3 kV
Power-frequency withstand voltage
Voltage waveform ≥ (50/60 Hz)
3.31 kV
Insulation resistance
Requirements > 5 MΩ
12 TΩ
Contact resistance R1
Tested number of positions
12
Tested conductor cross section
4 mm²
Test current
20 A
Upper limiting temperature
Requirements < 100°C
Test passed
Thermal tests (C)
Climatic tests (D)
-40 °C/2 h
Test sequence 2: heat storage
100 °C/168 h
Test sequence 3: noxious gas storage
(ISO 6988)
0.2 dm3 SO2 on 300 dm3/
40 °C/1 cycle
Rated impulse voltage at sea level
Voltage waveform ≥ (1.2/50 μs)
7.3 kV
Power-frequency withstand voltage
Voltage waveform ≥ (50/60 Hz)
3.31 kV
Test sequence 1: low temperature storage
Specification
IEC 61984:2008-10
Degree of protection
Back of hand safety with
IP10 access probe
REF 1804904
PHOENIX CONTACT GmbH & Co. KG • 32823 Blomberg • Germany
phoenixcontact.com
© PHOENIX CONTACT 2017
Environmental and endurance tests (E)
PHOENIX CONTACT 13 / 13
