Printed-circuit board connector - MC 1,5/ 3-ST-3,5 - 1840379
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Plug component, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 3, Pitch: 3.5 mm,
Connection method: Screw connection, Color: green, Contact surface: Tin
The figure shows a 10-position
version of the product
Product Features
Generously dimensioned wiring space
Plug-in direction parallel to the conductor axis
Low design height of the MC 1,5 plug range
Individual position coding by removing the coding tab and connecting the coding profile to the header
Key Commercial Data
Packing unit
1 pc
GTIN
Weight per Piece (excluding packing)
2.35 g
Custom tariff number
85366990
Country of origin
United States
Technical data
Dimensions
Height
11.1 mm
Width
10.5 mm
Pitch
3.50 mm
Dimension a
7 mm
General
Range of articles
MC 1,5/..-ST
11/15/2015 Page 1 / 6
https://www.phoenixcontact.com/us/products/1840379
Printed-circuit board connector - MC 1,5/ 3-ST-3,5 - 1840379
Technical data
General
Insulating material group
I
Rated surge voltage (III/3)
2.5 kV
Rated surge voltage (III/2)
2.5 kV
Rated surge voltage (II/2)
2.5 kV
Rated voltage (III/3)
160 V
Rated voltage (III/2)
160 V
Rated voltage (II/2)
320 V
Connection in acc. with standard
EN-VDE
Nominal current IN
8A
Nominal cross section
1.5 mm²
Maximum load current
8 A (with 1.5 mm² conductor cross section)
Insulating material
PA
Flammability rating according to UL 94
V0
Internal cylindrical gage
A1
Stripping length
7 mm
Number of positions
3
Screw thread
M2
Tightening torque, min
0.22 Nm
Tightening torque max
0.25 Nm
Connection data
Conductor cross section solid min.
0.14 mm²
Conductor cross section solid max.
1.5 mm²
Conductor cross section flexible min.
0.14 mm²
Conductor cross section flexible max.
1.5 mm²
Conductor cross section flexible, with ferrule without plastic sleeve min.
0.25 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max.
1.5 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min.
0.25 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max.
0.5 mm²
Conductor cross section AWG min.
28
Conductor cross section AWG max.
16
2 conductors with same cross section, solid min.
0.08 mm²
2 conductors with same cross section, solid max.
0.5 mm²
2 conductors with same cross section, stranded min.
0.08 mm²
2 conductors with same cross section, stranded max.
0.75 mm²
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
0.25 mm²
11/15/2015 Page 2 / 6
https://www.phoenixcontact.com/us/products/1840379
Printed-circuit board connector - MC 1,5/ 3-ST-3,5 - 1840379
Technical data
Connection data
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
0.34 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, max.
Minimum AWG according to UL/CUL
30
Maximum AWG according to UL/CUL
14
Standards and Regulations
Connection in acc. with standard
EN-VDE
CSA
Flammability rating according to UL 94
V0
Classifications
eCl@ss
eCl@ss 4.0
272607xx
eCl@ss 4.1
27260701
eCl@ss 5.0
27260701
eCl@ss 5.1
27260701
eCl@ss 6.0
27260704
eCl@ss 7.0
27440402
eCl@ss 8.0
27440309
ETIM
ETIM 3.0
EC001121
ETIM 4.0
EC002638
ETIM 5.0
EC002638
UNSPSC
UNSPSC 6.01
30211810
UNSPSC 7.0901
39121409
UNSPSC 11
39121409
UNSPSC 12.01
39121409
UNSPSC 13.2
39121409
Approvals
Approvals
11/15/2015 Page 3 / 6
https://www.phoenixcontact.com/us/products/1840379
Printed-circuit board connector - MC 1,5/ 3-ST-3,5 - 1840379
Approvals
Approvals
CSA / VDE Gutachten mit Fertigungsüberwachung / IECEE CB Scheme / CCA / EAC / cULus Recognized
Ex Approvals
Approvals submitted
Approval details
CSA
B
D
mm²/AWG/kcmil
28-16
28-16
Nominal current IN
8A
8A
Nominal voltage UN
300 V
300 V
VDE Gutachten mit Fertigungsüberwachung
mm²/AWG/kcmil
0.2-1.5
Nominal current IN
8A
Nominal voltage UN
160 V
IECEE CB Scheme
mm²/AWG/kcmil
0.2-1.5
Nominal current IN
8A
Nominal voltage UN
160 V
11/15/2015 Page 4 / 6
https://www.phoenixcontact.com/us/products/1840379
Printed-circuit board connector - MC 1,5/ 3-ST-3,5 - 1840379
Approvals
CCA
mm²/AWG/kcmil
0.2-1.5
Nominal current IN
8A
Nominal voltage UN
160 V
EAC
cULus Recognized
B
D
mm²/AWG/kcmil
30-14
30-14
Nominal current IN
8A
8A
Nominal voltage UN
300 V
300 V
Drawings
16
14
12
10
8
6
4
2
0
#
!=2-pos.
"=5-pos.
#=12-pos.
$=20-pos.
0
10
20
30
Diagram
40
50
60
!
"
$
70
80
Current strength [A]
Current strength [A]
Diagram
16
14
12
10
8
6
4
2
0
= 2-pos.
= 5-pos.
= 12-pos.
0
90 100 110
20
40
Type: MC 1,5/...-ST-3,5 with MCV 1,5/...-G-3,5
20
Current strength [A]
Current strength [A]
40
60
80
100
Ambient temperature [°C]
Type: MC 1,5/...-ST-3,5 with MC 1,5/...-G-3,5
100
Diagram
= 2-pos.
= 5-pos.
= 12-pos.
= 20-pos.
0
80
Type: MC 1,5/...-ST(F)-3,5 with MCV 1,5/...-G(F)-3,5 P... THR
Diagram
16
14
12
10
8
6
4
2
0
60
Ambient temperature [°C]
Ambient temperature [°C]
16
14
12
10
8
6
4
2
0
= 2-pos.
= 5-pos.
= 12-pos.
0
20
40
60
80
100
Ambient temperature [°C]
Type: MC 1,5/...-ST(F)-3,5 with MC 1,5/...-G(F)-3,5 P.. THR
11/15/2015 Page 5 / 6
https://www.phoenixcontact.com/us/products/1840379
Printed-circuit board connector - MC 1,5/ 3-ST-3,5 - 1840379
Dimensional drawing
16,1
11,1
a+3,5
6,6
1,75
3,5
a
