Printed-circuit board connector - MCV 1,5/ 3-G-3,5 - 1843619
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB headers, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 3, pitch: 3.5 mm, color:
green, contact surface: Tin, mounting: Wave soldering
The figure shows a 10-position
version of the product
Your advantages
Well-known mounting principle allows worldwide use
Vertical connection enables multi-row arrangement on the PCB
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Key Commercial Data
Packing unit
1 pc
GTIN
GTIN
4017918112769
Weight per Piece (excluding packing)
0.980 g
Custom tariff number
85366930
Country of origin
Germany
Technical data
Dimensions
Length [ l ]
7.25 mm
Width
11.9 mm
Pitch
3.5 mm
Dimension a
7 mm
Width [ w ]
11.9 mm
03/29/2019 Page 1 / 7
https://www.phoenixcontact.com/us/products/1843619
Printed-circuit board connector - MCV 1,5/ 3-G-3,5 - 1843619
Technical data
Dimensions
Height [ h ]
12.6 mm
Height
9.2 mm
Length of the solder pin
3.4 mm
Pin dimensions
0.8 x 0.8 mm
Length
7.25 mm
General
Range of articles
MCV 1,5/..-G
Insulating material group
IIIa
Rated surge voltage (III/3)
2.5 kV
Rated surge voltage (III/2)
2.5 kV
Rated surge voltage (II/2)
2.5 kV
Rated voltage (III/3)
160 V
Rated voltage (III/2)
160 V
Rated voltage (II/2)
250 V
Connection in acc. with standard
EN-VDE
Nominal current IN
8A
Maximum load current
8A
Insulating material
PBT
Flammability rating according to UL 94
V0
Color
green
Number of positions
3
Standards and Regulations
Connection in acc. with standard
EN-VDE
CSA
Flammability rating according to UL 94
V0
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Drawings
03/29/2019 Page 2 / 7
https://www.phoenixcontact.com/us/products/1843619
Printed-circuit board connector - MCV 1,5/ 3-G-3,5 - 1843619
Drilling diagram
Diagram
16
14
12
10
8
6
4
2
0
3
Ø1,2
Current strength [A]
2,45
(2,6)
a
3,5
(3,81)
#
!=2-pos.
"=5-pos.
#=12-pos.
$=20-pos.
0
10
20
30
40
50
60
!
"
$
70
80
90 100 110
Ambient temperature [°C]
Type: MC 1,5/...-ST-3,5 with MCV 1,5/...-G-3,5
16
14
12
10
8
6
4
2
0
Dimensional drawing
11,1
a+4,9
18,7
= 2-pos.
= 5-pos.
= 16-pos.
0
20
9,2
Current strength [A]
Diagram
40
60
80
100
3,4
Ambient temperature [°C]
3
7,25
2,45
3,5
a
Type: MCVW 1,5/...-ST-3,5 with MCV 1,5/...-G-3,5
Classifications
eCl@ss
eCl@ss 4.0
272607xx
eCl@ss 4.1
27260701
eCl@ss 5.0
27260701
eCl@ss 5.1
27260700
eCl@ss 6.0
27260700
eCl@ss 7.0
27440402
eCl@ss 8.0
27440402
eCl@ss 9.0
27440402
ETIM
ETIM 3.0
EC001121
ETIM 4.0
EC002637
ETIM 5.0
EC002637
ETIM 6.0
EC002637
03/29/2019 Page 3 / 7
