Base strip - MC 1,5/16-GF-3,5 - 1843936
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Header, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 16, pitch: 3.5 mm, color: green,
contact surface: Tin, mounting: Wave soldering
The figure shows a 10-position
version of the product
Why buy this product
Well-known mounting principle allows worldwide use
Screwable flange for superior mechanical stability
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Key Commercial Data
Packing unit
1 STK
GTIN
GTIN
4017918113049
Weight per Piece (excluding packing)
5.130 g
Custom tariff number
85366930
Country of origin
Germany
Technical data
Dimensions
Length [ l ]
9.2 mm
Pitch
3.5 mm
Dimension a
52.5 mm
Width [ w ]
66.35 mm
Constructional height
7.25 mm
01/06/2018 Page 1 / 7
https://www.phoenixcontact.com/us/products/1843936
Base strip - MC 1,5/16-GF-3,5 - 1843936
Technical data
Dimensions
Height [ h ]
10.65 mm
Length of the solder pin
3.4 mm
Pin dimensions
0,8 x 0,8
Hole diameter
1.2 mm
General
Range of articles
MC 1,5/..-GF
Insulating material group
IIIa
Rated surge voltage (III/3)
2.5 kV
Rated surge voltage (III/2)
2.5 kV
Rated surge voltage (II/2)
2.5 kV
Rated voltage (III/3)
160 V
Rated voltage (III/2)
160 V
Rated voltage (II/2)
250 V
Connection in acc. with standard
EN-VDE
Nominal current IN
8A
Maximum load current
8A
Insulating material
PBT
Flammability rating according to UL 94
V0
Color
green
Number of positions
16
Standards and Regulations
Connection in acc. with standard
EN-VDE
CSA
Flammability rating according to UL 94
V0
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category
“Manufacturer's declaration”
Drawings
01/06/2018 Page 2 / 7
https://www.phoenixcontact.com/us/products/1843936
Base strip - MC 1,5/16-GF-3,5 - 1843936
16
14
12
10
8
6
4
2
0
Dimensional drawing
18,7
a+13,8
0
10
20
30
40
50
60
70
80
7,1
90 100 110
3,4
= 2-pos.
= 5-pos.
= 12-pos.
= 20-pos.
7,25
9,2
11,1
Current strength [A]
Diagram
3,5
4,3
a
8
Ambient temperature [°C]
Type: FK-MCP 1,5/...-STF-3,5 with MC 1,5/...-GF-3,5
Drilling diagram
Diagram
Current strength [A]
a
2,4
6,9
8
0,9
4,3
16
14
12
10
8
6
4
2
0
= 2-pos.
= 5-pos.
= 12-pos.
= 20-pos.
0
1,2
20
40
60
80
100
Ambient temperature [°C]
Type: MC 1,5/...-STF-3,5 with MC 1,5/...-GF-3,5
Classifications
eCl@ss
eCl@ss 4.0
272607xx
eCl@ss 4.1
27260701
eCl@ss 5.0
27260701
eCl@ss 5.1
27260701
eCl@ss 6.0
27260704
eCl@ss 7.0
27440402
eCl@ss 8.0
27440402
eCl@ss 9.0
27440402
ETIM
ETIM 3.0
EC001121
ETIM 4.0
EC002637
ETIM 5.0
EC002637
ETIM 6.0
EC002637
01/06/2018 Page 3 / 7
https://www.phoenixcontact.com/us/products/1843936
Base strip - MC 1,5/16-GF-3,5 - 1843936
Classifications
UNSPSC
UNSPSC 6.01
30211810
UNSPSC 7.0901
39121409
UNSPSC 11
39121409
UNSPSC 12.01
39121409
UNSPSC 13.2
39121409
Approvals
Approvals
Approvals
CSA / VDE Gutachten mit Fertigungsüberwachung / IECEE CB Scheme / CCA / cULus Recognized / EAC
Ex Approvals
Approval details
CSA
http://www.csagroup.org/services-industries/product-listing/
B
D
Nominal current IN
8A
8A
Nominal voltage UN
300 V
300 V
VDE Gutachten mit
Fertigungsüberwachung
http://www.vde.com/en/Institute/OnlineService/
VDE-approved-products/Pages/Online-Search.aspx
Nominal current IN
8A
Nominal voltage UN
160 V
IECEE CB Scheme
http://www.iecee.org/
Nominal current IN
8A
13631
40011723
DE1-59621-B1B2
01/06/2018 Page 4 / 7
https://www.phoenixcontact.com/us/products/1843936
Base strip - MC 1,5/16-GF-3,5 - 1843936
Approvals
Nominal voltage UN
160 V
CCA
CCA/ DE1 34219
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
E60425-20110128
Nominal current IN
8A
Nominal voltage UN
160 V
cULus Recognized
B
D
Nominal current IN
8A
8A
Nominal voltage UN
300 V
300 V
EAC
B.01742
Accessories
Accessories
Coding element
Coding profile - CP-MSTB - 1734634
Coding profile, is inserted into the slot on the plug or inverted header, red insulating material
Fiber optics
Fiber optics - MC 1,5/10-LWL 1,5-3,5 - 1841161
01/06/2018 Page 5 / 7
https://www.phoenixcontact.com/us/products/1843936
Base strip - MC 1,5/16-GF-3,5 - 1843936
Accessories
Fiber optics - MC 1,5/10-LWL 2,3-3,5 - 1841187
Fiber optics - MC 1,5/10-LWL 4-3,5 - 1841200
Labeled terminal marker
Marker card - SK 3,5/2,8:FORTL.ZAHLEN - 0804073
Marker card, Card, white, labeled, Horizontal: Consecutive numbers 1 - 10, 11 - 20, etc. up to 91 - 99, mounting type:
adhesive, for terminal block width: 3.5 mm, lettering field size: 3.5 x 2.8 mm
Additional products
Printed-circuit board connector - MC 1,5/16-STF-3,5 - 1847262
Plug component, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 16, pitch: 3.5 mm, connection
method: Screw connection with tension sleeve, color: green, contact surface: Tin
Printed-circuit board connector - MCVW 1,5/16-STF-3,5 - 1863149
Plug component, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 16, pitch: 3.5 mm, connection
method: Screw connection with tension sleeve, color: green, contact surface: Tin
01/06/2018 Page 6 / 7
https://www.phoenixcontact.com/us/products/1843936
Base strip - MC 1,5/16-GF-3,5 - 1843936
Accessories
Plug - MCVR 1,5/16-STF-3,5 - 1863440
Plug component, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 16, pitch: 3.5 mm, connection
method: Screw connection with tension sleeve, color: green, contact surface: Tin
Printed-circuit board connector - FK-MCP 1,5/16-STF-3,5 - 1940237
Plug component, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 16, pitch: 3.5 mm, connection
method: Push-in spring connection, color: green, contact surface: Tin
Printed-circuit board connector - FMC 1,5/16-STF-3,5 - 1966237
Plug component, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 16, pitch: 3.5 mm, connection
method: Push-in spring connection, color: green, contact surface: Tin
Phoenix Contact 2018 © - all rights reserved
http://www.phoenixcontact.com
01/06/2018 Page 7 / 7
