MS-104-3-3

PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Micro Reed Sensor • pitch 11.40 mm Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF A 10 0.5 0.7 150 120 200 200 109 0.4 MS-104-3 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 10-25 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 0.3 0.1 600 12,000 10 50 -20 to +85 Dimensions in mm R 1.35 typ. 11.4 2.7 -0.1 2.8 -0.1 2.9 +0.5/-0.3 10.16 0.4 0.4 Ordering Information Series MS-104-3 AT Range 1 = 10-15 / 2 = 15-20 / 3 = 20-25 Ordering example: MS-104-3-2 describes MS-104-3 with 15-20 AT Customized types available.  PIC GmbH, Nürnberg (GERMANY) ms1043_e Rev. 2.2 (003) Page 1 of 1
