MS-214-3-3

MS-214-3 Miniature Reed Sensor Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF A 10 0.7 1.0 180 130 200 100 109 0.5 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 10-25 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 0.5 0.3 500 5,000 20 50 -40 to +85 Dimensions in mm 25.2 ±0.3 Ø 3.8 ±0.1 500 Wire: AWG 26, black, stripped and tinned Ordering Information Series MS-214-3 AT Range 1 = 10-15 / 2 = 15-20 / 3 = 20-25 Ordering example: MS-214-3-2 describes MS-214-3 with 15-20 AT Customized types available. © PIC GmbH, Nürnberg (GERMANY) www.pic-gmbh.com ms2143_e Rev. 2.2, 17.07.2008, (014) Page 1 of 1
