MS-217-4-4

PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com MS-217-4 Form C Reed Sensor Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF C 5 0.25 1.5 175 120 200 100 109 1.0 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 10-30 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 0.7 1.0 100 1,100 30 50 -20 to +85 Dimensions in mm 40.1 ±0.3 COM black NC brown NO red Ø 6.0 ±0.1 500 Wire: AWG 24, stripped and tinned Ordering Information Series MS-217-4 AT Range 1 = 10-15 / 2 = 15-20 / 3 = 20-25 / 4 = 25-30 Ordering example: MS-217-4-2 describes MS-217-4 with 15-20 AT Customized types available. © PIC GmbH, Nürnberg (GERMANY) ms2174_e Rev. 1.1, 08.11.2007, (014) Page 1 of 1
