MS-225-3-2

PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Miniature Reed Sensor • M5 metal thread Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF A 10 0.7 1.0 180 130 200 100 109 0.5 MS-225-3 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 10-25 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 0.5 0.3 500 5,000 20 50 -20 to +85 Dimensions in mm M5 x 0.5 4.1 ±0.2 24.9 ±0.3 500 Wire: AWG 26, black, stripped and tinned Ordering Information Series MS-225-3 AT Range 1 = 10-15 / 2 = 15-20 / 3 = 20-25 Ordering example: MS-225-3-2 describes MS-225-3 with 15-20 AT Customized types available.  PIC GmbH, Nürnberg (GERMANY) ms2253_e Rev. 2.1 (003) Page 1 of 2 PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Miniature Reed Sensor • M5 metal thread Matching Actuator MSM-225 in mm M5 x 0.5 4.1 ±0.2 MS-225-3 Pb Lead free 24.9 ±0.3 Customized types and other magnet orientations available.  PIC GmbH, Nürnberg (GERMANY) ms2253_e Rev. 2.1 (003) Page 2 of 2
