MS-324-3

PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Miniature Reed Sensor • Flatpack Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF A 10 1.0 1.2 200 140 240 100 1010 0.5 MS-324-3 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 10-25 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 1.0 0.4 500 4,000 20 100 -20 to +85 Dimensions in mm 23.0 ±0.2 14.0 5.9 ±0.1 13.9 ±0.1 3.0 6.5 500 4.0 2.9 3.1 Wire: AWG 24, black, stripped and tinned Ordering Information Series MS-324-3 AT Range 1 = 10-15 / 2 = 15-20 / 3 = 20-25 Ordering example: MS-324-3-2 describes MS-324-3 with 15-20 AT Customized types available.  PIC GmbH, Nürnberg (GERMANY) ms3243_e Rev. 1.0 (003) Page 1 of 2 PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Miniature Reed Sensor • Flatpack Matching Actuator MSM-324 in mm 23.0 ±0.2 14.0 5.9 ±0.1 MS-324-3 Pb Lead free 13.9 ±0.1 3.0 6.5 3.1 4.0 2.9 Customized types and other magnet orientations available.  PIC GmbH, Nürnberg (GERMANY) ms3243_e Rev. 1.0 (003) Page 2 of 2
