MS-324-4-4

Form C Reed Sensor • Flatpack Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF C 5 0.25 1.5 175 120 200 100 109 1.0 MS-324-4 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 15-30 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 0.7 1.0 100 1,100 30 50 -20 to +85 Dimensions in mm 23.0 ±0.2 14.0 5.9 ±0.1 13.9 ±0.1 3.0 6.5 500 3.1 COM black NC white NO grey 4.0 2.9 Wire: UL1007 AWG 26, stripped and tinned Ordering Information Series MS-324-4 AT Range 2 = 15-20 / 3 = 20-25 / 4 = 25-30 Ordering example: MS-324-4-2 describes MS-324-4 with 15-20 AT Customized types available. © PIC GmbH, Nürnberg (GERMANY) www.pic-gmbh.com Page 1 of 2 Rev. 1.2, 12.01.2009, (014) Form C Reed Sensor • Flatpack Matching Actuator MSM-324 in mm 23.0 ±0.2 14.0 5.9 ±0.1 MS-324-4 Pb Lead free 13.9 ±0.1 3.0 6.5 3.1 4.0 2.9 Customized types and other magnet orientations available. © PIC GmbH, Nürnberg (GERMANY) www.pic-gmbh.com Page 2 of 2 Rev. 1.2, 12.01.2009, (014)
