PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com
Form C Reed Sensor • Flatpack Electrical Characteristics
Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF C 5 0.25 1.5 175 120 200 100 109 1.0
MS-328-4
Pb
Lead free
Magnetical Characteristics
Pull in range available
1 1
AT
15-30
AT range stated for unmodified Reed Switch
Operating Characteristics
Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 0.7 1.0 100 1,100 30 50 -20 to +85
Dimensions
in mm
28.5 ±0.2 15.9 6.3 ±0.2
19.0 ±0.2 3.2 9.5
COM black NC white NO grey
4.7
500
8.0
3.4
Wire: AWG 22, stripped and tinned
Ordering Information
Series MS-328-4 AT Range 2 = 15-20 / 3 = 20-25 / 4 = 25-30
Ordering example: MS-328-4-2 describes MS-328-4 with 15-20 AT
Customized types available.
© PIC GmbH, Nürnberg (GERMANY)
ms3284_e Rev. 1.2, 08.11.2007, (014)
Page 1 of 2
PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com
Form C Reed Sensor • Flatpack Matching Actuator MSM-328
in mm
28.5 ±0.2 15.9 6.3 ±0.2
MS-328-4
Pb
Lead free
19.0 ±0.2 3.2 9.5
4.7
8.0
3.4
Customized types and other magnet orientations available.
© PIC GmbH, Nürnberg (GERMANY)
ms3284_e Rev. 1.2, 08.11.2007, (014)
Page 2 of 2
