MS-328-5-3

PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Mains switching Reed Sensor • Flatpack Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF A 10 0.5 1.5 200 260 450 100 1010 0.2 MS-328-5 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 20-35 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 0.6 0.4 500 4,000 20 100 -20 to +85 Dimensions in mm 28.5 ±0.2 15.9 6.3 ±0.2 19.0 ±0.2 4.7 9.5 3.2 500 8.0 3.4 Wire: AWG 20, black, stripped and tinned Ordering Information Series MS-328-5 AT Range 3 = 20-25 / 4 = 25-30 / 5 = 30-35 Ordering example: MS-328-5-3 describes MS-328-5 with 20-25 AT Customized types available.  PIC GmbH, Nürnberg (GERMANY) ms3285_e Rev. 1.1 (004) Page 1 of 2 PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Mains switching Reed Sensor • Flatpack Matching Actuator MSM-328 in mm 28.5 ±0.2 15.9 6.3 ±0.2 MS-328-5 Pb Lead free 19.0 ±0.2 4.7 9.5 3.2 8.0 3.4 Customized types and other magnet orientations available.  PIC GmbH, Nürnberg (GERMANY) ms3285_e Rev. 1.1 (004) Page 2 of 2
