MS-332-5-6

PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Power Reed Sensor • Flatpack Electrical Characteristics Contact form Contact rating max. Switching current max. Carry current max. Switching voltage max. Breakdown voltage min. Contact resistance (initial) max. Insulation resistance min. Capacitance typ. W / VA A A VDC VAC VDC mΩ Ω pF A 50 1.5 2.0 200 250 400 100 1010 0.5 MS-332-6 Pb Lead free Magnetical Characteristics Pull in range available 1 1 AT 25-40 AT range stated for unmodified Reed Switch Operating Characteristics Operate time (incl. bounce) max. Release time max. Switching frequency max. Resonant frequency typ. Vibration (50-2000 Hz) Shock (1/2 sin 11 ms) Operating temperature ms ms Hz Hz g g °C 1.0 0.4 300 2,600 20 50 -20 to +85 Dimensions in mm 8.0 4.2 x 3.2 3.2 3.6 ±0.2 6.0 ±0.2 10.0 ±0.2 24.0 ±0.2 500 32.0 ±0.2 3.6 ±0.2 5.5 ±0.2 Wire: AWG 20, black, stripped and tinned Ordering Information Series MS-332-5 AT Range 4 = 25-30 / 5 = 30-35 / 6 = 35-40 Ordering example: MS-332-6-4 describes MS-332-6 with 25-30 AT Customized types available.  PIC GmbH, Nürnberg (GERMANY) ms3326_e Rev. 1.0 (004) Page 1 of 2 PIC GmbH • Nibelungenstr. 5A 90530 Wendelstein, Germany Phone +49 911 99 59 06-0 Fax +49 911 99 59 06-99 info@pic-gmbh.com • www.pic-gmbh.com Power Reed Sensor • Flatpack Matching Actuator MSM-332 in mm 8.0 4.2 x 3.2 3.2 3.6 ±0.2 6.0 ±0.2 MS-332-6 Pb Lead free 10.0 ±0.2 24.0 ±0.2 32.0 ±0.2 3.6 ±0.2 5.5 ±0.2 Customized types and other magnet orientations available.  PIC GmbH, Nürnberg (GERMANY) ms3326_e Rev. 1.0 (004) Page 2 of 2
