PM-6106

10/100 Base-TX SINGLE PORT MAGNETIC MODULES Smallest SOIC Transformer Ê Meets all IEEE 802.3 and ANSI X3.263 standard including 350 uH OCL with 8 mADC Bias Ë Compact footprint for use in the most spacerestrictive applications O ELECTRICAL SPECIFICATIONS AT 25OC - OPERATING TEMPERATURE RANGE 0 C TO +70OC Turn Ratio PART NUMBER TX RX PM-6101 PM-6102 PM-6103 PM-6104 PM-6105 PM-6106 PM-6107 1:1 1:1 2:1 1:1 1.41:1 1.25:1 1:1.41 1:1 1:1 1:1 2:1 1:1 1:1 1:1 Return Loss INSERTION LOSS (dB TYP) (dB Max) 30 60 80 100KHz to MHz MHz MHz 100MHz Diff. to Com Mode Rejection (dB Min) 30 50 100 30 MHz MHz MHz MHz Crosstalk (dB Min) 60 100 MHz MHz Schematic HI-POT (Vrms) 1.1 1.1 1.1 1.1 1.1 1.1 1.1 -20 -20 -20 -20 -20 -20 -18 -14 -14 -14 -14 -14 -14 -12 -11.5 -11.5 -11.5 -11.5 -11.5 -11.5 -11.5 -42 -42 -42 -42 -42 -42 -42 -37 -37 -37 -37 -37 -37 -37 -33 -33 -33 -33 -33 -33 -30 -45 -45 -45 -45 -45 -45 -45 -40 -40 -40 -40 -40 -40 -40 -35 -35 -35 -35 -35 -35 -35 A B B B B B B 1500 1500 1500 1500 1500 1500 1500 SCHEMATIC "A" TRANSMIT 1 2 3 RECEIVE 6 7 8 11 10 9 6 7 8 16 15 14 1 2 3 SCHEMATIC "B" TRANSMIT 16 15 14 RECEIVE 11 10 9 MECHANICAL 16 15 14 13 12 11 10 9 All Dimensions in inches (mm) Unless otherwise specified, all tolerances are ± 0.010 (0.25) PCB LAYOUT .420 (10.67) P PM-61xx M YYWW PIN #1 I.D. 1 2 3 4 5 6 7 8 0.285 (7.24) MAX 0.235 (5.97) .019 (0.48) TYP 0.050 (1.27) TYP 0.035 (0.89) 0.37 (9.40) 0.500 (12.70) MAX 16x.075 (1.91) .270 (6.86) 1 16x.025 (.64) 16 7x.050 (1.27) .350 (8.89) 8 0.020 (0.05) TYP 9 0.350 (8.89) .015 (0.38) Specifications subject to change without notice. pm-61xx 11/00 20381 BARENTS SEA CIRCLE, LAKE FOREST, CA 92630 • TEL: (949) 452-0511 • FAX: (949) 452-0512 • http://www.premiermag.com 1
