PM-DC05105

2.0 WATT DC-DC CONVERTER Unregulated, 16 Pins SMD FEATURES – — ˜ ™ Up to 1.8 Watts Output Power 16Pins SMD Package 2000 Vdc Unregulated Output Types ELECTRICAL SPECFICATIONS q q q q Input Voltage Range............................ ± 5% Output Voltage Tolerance.................. ± 5% Line Regulation (10% To 100% F.L)........ ±1.2% Load Regulation (10% To 100% F.L).... ±10% GENERAL SPECIFICATIONS q Output Ripple & Noise.......................... 100mVp-p(20MHz B.W.) q Isolation Resistance ............................. 100MΩ Min @500VDC q Switching Frequency............................ 100KHz TYP q Operating Temperature....................... 0 °C To +70 °C q Efficiency (Unregulated)...................... 70% TYP q Short Circuit Protection........................ Short Term ELECTRICAL SPECIFICATIONS AT 25OC - OPERATING TEMPERATURE RANGE 0OC TO +70OC PART NUMBER PM-DC05105 PM-DC05109 PM-DC05112 PM-DC05115 PM-DC12105 PM-DC12109 PM-DC12112 PM-DC12115 PACKAGE PHYSICAL DIMENSIONS .... DIMENSIONS IN INCH (mm) INPUT VOLTAGE (Vdc) OUTPUT VOLTAGE (Vdc) OUTPUT CURRENT (mA max.) EFFICIENCY (%) 5.0 5.0 5.0 5.0 12.0 12.0 12.0 12.0 5.0 9.0 12.0 15.0 5.0 9.0 12.0 15.0 360 200 150 120 360 200 150 120 70 75 75 75 70 75 75 75 PIN#1 DOT P PMDCxxxxx M YYWW 0.500 (12.70) 0.090 X16 (2.29) 0.540 (13.72) 1.000 (25.40) 0.385 (9.78) 0.100 (2.54) 0.040 X16 (1.02) 0.700 (17.78) SUGGESTED PAD LAYOUT 0.400 (10.16) MAX 0° - 8° 0.018 X16 (0.46) 0.040 X16 (1.02) 0.100 X7 (2.54) 0.004 (0.10) PIN 1 2 3 7 8 OTHER SINGLE OUTPUT - INPUT N.C + INPUT + OUTPUT - OUTPUT N.C 0.700 (17.78) Specifications subject to change without notice. PM-DCXXXXX 9/2000 20381 BARENTS SEA CIRCLE, LAKE FOREST, CA 92630 • TEL: (949) 452-0511 • FAX: (949) 452-0512 • http://www.premiermag.com 1 2.0 WATT DC-DC CONVERTER Unregulated, 16 Pins SMD FEATURES – Up to 1.8 Watts Output Power — 16Pins SMD Package ˜ 2000 Vdc ELECTRICAL SPECFICATIONS q Input Voltage Range............................ ± 5% q Output Voltage Tolerance.................. ± 5% q Line Regulation .......................................... 8% q Load Regulation ...................................... 12% GENERAL SPECIFICATIONS q Input Filter.............................................. Capacitor Type q Output Ripple & Noise........................ 100mVp-p(20MHz B.W.) q Isolation Resistance ............................ 100MΩ Min @500VDC q Switching Frequency.......................... 25KHz TYP q Operating Temperature.................... 0 °C To +70 °C q Efficiency (Unregulated)................... 70% TYP q Short Circuit Protection..................... Current Limit (80-450mA) q Short Circuit RESTART.......................... Automatic q Remote On/Off................................... Active Hi Enable, Pin 2 ELECTRICAL SPECIFICATIONS AT 25OC - OPERATING TEMPERATURE RANGE 0OC TO +70OC PART NUMBER PM-DC05209 INPUT VOLTAGE (Vdc) OUTPUT VOLTAGE (Vdc) OUTPUT CURRENT (mA max.) EFFICIENCY (%) 5.0 9.0 200 75 PACKAGE PHYSICAL DIMENSIONS .... DIMENSIONS IN INCH (mm) PIN#1 DOT P PMDCxxxxx M YYWW 0.504 (12.80) 0.061 X16 (1.55) 0.567 (14.41) 1.000 (25.40) MAX 0.385 (9.78) 0.100 (2.54) 0.040 X16 (1.02) 0.700 (17.78) SUGGESTED PAD LAYOUT 0.34 (8.65) MAX 0° - 8° 0.018 X16 (0.46) 0.040 X16 (1.02) 0.100 X7 (2.54) 0.004 (0.10) PIN 1 2 3 7 8 OTHER SINGLE OUTPUT - INPUT HI-ENABLE + INPUT + OUTPUT - OUTPUT N.C 0.700 (17.78) Specifications subject to change without notice. PM-DCXXXXX 9/2000 20381 BARENTS SEA CIRCLE, LAKE FOREST, CA 92630 • TEL: (949) 452-0511 • FAX: (949) 452-0512 • http://www.premiermag.com 2
