3220-18-2

Pomona ® Model 3220 Minigator Clip To Stacking Banana Plug FEATURES: Provides cross hole for cross stacking, and a jack for vertical stacking. Allows an Alligator Clip with leads to be used from a Banana Jack. MATERIALS: Conn: Insulated Minigator Clip Material: Steel. Finish: Nickel plated. Insulator: Vinyl. Color: Matches color of wire. Conn: Banana Plug Material: Spring, Beryllium Copper per QQ-C-533, Alloy 172, Cond. HT. Plug Body, Brass per QQ-B-626, Alloy 360, ½ Hard. Finish: Nickel plated per QQ-N-290, Class 2, 200/300 microinches. Insulation: Polypropylene molded to plug body and wire. Color: Matches color of wire. Marking: POMONA 3220-XX RATINGS: Operating Temperature: +50º C. (+122º F.) Max. Operating Voltage: Hand-held testing: 30VAC/60VDC Max. Current: 5 Amperes ORDERING INFORMATION: Model 3220-XX-* XX = Cable Lengths, Standard Lengths: 12 (305), 18 (475), 24 (610, 36 (914). Additional lengths can be quoted upon request. *= Color, -0 Black, -2 Red Ordering Example: 3220-36-2 Indicates 36 in length, color is Red. All dimensions are in inches. Tolerances (except noted): .xx = ±.02 (,51 mm), .xxx = ± .005 (,127 mm). All specifications are to the latest revisions. Specifications are subject to change without notice. Registered trademarks are the property of their respective companies. 6/9/99 Made in USA SY/EH/LS W:\pomona\grponly\Datasheet Updates\Updates 2005\d3220_1_02.doc More drawings available at www.pomonaelectronics.com Page 1 of 1
